XPower A-5 Bedienungsanleitung
2-IN-1
Multi-Use Electric
Duster
OWNER’S MANUAL
MODEL: A-5 (115V/60Hz)
Nozzles included
XPOWER MANUFACTURE, INC.
240 Clary Avenue
San Gabriel, CA 91776, USA
PLEASE READ AND SAVE THESE INSTRUCTIONS
........................................................................................................................................
............................................................................................................................................
............................................................................................................................
..............................................................................................................................
Parts List .............................................................................................................................................
Maintenance ......................................................................................................................................
..................................................................................................................
.............................................................................................................................
1
2-3
4,5,6
1
12
TABLE OF CONTENTS
........................................................................................................................................
............................................................................................................................................
............................................................................................................................
..............................................................................................................................
Parts List .............................................................................................................................................
Maintenance ......................................................................................................................................
..................................................................................................................
.............................................................................................................................
1
2-3
4,5,6
1
12
- 1-
INTRODUCTION
Special Features:
• 2-in-1 funcon: Blow and Vacuum.
• Powerful 2HP Motor
• High impact and rugged ABS housing material.
• Easy-to-change and washable filter.
• 2-speed sengs, 3-way switch.
• 5’ heavy duty flexible hose.
• 4 nozzle aachments for endless applicaons.
ersa adapters, you can
findingendless uses !
OPERATION
outlet.
Screw the hose clockwisely to connect to the front hose connector (Fig. A).
over in place on
the rear cover. Turn on switch to desired speed.
All units in use must be monitored at all mes.
Fig. A
Hose Connected to Front
- 2-
Accessories Included
Nozzle Category
Electronics
Genereal Use
Drying
Description Image
Tapered
Straw Adapter
Detail Brush
Standard Nozzle
Standard Brush
Flat Nozzle
The provided black bag is used to pack
the nozzles, excluding Electric Duster.
•Important: Always keep air bleed hole on the hose open when vacuuming in order to
prevent ove
Fig.D
1. Unscrew the hose from the front connector.
2. Remove outer inlet filter and crossed cover of the rear cover (Fig. B).
4. ALWAYS keep air bleed intake hole on the hose open when vacuuming in order to prevent
5. IMPORTANT!
to the motor can occur in drying mode if clean filters and dust case are not in place.
6. Do not vacuum the water when it’s used as a vacuum.
VACUUM OPERATION
Fig. B Fig. C
Air Bleed Hole
- 3-
- 4-
SAFETY INSTRUCTIONS
WARNING: IMPORTANT SAFETY PRECAUTIONS! PLEASE READ COMPLETELY BEFORE
USING PRODUCT!
ld always be followed to reduce the
risk of fire, electric shock, and personal injury, including, but not limited to the following:
Do not use aachments not intended for use with the Electric Duster. Only use aachments
recommended or sold by the manufacturer.
Do not aempt to perform any service or maintenance not outlined in instrucon manual.
Do not use outdoors.
WARNING: This Electric Duster is not intended for use by children. Adult assembly and operation
required. To reduce the risk of injury, close supervision is necessary when an appliance is used
near children.
5. Do not use as a toy.
6. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
7. Do not use extension cords with Electric Duster.
Do not unplug unit by pulling on cord, to unplug, grasp the plug, not the cord.
WARNING: Never use the unit with a damaged cord or plug, or aer the appliance malfuncons or
is dropped, damaged, return to an Authorized Service Center for service, examinaon, repair, or
electrical or mechanical adjustment.
- 5 -
To disconnect, turn all controls to the off (“O”) posion, then remove plug from outlet.
11. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
Do not handle plug or appliance with wet hands.
Use extra care when cleaning on stairs.
DANGER: Do not expose Electric Duster to rain or water.
Do not use or store Electric Duster where it can fall or be pulled into tub or sink or standing water.
If it falls into water, unplug it, do not reach into the water. Keep units out of baths and do not oper-
ate on a wet floor,or wet surface.
16. Do not use to pick up flammable or combusble liquids, such as gasoline, or use in areas where
they may be present. Do not pick up anything that is burning or smoking, such as cigarees,
matches, or hot ashes.
17. WARNING: Do not put any object into Electric Duster openings. Keep loose clothing, jewelry and
hair away from duster openings. Do not use with any opening blocked; keep free of dust, lint,
and anything that may reduce air flow.
19. WARNING: Do not allow any material to clog or block air intakes as this may cause units to
overheat and result in a fire or electrical hazard. Regularly clear hair or other substances from air
intakes. Do not contact moving parts.
SAVE THESE INSTRUCTIONS
HOUSEHOLD and COMMERCIAL USE
grounding means is provided on a double-insulated appliance. Nor should a means for grounding
be added to the appliance. Serving a double-insulated appliance requires extreme care and
knowledge of the system, and should be done only by qualified service personnel. Replacement
A double-insulated appliance is marked with one or more of the following:
The words “DOUBLE INSULATION” or “DOUBLE INSULATED” or the double
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the
outlet. Do not change the plug in any way.
SERVICING OF DOUBLE-INSULATED APPLIANCES
- 6 -
Model A-5 Size (L x W x H) 10.3" x 5.2" x 8"
Volt/Cycle 115V / 60Hz Cord Length 5'
Horse Power 2HP Hose Length 5'
Amp Draw 8A OverheangProtecon Thermal
Unit Weight4.8 lbs. Max. Airflow100 CFM
Speeds Control 2 Speeds: Hi / Low Housing Material ABS
SPECIFICATIONS
- 7-
SPECIFICATIONS
Model
Volt/Cycle
Horse Power
Amp Draw
Unit Weight
Speeds Control
Size (L x W x H)
Cord Length
A-5
4.8 lbs
2 Speeds: Hi / Low
Thermal
Housing Material ABS
Hose Length
Max. Airflow 100 CFM
115V / 60Hz
2HP
8A
10.3X5.2X8 inch
5’
5’
- 7-
1
2
Right housing
3
Switch
4
5
Air outlet grid
6
7
8
Sponge pad 1
9
Motor
10
Dustproof cover
11
Motor filter
12
Dust case
13
Dust bag
14
Rear cover
15
16
Crossed cover
17
18
Inlet filter
19
Hose
20
Power cord
Standard nozzle with brush
Tapered flow nozzle with brush
Sponge pad 2
Sponge pad 3
Flat nozzle
PARTS LIST
1819
20 21
Square nozzle
21
1
2
3
4
5
6
7
8
9
10
11
12
16 15
13
14
17
MAINTENANCE
reach
-8-
