LUSTRE AND LUCIA DIFFUSERS
OPERATION MANUAL
LUSTRE DIFFUSERLUCIA DIFFUSER
English 2
Français 15
Español 28
Deutsch 41
中文 54
Bahasa 66
2
Contents
Overview.............................................................................................................3
Contents..............................................................................................................3
Diagram...............................................................................................................4
Operating Instructions.......................................................................................6
Functionality........................................................................................................7
Diffusion settings......................................................................... .7
Light settings..................................................................................8
Safety and Care Instructions..............................................................................8
Cleaning and Maintenance..............................................................................10
Troubleshooting.................................................................................................11
Specifications......................................................................................................12
Young Living Diffuser Warranty.........................................................................13
3
Overview
Young Living’s Lustre and Lucia Diffusers feature hand-blown glass covers
that set an exotic and modern tone in any space. Each diffuser functions as a
humidifier, atomizer, and aroma diffuser in one simple-to-use product. They
also help reduce your home’s toxin footprint by replacing harmful household
fragrances and chemicals with effective, naturally derived essential oils.
Using ultrasonic frequency technology, the Lustre and Lucia Diffusers
generate waves at 1.7 million per second, breaking down essential oils
and water into millions of microparticles, dispersing them into the air and
releasing the constituents found in the oils for you to enjoy.
Contents
Lustre Diffuser, AC Power Adapter, and Quick Start Guide
or
Lucia Diffuser, AC Power Adapter, and Quick Start Guide
ENGLISH
4
Diagram
Transparent view
Outer glass cover
(Model will determine overall shape)
Diffuser
On/Off/
Timer
buttons
Light
On/Off
button
Splash
guard
5
X
X
Diagram
Inner lid
Mist spout
Diffuser base
Alignment
gasket
Water
fill line
Fan intake
Fan intake
Lustre BaseLucia Base
Ventilation
hole
Adapter
port
Adapter
port
Ultrasonic
plate
6
Operating Instructions
1. Remove the outer glass cover by holding the base securely and gently
lifting the cover. Remove the inner lid of the diffuser.
2. Make sure that the reservoir is empty of water.
3. Insert the power adapter plug securely into the jack found at the
bottom of the Lustre Diffuser or on the side of the Lucia Diffuser.
4. Set the diffuser on a hard, flat surface.
5. Add water to the reservoir until the level reaches but does not exceed
the water fill line.
6. Add 8–10 drops of essential oil.
7. Place the inner lid back onto the diffuser. Make sure to align the lid
to the reservoir. The lid should sit flush on the reservoir on all sides;
otherwise leaking will occur.
8. Replace the outer glass cover so that it fits securely over the rubber
alignment gasket and sits flush on the base.
9. Plug the power adapter into a power outlet.
10. Press the On/Off button to switch the diffuser on.
11. The diffuser will produce mist, and the LED light will turn on.
7
Functionality
Diffusion settings
• Press the On/Off button once to turn on the diffuser and begin
continuous mist operation. Continuous operation is approximately 6
hours for the Lustre and 3 hours for the Lucia, with water filled to the
max fill line. Continuous mode is indicated by a solid light.
• For intermittent mode, press the On/Off button a second time to
activate it. The diffuser will run for 30 seconds on and 30 seconds off for
up to 12 hours for the Lustre and up to 6 hours for the Lucia. Intermittent
mode is indicated by a slow flashing light.
• For 60, 90, or 120 minutes of continuous operation, press the On/Off
button a third time. Timer mode is indicated by a solid light over the
selected time.
• To turn off the diffuser while in any mode, press and hold the On/Off
button for 2 seconds. All lights will turn off.
Note: The diffuser and lights will turn off automatically when the reservoir
is empty.
On/Off/Timer
button Light button
Timer indicator lights
8
Light settings
While the diffuser is running in default mode, the light will cycle through the
colors at 5-second intervals.
• Press the light button once for each color until the static individual color
option (off-white, green, blue, red, yellow, lavender, or white) appears.
• To run the light without diffusion, press the light button once while the
diffuser is off to start color-cycle mode.
• You can turn off the light at any time by pressing and holding the
light button for 2 seconds.
Please read and follow these safety guidelines closely to ensure safe
operation of the diffuser.
• Unplug the diffuser immediately and discontinue use in the event of
smoke or a burning smell.
• Use room-temperature tap, spring, or mineral water.
• Never wrap the adapter with cloth, paper, etc. Such actions may result in
fire or damage to the diffuser.
• Never touch the adapter with wet hands; electric shock or injury
may occur.
• Do not disassemble or attempt to repair the diffuser; this will void
the warranty.
• Never immerse the diffuser in water.
• Unplug the adapter when refilling, cleaning, or moving the diffuser.
• Keep the diffuser out of reach of children.
Safety and Care Instructions
9
• Do not remove or place objects in the water reservoir during operation.
• Do not place your fingers in the water during operation; this may result
in injury.
• Do not place acidic or alkaline chemicals in the reservoir.
• Use only the included power adapter provided in the packaging or by
Young Living.
• Do not shake the diffuser.
• Any damage caused by the user does not qualify such user for
replacement of any or all parts by Young Living.
• Do not use metal objects to clean the ultrasonic plate; use only a cotton
swab or cloth dipped in rubbing alcohol or a neutral detergent.
• Never use the diffuser for purposes other than those listed in
this manual.
• If the diffuser will not be used for an extended period or needs to be
relocated, unplug the power adapter, empty the water reservoir, and
wipe the water reservoir interior clean before storing or moving.
• Clean the diffuser before switching essential oils.
• Use only 100 percent pure, natural essential oils. Artificial, synthetic, or
impure oils and fragrances can damage the diffuser.
• The water level should not exceed the water fill line.
• When unplugging the power adapter, pull from the adapter plug instead
of pulling the wire.
• Avoid placing the diffuser in direct sunlight, close to a refrigerator or fan,
or in a hot environment.
10
Always turn off and unplug the diffuser prior to cleaning. To ensure proper
performance, clean the ultrasonic plate and lid after each use. If essential oil
begins to build up on the ultrasonic plate, gently wipe it off using a cotton
swab dipped in rubbing alcohol. If essential oil begins to build up on the
lid, gently wipe it off using mild soap and water only. Never use a corrosive
detergent to clean the ultrasonic plate or damage will occur. Periodically
check under the diffuser to keep the fan intake free of debris. Debris can be
removed by blowing on the fan intake opening or wiping with a clean, dry
cloth. Do not use aerosol sprays, solvents, or abrasives to clean the plastic
housing. When not in use, clean the diffuser and store dry.
Cleaning and Maintenance
Notice: When emptying
the water reservoir, pour
the water from the opposite
side of the reservoir
ventilation hole.
X
