ZKTeco FA50 Bedienungsanleitung

Installation Guide

FA50

Version: 1.0

Due to regular system upgrades and products, ZKTeco could not guarantee exact consistency between

the actual product and the written information in this manual.

- 1 -

Operation Instructions

1.

Figure 1-1

1. The device has two USB plugs, as shown in the below Figure 1-1.

Insert the USB cable "A" of FA50M into the USB port situated on the

host’s back, as shown in Figure 1-2.

Figure 1-2

- 2 -

2. Right-click on My Computer > Properties > Device Manager.

As shown in the figure below, if "Imaging devices" and "libusb-win32

Usb Devices" appear, users can continue using the same device. But

if "Imaging devices" and "libusb-win32 Usb Devices" did not appear,

it means that the device did not get connected appropriately.

Note: Generally, it is due to the insufficient power supply of the USB.

Just insert the USB cable "B" into the USB port of the host.

Figure 1-3

- 3 -

Steps to Run Demo for the First Time on Windows

2.

Double-click and open the "FA50 Demo" file, then click "FA50M

InstallDriver" to install the driver, as shown in Figure 2-1.

Driver Installation

Figure 2-1

- 4 -

On the Installation window, click "Next", as shown in Figure 2-2.

Figure 2-2

Then click "Finish" to successfully install the driver.

Figure 2-3

Demo Test Process

3.

1. Double-click and open the "FA50 Demo" file, and then open the

Demo Test software, as shown in Figure 3-1.

Figure 3-1

2. On the Demo Test software, firstly click "Open" to open the UVC

camera. The camera gets opened successfully only if "Camera

opened" gets displayed. Then the camera successfully captures the

image and displays it, as shown in Figure 3-2.

Figure 3-2

- 5 -

Secondly, as shown in Figure 3-3, click "Open" to open HID, and "HID

ope ned " wil l g et displayed, w hic h m ean s the HID ope ned

successfully.

Figure 3-3

3. Next, enter the registrant ID in the "User ID" field, then aim your

face at the camera, and click "Add User" to register the user ID.

And as shown in Figure 3-4, if "Add User successfully" appears, it

means that the user ID is successfully registered.

- 6 -

Figure 3-4

Click "Enroll face" to register face, and if "Enroll face successfully"

gets displayed, it means that face registration is successful.

Figure 3-5

As shown in Figure 3-6, the software displays the recognized

registration ID's username, and thus the recognition process is

complete.

Figure 3-6

- 7 -

To clear the user, click the "Clear User" button, and if " Clear User

successfully" gets displayed, it means that the user removal is

successful.

Figure 3-7

Precautions

4.

1. If the registration gets failed, click "Clear User" to clear the user

and register again.

- 8 -

Figure 4-1

- 9 -

2. When clicking "Open" to open HID, and if "No device found" gets

displayed, carry out the following solutions.

Insufficient power supply, plug in two USB ports.

The driver did not get installed successfully, repeat the steps of the

driver installation process.

Figure 4-2
