Installation Guide SpeedFace-V3LVersion: 1.0Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.

1How to Install the Device?Installation EnvironmentPlease refer to the following recommendations for installation.AVOID DIRECT SUNLIGHT AND EXPOSUREAVOID GLASS REFRACTIONKEEP EFFECTIVEDISTANCE0.3-2.5mKEEP DISTANCE10ft

6.5ft

window

Device InstallationFix the backplate on the wall using wall mounting screws.Attach the device to the backplate.Fasten the device to the backplate with a security screw.①②③④Attach the mounting template sticker to the wall, and drill holes according to the mounting paper.11.5m243①②

2Power ConnectionWiring DiagramRecommended AC Adapter：1) 12V ± 10%, at least 1500mA.2) To share the power with other devices, use an AC Adapter with higher current ratings. 12VEthernet ConnectionClick on [COMM.] > [Ethernet] > [IP Address] , input the IP address and click on [OK].IP address: 192.168.1.130Subnet mask: 255.255.255.0Default IP address: 192.168.1.201Subnet mask: 255.255.255.0Connect the device and computer software over an Ethernet cable. As shown in the example below:ZKBio AccessNote: In LAN, the IP addresses of the server (PC) and the device must be in thesame network segment when connecting to the ZKBio Access software.

3Wiegand Reader ConnectionNote: 485A and 485B can be connected to the Barrier gate or the 485 Reader, separately, but cannot be connected to the gate and reader at the same time. RS485 Connection WD0 WD1485A485BWD0-OUTWD1-OUTINWD0INWD1GND12V-OUTWiegand Reader+12VGND WD1 WD0Access Controller485 Reader+12VGND485+485-485A485BWD0-OUTWD1-OUTINWD0INWD1GND12V-OUT

Door Sensor, Exit Button, Alarm & Auxiliary Connection4NCCOMNOSENGNDBUTAUXGNDBELL+BELL-ALARM+ALARM-

AlarmAlarm Power NOCOM

SmokeDetectorExitButtonDoor SensorLock Relay ConnectionThe system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals. Take NC Lock as an example below:1)Device not sharing power with the lock2)Device sharing power with the lockNormally Closed LockNormally Closed LockGNDDC12VFR107Maximum 30V 3A input.+12VDC12VGNDDC12VFR107+12VNCCOMNOSENGNDBUTNCCOMNOSENGNDBUT
