ZMODO ZH-IZV15-WAC Bedienungsanleitung

What’s in the Box:

Camera, bracket, power adapter,

screws & anchors, quick start guide

Quick Start Guide

Smart Pan & Tilt Camera

Connect with us!

Like us on

Facebook.com/Zmodo

Solid red

Having difficulty? Please visit our support page for more

instructions,troubleshooting, and other resources:

http://www.zmodo.com/supports

Android is a trademark of Google Inc. Google Play is a trademark of Google Inc.

Apple, the Apple logo, and iPhone are trademarks of Apple Inc., registered in the

U.S. and other countries. App Store is a service mark of Apple Inc.

Solid blue Blinking blue

The camera can't connect to the WiFi. Why?

You may have entered the password incorrectly. Try re-

entering your WiFi password.

You may not have a working internal connection. Check to

see if your router is connected to the Internet. Try

resetting your camera by pressing the reset pinhole on the

bottom of the camera. Hold the button until the light turns

blinking green. Then begin the setup procedure again.

Blinking green

Solid green

The camera is powering

on.

The camera is ready for

SmartLink setup.

The camera has

successfully connected to

the WiFi network.

The camera is connecting

to the WiFi network. Please

do NOT turn off or unplug

the camera.

Twitter @Zmodo

Status Indicator Guide

Set up the camera and find the best mounting location based on

the live view from your smartphone. Make sure that your camera is

within range of your WiFi network.

2Take the PT camera and line it up

to the bracket as shown, using

the provided screws to fasten the

camera to the mounting bracket.

(Screw)

(Bracket)

3After you’ve attached the bracket to

the camera, slide the bracket onto

the two screws that you inserted

into the wall in Step 1

1Line the camera’s mounting bracket

against the wall and mark the

appropriate holes. Drill two holes

slightly smaller than the wall anchor

and use a hammer to gently insert

the anchors into the wall. Insert the

screws into the anchors.

Mounting the Camera

MeShare App Interface

View captured alarm

snapshots.

Enter the device's live view.

My MeShare Interface

Live view Interface

Pan Tilt Control Interface

Access device settings.

Invite your family or friends

to view the clips of moments.

Rotate the camera by

using the control stick.

Record videos directly

onto your phone. Tap

once to record, and tap

again to stop recording.

Capture photos directly

onto your phone.

Activate the push-to-

talk function.

Enable / disable audio.

Change the display

resolution.

Enter the Pan Tilt Control

Interface.

6 9

11 11

Viewing & Recording Options

Local Recording(microSD Card not included)

Record continuous footage by inserting a microSD card (up to

64GB) into the corresponding port on the camera (please see

the diagram on the box).

Note: You will need to format the microSD card in the MeShare app

after inserting it. You can do so through the device settings menu.

Now compatible with MeShare!

We have partnered with MeShare to bring you optional cloud

services! The MeShare Cloud Service (MCS) allows you to:

Visit for more information on www.meshare.com/cloud

plans and features.

Create and save video clips from your recordings.

Access your playback footage and clips from any

location with Internet connection.

Share recorded footage and clips with family and

friends.

Access more smart features in the future!

Record continuously and store the footage on our

secure cloud servers.

MeShare Web App

You can also view your device on any computer using MeShare’s

free web app. Simply use your MeShare username and password

and log in to user.meshare.com.

Camera Setup

Congratulations! We are excited to welcome you to the next

generation of smart technology. Follow the steps below to set

up your camera. To get started, all you need is a smartphone

and WiFi:

1TM ®

Connect your Android phone or iPhone to the WiFi

network that you want your camera to use. Make sure

that you know the password to connect to this network.

System Requirements: Android™ (v.4.0 or newer) or

® ® ®

iPhone , iPad , iPod touch (v.7.0 or newer) ,a

password-protected 2.4GHz WiFi network.

3Log in and press the Add Device option located

on the bottom of the screen, and follow the on-

screen instructions to complete your setup!

Note: Plug the power adapter into the power input

located at the bottom of the camera.

2Download and install the ‘MeShare’ app from Google

TM TM

Play or the App Store . Launch the app and sign up

for a free MeShare account.

MeShare
