ACTi D91 Bedienungsanleitung

Indoor Mini Dome &

Indoor Mini Fisheye Dome

Hardware Manual

D91, D92, E91, E92, E93, E94, E95, E96,

E97

Ver. 2013/09/12

www.acti.com

Hardware Manual

Table of Contents

Precautions 3

Safety Instructions ...........................................................................5

Introduction 6

List of Models....................................................................................6

Package Contents.............................................................................7

Physical Description ........................................................................8

Installation Procedures 9

Mount the Camera ............................................................................9

Surface Mount..............................................................................10

Gang Box Mount..........................................................................13

Basic Connections .........................................................................16

Accessing the Camera 17

Configure the IP Addresses...........................................................17

Using DHCP Server to Assign IPAddresses................................17

Using the Default Camera IP Address..........................................19

Access the Camera.........................................................................21

Other Adjustments and Accessories 23

Adjust the Viewing Angle and Focus............................................23

Replace the Dome Cover................................................................25

www.acti.com

Hardware Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please inform your

local office if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

www.acti.com

Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

www.acti.com

Hardware Manual

Safety Instructions

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

cause hazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device in a dry place protected from weather

Servicing

Do not attempt to service this video product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the video product.

3) If the video product has been directly exposed to rain or water.

4) If the video product does not operate normally by following the operating Instructions in

this manual. Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal

operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

www.acti.com

Hardware Manual

Introduction

List of Models

This hardware manual contains the following models:

D91

1MP Indoor Mini Dome with Fixed lens

D92

3MP Indoor Mini Dome with Fixed lens

E91

1MP Indoor Mini Dome with Basic WDR, Fixed lens

E92

3MP Indoor Mini Dome with Basic WDR, Fixed lens

E93

5MP Indoor Mini Dome with Basic WDR, Fixed lens

E94

1.3MP Indoor Mini Dome with Basic WDR, SLLS, Fixed lens

E95

2MP Indoor Mini Dome with Basic WDR, SLLS, Fixed lens

E96

5MP Indoor Mini Fisheye Dome with Basic WDR, Fixed lens

E97

10MP Indoor Mini Dome with Basic WDR, Fixed lens

www.acti.com

Hardware Manual

Package Contents

Camera

E96 (Mini Fisheye Dome)

Screw Kit

Drill Template

Hexagon Screwdriver

(Available in select models only)

Lens Focus Tuner

(Not available in E93 and E96 models)

Quick Installation Guide

Warranty Card

Drill Template

www.acti.com

Hardware Manual

Physical Description

1) Ethernet Port

The Ethernet port connects to a network using an Ethernet cable.

2) Reset Button

The Reset Button is used to restore the factory default settings of the camera, including the

administrator’s password.

While the power is on, press and hold the1 Reset Button for 5 seconds to reset the camera.

3) Power LED

The Power LED lights up when the power is on.

4) MicroSDHC Card Slot

Insert a microSDHC card into the slot for local recording.

www.acti.com

Hardware Manual

Installation Procedures

Mount the Camera

Before mounting the camera, remove the dome cover by loosening the three (3) screws.

There are two ways to mount the camera:

Surface mount: Use this method to mount the camera directly on the ceiling. See

Surface Mount on page 10.

Gang Box Mount: If the camera will be mounted on a gang box (applicable in some

areas in the US), a gang box converter (not included in the camera package) is

needed. See Gang Box Mount on page 13.

www.acti.com

Hardware Manual

Surface Mount

1. Mark the location of the screw holes base on the drill template included in the package.

NOTE: Depending on the surface where you will install the camera, it may be necessary to

drill three (3) holes with φ3.5 on the ceiling and use the supplied screw tox.

2. Route the cables through the ceiling, taking the Conduit Hole on the drilling template as a

reference. Or, slide off the cable exit tab on the dome cover to route the cable through that

hole later.

Conduit Hole
