@Adam Equipment Company 2005

Adam Equipment

CBW SERIES

SERVICE MANUAL

ADAM EQUIPMENT CO. LTD.

p.n. 4331, Rev. A3, January 2005

@Adam Equipment Company 2005

CONTENTS

1.0 INTRODUCTION .............................................................................................3

2.0 TROUBLE SHOOTING GUIDE........................................................................3

3.0 ERROR CODES ..............................................................................................5

4.0 CBW DESCRIPTION .......................................................................................6

5.0 CBW CALIBRATION & PARAMETERS (VER.1.2-2.03)..................................7

5.1 CBW CALIBRATION (VER. 1.2-2.03) ..........................................................7

5.2 CBW PARAMETERS (VER. 1.2-2.03)..........................................................8

6.0 TWO POINT FACTORY CALIBRATION........................................................10

6.1 ADC OUTPUT CHECKING............................................................................11

7.0 LOAD CELL DAMAGE...................................................................................12

8.0 CBW RS-232 INSTALLATION.......................................................................14

9.0 SCHEMATICS ...............................................................................................16

@Adam Equipment Company 2005

1.0 INTRODUCTION

The CBW series of scales are general purpose scales.

Refer to the Operators Manual for details of operation.

This manual will cover details of calibration and troubleshooting.

If you have a problem with the scales that is not directly addressed by this manual

then contact your dealer or Adam Equipment for more assistance.

In order to supply further assistance we will need the following information:

2.0 TROUBLE SHOOTING GUIDE

PROBLEM POSSIBLE CAUSE

Display is blank Power Switch faulty or not connected

No turn on test Battery not charged or faulty

Power supply faulty or incorrect type

E6 is displayed Pan not installed

Poor connection

Load cell damaged

Electronics faulty

“- - - - - -“appears on display Maximum capacity exceeded

Load Cell damaged

Electronics is faulty

Name of your company:

Contact Name:

Contact telephone, e-mail, fax or other methods:

Model number of the scales:

Serial number:

Software revision number (displayed when power is first turned on):

Brief description of the problem:

Include any recent history of the scale. For example-

Has it been working since it’s delivered

Water entered

Damaged from a fire

Electrical Storms in the area

Dropped on the floor, etc.

@Adam Equipment Company 2005

Display is unstable Drafts or air currents

Obstruction under pan

Sample is moving (animal weighing)

Vibrations through table

Temperature changed dramatically

Electronics faulty or Battery low

Weight value incorrect Calibration error, Recalibrate

Unit calibrated with inaccurate weight

Balance not level

Obstruction between sample pan

Wrong unit of weight displayed

Cannot use Full Capacity Over-load Stops hitting pan support or hitting

bottom of load cell

Electronics faulty

Parameters set incorrectly

Load Cell Damaged

Not Linear Overload stops hitting too soon

Faulty factory calibration

Off Centre Loading error Overload Stops not correct

Obstruction under pan

Battery will not charge Charging circuit failure

Battery Failure

Incorrect adapter (below 800 mA)

Processor failure

@Adam Equipment Company 2005

3.0 ERROR CODES

ERROR CODE DESCRIPTION POSSIBLE CAUSES



Initial Zero is greater than

allowed (4% of maximum

capacity) when power is turned

on or when the [Zero/Enter] key

is pressed.

Weight on the pan when turning

the scale on.

Excessive weight on the pan when

zeroing the scale.

Improper calibration of the scale.

Damaged load cell.

Damaged Electronics.



Keyboard error. Improper operation of the scale.



A/D count is not correct when

turning the scale on. Platform is not installed.

Load cell is damaged.

Electronics is damaged.



Scale is not stable when setting

the percentage weighing. The scale is not stable.

Improper operation of the scale.





or

in old

versions



Calibration error. Improper calibration (should be

within + 10% of the factory

calibration). The old calibration

data will be retained until the

calibration process is complete.



Scale is unstable. There is vibration or draft making

the scale unstable.

Electronics may be damaged.

@Adam Equipment Company 2005

4.0 CBW DESCRIPTION

The CBW scales have an enclosure with all components mounted within it. To gain

access to the components remove the 4 screws securing the cover to the base.

The basic unit consists of:

Base

Load Cell frame

Power switch

Main PCB assembly

Battery

Display PCB assembly

Keypad

All models of CBW are similar except the selection of load cells and the program.

The main circuit board is the same as used in the CBC scales. Normally if a problem

is found with a circuit board the most cost effective method of solving the problem is

to replace the circuit board.

Schematics are attached in order to complete the documentation. However it is rare

that the problem due to a faulty component on the PCB is traced by a user.

The main PCB assembly includes:

A/D converter (AU1),

Microprocessor (DU1) and

Power supply/battery charger circuits (DU5, T2).

@Adam Equipment Company 2005

5.0 CBW CALIBRATION & PARAMETERS (VER.1.2-2.03)

5.1 CBW CALIBRATION (VER. 1.2-2.03)

The CBW scales calibrate using metric weights and the CBWa scales can calibrate

using either metric or pound weights, depending on the weighing unit in use before

calibration.

To start calibration turn the scale off and then turn it on again. Press the [Tare] and

[%] keys together once, during the initial counting from 9 to 0 on the display.

The display will show "



". Remove all weight from the pan and then press the

[Zero/Enter] key to set the initial zero point when the scale is stable.

The display will then show “



” at which point the calibration mass should be

placed on the pan. It is best to use a weight close to the full capacity of the scale.

Press the [Zero/Enter] key. The display will then show the last mass used. If this is

the same as the mass on the pan then this can be used or a different value can be

entered.

To use this value, press the [Zero/Enter] key when the stable indicator is on.

Or if a different value is desired, enter the value using the []arrow key to select the

flashing digit and the []to increment the flashing digit. If value is correct, press the

[Zero/Enter] key to accept when the stable indicator is on.

Remove the calibration weight as the scale counts back from 9 to 0.

If an error message “

 

” or “

 

” is shown during calibration, re-check the

calibration and repeat, if necessary. If the error cannot be corrected contact your

dealer or Adam Equipment for advice.

After calibration the scale should be checked to verify the calibration and linearity is

correct. If necessary, repeat the calibration.

Note: Ensure that the scale is stable before accepting any weight.

To view the ADC Counts press [Zero/Enter] and [%] together. At zero load, it

should be 25,000 and at full load, it should be approximately 500,000.

CBW

a scales

will also have the Lb or Kg (or g)

indicator on to show the

denomination of the weight requested. If the scale was in pounds before starting

calibration the weights requested will be pound values, or if the scale was weighing in

kilograms then metric weights will be requested.

@Adam Equipment Company 2005

5.2 CBW PARAMETERS (VER. 1.2-2.03)

The scale has several parameters that allow the user to set the scale to:

Display the weight in other increments of weight to minimise the affects of

vibration, wind or other environmental conditions.

Control the back light on the display. It may be necessary to turn the backlight

off to maximise battery life.

Set the Accumulation to Automatic, manual or set the RS-232 interface to

continuously print the weight.

Set the accumulation to be active when [Print] key is pressed or to be inactive.

Set a range for auto zero.

Select another weighing unit than the standard.

Disable the Limit Warning Beeper.

Adjust the ADC Speed.

To set these parameters press the [Func] and [Print] keys at the same time.

Setting the scale increment

The display will show "



" where



can be 1, 2, 5,10 or 20. The first value

shown is the default scale increment value.

To change to a different increment value press [Tare/].

Press the [Zero/Enter] key to store the changed value.

For example, on a 15kg scale the standard increment is 0.5g, the value can be

changed to 1.0g or 2.0g.

Control the backlight

The standard is to have the backlight operate automatically, turning it off when

the scale is not being used.

The backlight can be set to be "

 

", "

 

" (Automatic) or "

 

". The

maximum battery life is achieved with the backlight turned off.

Press the [Tare/] key to change the setting.

Press the [Zero/Enter] to store the changed setting.

Automatic accumulation

With "



" the memory will accumulate the weight automatically.



" will enable the manual accumulation.

 

" will set the RS-232 interface to send the weight continuously and the

accumulation function is disabled.

@Adam Equipment Company 2005

Press the [Tare/]key to change the setting.

Press the [Zero/Enter] key to store the changed setting.

Accumulation of data in memory when [Print] is pressed

To accumulate weight in the memory when [Print] is pressed, set "



". To

use the [Print] key to only print the weight without adding it to memory, set "





Press [Tare/]to change the setting between



and



Press the [Zero/Enter] key to store the changed setting.

Auto zero range

The auto-zero will automatically set the scale to zero when the displayed weight

is almost near zero. This helps to make sure that the scale is measuring weight

from an accurate zero starting point.

The Auto zero value can be set to 0.5, 1, 2 or 4 scale divisions. The normal

setting is 1 scale division. The display will show “



”.

Press the [Tare/]key to change the value.

Press the [Zero/Enter] key to store the changed setting.

Selectable unit of weight displayed

The scales are normally set to display in kilograms, however they will show the

weight in grams, if enabled.

The display will show “



” or “



”.

Press [Tare/]to change the setting between







Press the [Zero/Enter] key to store the changed setting.

The CBWa scales can change units from kilograms to grams, pounds or

pounds/ounces immediately if they are enabled as in the step above. This also

allows the scales to be calibrated in either kilograms or pounds and all memory

accumulations are in either kilograms or pounds as last selected.

When the scales are set to display in other units of weight the accumulation

function is still keeping the weight in kilograms (or pounds for the CBWa series)

in memory and will use the base weighing unit when printing over the RS-232

interface.

@Adam Equipment Company 2005

Setting of the check weighing alarm

The display will show “



” where “



” is a digit from





will set the buzzer to off when check weighing

will set the buzzer to on when the OK symbol is on

will set the buzzer to on when the weight is outside the OK symbol limit

To change this digit press the [Tare/]key.

Press the [Zero/Enter] key to store the changed value and continue to the next

parameter.

Speed at which the machine will run the ADC

The slowest setting is



and the fastest is



. The default setting is usually



The display will show “



”.

To change this setting press the [Tare/]key.

Press [Zero/Enter] to store the changed value and return to the normal weighing.

6.0 TWO POINT FACTORY CALIBRATION

This procedure is the same as normal calibration but can be set even if the stability

indicator will not show or when the raw counts do not seem to be moving.

Please ensure that the load cell is not damaged and that the load cell is wired

correctly with the right output voltages.

To start the factory calibration, turn the scale off and then turn it back on. Press the

[Limit] and [%] keys together during the initial counting from 9 to 0 on the display.

The display will show "



". Remove all weight from the pan and then press the

[Zero/Enter] key to set the initial zero point when the scale is stable.

The display will then show the first calibration weight used. This value will be one

third of the scale capacity.

Place this value weight on the scale and press the [Zero/Enter] key when the stable

indicator is on

The display will then show then second value weight to be used which will be full

capacity of the scale.

Place this value calibration weight on the platform and then press the [Zero/Enter]

key when the stable indicator is on.

Remove the calibration weight as the scale counts back from 9 to 0.

Andere Handbücher für CBW Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Adam Equipment Skala Handbücher

Adam Equipment

Adam Equipment CBK series Bedienungsanleitung

Adam Equipment

Adam Equipment CBK series Bedienungsanleitung

Adam Equipment

Adam Equipment AQT Series Bedienungsanleitung

Adam Equipment

Adam Equipment CBC SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment Luna LAB Series Bedienungsanleitung

Adam Equipment

Adam Equipment LBX 12 Bedienungsanleitung

Adam Equipment

Adam Equipment ACBplus Series Bedienungsanleitung

Adam Equipment

Adam Equipment 700660189 Bedienungsanleitung

Adam Equipment

Adam Equipment RAV Series Bedienungsanleitung

Adam Equipment

Adam Equipment Nimbus NBL Serie Bedienungsanleitung

Adam Equipment

Adam Equipment CFC SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment MUW Bedienungsanleitung

Adam Equipment

Adam Equipment SHS Series Bedienungsanleitung

Adam Equipment

Adam Equipment IHS Series Bedienungsanleitung

Adam Equipment

Adam Equipment MDW-160M Bedienungsanleitung

Adam Equipment

Adam Equipment CBW Series Bedienungsanleitung

Adam Equipment

Adam Equipment CBC SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment ACB-600H Bedienungsanleitung

Adam Equipment

Adam Equipment BCT Series Bedienungsanleitung

Adam Equipment

Adam Equipment Cruiser Count Series Bedienungsanleitung

Adam Equipment

Adam Equipment HIGHLAND SERIES Bedienungsanleitung

Adam Equipment

Adam Equipment CBD Series Bedienungsanleitung

Adam Equipment

Adam Equipment CCT Series Bedienungsanleitung

Adam Equipment

Adam Equipment LBK Series Bedienungsanleitung

Beliebte Skala Handbücher anderer Marken

AWS

AWS ZEO-50 Bedienungsanleitung

Gima

Gima Glass Body Fat Analyzer Stücklistenhandbuch

Seca

Seca 374 Bedienungsanleitung

TEC

TEC TEC SL59 SERIES Bedienungsanleitung

Axis

Axis B/E Series Bedienungsanleitung

Alecto

Alecto ACW-40 Bedienungsanleitung

Rice Lake

Rice Lake MSI-4260 IS Bedienungsanleitung

IKA

IKA RCT basic safety control Bedienungsanleitung

ADE

ADE M20011 Bedienungsanleitung

Duronic

Duronic KS3000 Bedienungsanleitung

Digi

Digi SM-720 Bedienungsanleitung

Cardinal

Cardinal CS Series Bedienungsanleitung

Korona

Korona Kastella Bedienungsanleitung

A&D

A&D FC-50Ki Bedienungsanleitung

BDA

BDA CAMARGUE Bedienungsanleitung

Tanita

Tanita HD-357 Bedienungsanleitung

Leifheit

Leifheit 03173 Bedienungsanleitung

Lumme

Lumme LU-1340 Bedienungsanleitung
