Agilent Technologies

Agilent 490

Micro GC Natural Gas

Analyzer

User Manual

Notices

No part of this manual may be reproduced

in any form or by any means (including

electronic storage and retrieval or transla-

tion into a foreign language) without prior

agreement and written consent from

Agilent Technologies, Inc. as governed by

United States and international copyright

laws.

Manual Part Number

G3582-90002

Edition

First edition, May 2012

Printed in USA

Agilent Technologies, Inc.

2850 Centerville Road

Wilmington, DE 19808-1610 USA

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Agilent disclaims all warranties,

either express or implied, with regard

to this manual and any information

contained herein, including but not

limited to the implied warranties of

merchantability and fitness for a par-

ticular purpose. Agilent shall not be

liable for errors or for incidental or

consequential damages in connection

with the furnishing, use, or perfor-

mance of this document or of any

information contained herein. Should

Agilent and the user have a separate

written agreement with warranty

terms covering the material in this

document that conflict with these

terms, the warranty terms in the sep-

arate agreement shall control.

Technology Licenses

The hardware and/or software described in

this document are furnished under a

license and may be used or copied only in

accordance with the terms of such license.

Restricted Rights Legend

If software is for use in the performance of

a U.S. Government prime contract or sub-

contract, Software is delivered and

licensed as “Commercial computer soft-

ware” as defined in DFAR 252.227-7014

(June 1995), or as a “commercial item” as

defined in FAR 2.101(a) or as “Restricted

computer software” as defined in FAR

52.227-19 (June 1987) or any equivalent

agency regulation or contract clause. Use,

duplication or disclosure of Software is

subject to Agilent Technologies’ standard

commercial license terms, and non-DOD

Departments and Agencies of the U.S.

Government will receive no greater than

Restricted Rights as defined in FAR

52.227-19(c)(1-2) (June 1987). U.S. Govern-

ment users will receive no greater than

Limited Rights as defined in FAR 52.227-14

(June 1987) or DFAR 252.227-7015 (b)(2)

(November 1995), as applicable in any

technical data.

Safety Notices

CAUTION

A CAUTION notice denotes a

hazard. It calls attention to an oper-

ating procedure, practice, or the

like that, if not correctly performed

or adhered to, could result in

damage to the product or loss of

important data. Do not proceed

beyond a CAUTION notice until the

indicated conditions are fully

understood and met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and met.

Natural Gas Analyzer 3

Contents

1 Agilent 490 Micro GC - Natural Gas Analyzers

Introduction 5

Types of Agilent 490 Micro GC - Natural Gas Analyzers 5

Agilent 490 Micro GC - Natural Gas Analyzer A and the Extended

Version 6

Natural Gas Analyzer A 6

Natural Gas Analyzer A Extended 6

Agilent 490 Micro GC - Natural Gas Analyzer B and the Extended

Version 7

Natural Gas Analyzer B 7

Natural Gas Analyzer B Extended 7

2 Checkout Information

Introduction 8

Natural Gas Analyzer A and the A Extended Version 10

HayeSep A straight 10

6 meter CP-Sil 5 CB 11

HayeSep A backflush 13

4 meter CP-Sil 5 CB 14

8 meter CP-Sil 5 CB 16

Natural Gas Analyzer B and B Extended Version 18

PoraPLOT U 18

6 meter CP Sil 5 CB 20

CP-Molsieve 5A 22

3 Tuning the Backflush Time

Tuning the Backflush Time on CP-Molsieve 5A, PoraPLOT U, or CP-Sil 5

CB 24

Tuning procedure for the backflush time 24

Tuning the Backflush Time on a HayeSep A 26

Tuning procedure for HayeSep A channel 26

Natural Gas Analyzer 4

A Appendix A: Certificate of the NGA Gas Calibration Standard

B Appendix B: Certificate of the Universal Gas Calibration Standard

C Appendix C: Typical Method Settings for Natural Gas Analyzers

D Appendix D: Carrier Gas Type Configuration

Procedure to Change the Carrier Gas Type 32

E Appendix E: Method for CP-Molsieve 5A Channel with Carrier Gas Argon

Agilent 490 Micro GC Natural Gas Analyzer

User Manual

Agilent Technologies

Agilent 490 Micro GC - Natural Gas

Analyzers

Introduction

Natural gas is a fossil fuel. Millions of years ago, the remains of

plants, animals, and micro-organisms were buried underneath

layers of soil and sediment. Due to the weight of the soil and

sediment, the pressure and temperature increased. This

resulted in the slow transformation of the organisms into

natural gas and oil.

The composition of natural gas varies widely. Natural gas is a

combustible mixture of hydrocarbon gases that mainly consists

of methane, smaller amounts of light hydrocarbons such as

ethane, propane, n-butane, n-pentane, hexanes plus, and other

gases such as nitrogen, carbon dioxide, oxygen, hydrogen, and

hydrogen sulfide. Natural gas can also contain traces of argon,

helium, neon, and xenon. Natural gas in its pure form is

colorless and odorless.

Natural Gas Analyzers have been designed to analyze the

different compositions of natural gas.

Types of Agilent 490 Micro GC - Natural Gas Analyzers

The following four types of Natural Gas Analyzers can be used

to analyze natural gas:

•The Agilent 490 Micro GC - Natural Gas Analyzer A

•The Agilent 490 Micro GC - Natural Gas Analyzer A Extended

•The Agilent 490 Micro GC - Natural Gas Analyzer B

•The Agilent 490 Micro GC - Natural Gas Analyzer B Extended

Agilent 490 Micro GC - Natural Gas Analyzers 1

Natural Gas Analyzers 6

Agilent 490 Micro GC - Natural Gas Analyzer A and the Extended Version

Natural Gas Analyzer A

The Agilent 490 Micro GC - Natural Gas Analyzer A is used to

analyze natural gas samples containing methane, carbon

dioxide, and hydrocarbons up to n-nonane.

The Agilent 490 Micro GC - Natural Gas Analyzer A is a dual

cabinet micro GC equipped with two channels:

•HayeSep A channel (straight)

•6 meter CP-Sil 5 CB channel

Natural Gas Analyzer A Extended

The Agilent 490 Micro GC - Natural Gas Analyzer A Extended is

used to analyze methane, carbon dioxide, and hydrocarbons up

to n-dodecane.

The Agilent 490 Micro GC - Natural Gas A Extended is a quad

cabinet micro GC equipped with three channels:

•HayeSep A channel with a backflush option

•4 meter CP-Sil 5 CB channel with a backflush option

•8 meter CP-Sil 5 CB channel

Agilent 490 Micro GC - Natural Gas Analyzers 1

Natural Gas Analyzers 7

Agilent 490 Micro GC - Natural Gas Analyzer B and the Extended Version

Natural Gas Analyzer B

The Agilent 490 Micro GC - Natural Gas Analyzer B is used to

analyze methane, carbon dioxide, hydrogen sulfide, and light

hydrocarbons up to n-nonane in natural gas.

The Agilent 490 Micro GC - Natural Gas Analyzer B is a dual

cabinet micro GC equipped with two channels:

•PoraPLOT U channel with a backflush option

•6 meter CP-Sil 5 CB channel

Natural Gas Analyzer B Extended

The Agilent 490 Micro GC - Natural Gas Analyzer B Extended is

used to analyze hydrogen, nitrogen, oxygen, methane, carbon

dioxide, carbon monoxide, hydrogen sulfide, and hydrocarbons

up to n-nonane.

The Agilent 490 Micro GC - Natural Gas Analyzer B Extended is

a quad cabinet micro GC equipped with three channels:

•CP-Molsieve 5A channel with a backflush option

•PoraPLOT U channel with a backflush option

•6 meter CP-Sil 5 CB channel

The Natural Gas Analyzer B Extended version is equipped with

a dual carrier gas option for the CP-Molsieve 5A channel. It is

made flexible for analysis of hydrogen and helium on the

CP-Molsieve 5A channel if required. For the analysis of helium

on the CP-Molsieve 5A channel, the carrier gas must be argon.

All analyzers are factory tuned on carrier gas helium.

Before starting up the Agilent 490 Micro GC - Natural Gas

Analyzer, ensure that correct carrier gases are connected for all

channels. For all types of analyzers, the required carrier gas is

helium. However, to analyze helium on the CP-Molsieve 5A, the

carrier gas must be argon. The required pressure for carrier gas

is 550 kPa (80 psi). For more information on the Agilent 490

Micro GC, see the Agilent 490 Micro GC User Manual.

Agilent 490 Micro GC Natural Gas Analyzer

User Manual

Agilent Technologies

Checkout Information

Introduction

The Agilent 490 Micro GC - Natural Gas Analyzers are factory

tuned on carrier gas helium including appropriate settings for

back flush times for the following channels:

•HayeSep A

•4 meter CP-Sil 5 CB

•CP-Molsieve 5A

•PoraPLOT U

The final checkout of the Agilent 490 Micro GC - Natural Gas

Analyzer is performed with a NGA Gas Calibration standard

and a Universal Gas Calibration standard.

•The NGA Gas Calibration standard contains nitrogen,

methane, ethane, carbon dioxide, propane, iso-butane,

n-butane, iso-pentane, n-pentane, and n-hexane. This natural

gas standard does not contain all components specified for

each type of Natural Gas Analyzer. Therefore, a second

checkout sample, the Universal Gas Calibration standard is

analyzed on the Natural Gas Analyzer.

•The Universal Gas Calibration standard contains helium,

neon, hydrogen, oxygen, nitrogen, methane, ethane, ethylene,

carbon dioxide, carbon monoxide, acetylene, propane,

methyl acetylene, n-butane, n-hexane, and n-heptane. Not all

components in the Universal Gas Calibration standard are

specified for the Natural Gas Analyzer.

Checkout Information 2

Natural Gas Analyzers 9

More detailed information about the NGA Gas Calibration

standard and the Universal Gas Calibration standard can be

found in Appendix Aon page 27 and Appendix Bon page 28.

The components specified for each channel are described in

“Agilent 490 Micro GC - Natural Gas Analyzer A and the

Extended Version” on page 6 and “Agilent 490 Micro GC -

Natural Gas Analyzer B and the Extended Version” on page 7.

The NGA Gas Calibration standard and the Universal Gas

Calibration standard are shipped with the analyzer and used by

the Agilent Customer Engineer at installation. The factory

tuned method, final chromatogram (Test Report), and the

Natural Gas Analyzer User Manual are supplied on the Analyzer

CD.

To perform reference checks on the analyzer, use the NGA Gas

Calibration standard or the Universal Gas Calibration standard.

If OpenLAB CDS EZChrom is used, load the method from the

analyzer CD or create a method using the settings from the

method pdf-file available on the analyzer CD. For a quick start,

see the method settings for Natural Gas Analyzers listed in

Appendix Con page 29. Connect and inject the NGA Gas

Calibration standard.

To analyze helium on the CP-Molsieve 5A channel, use the

Universal Gas Calibration standard for the checkout. Ensure

that the carrier gas argon is supplied and configured before

starting the analysis. For more information on how to configure

the carrier gas for the analyzer see Appendix Don page 31.

Method settings for this analysis can be found in Appendix Eon

page 35.

The NGA Gas Calibration standard and the Universal Gas

Calibration standard do not contain hydrogen sulfide. A

reference chromatogram of hydrogen sulfide is included in this

manual.

Checkout Information 2

Natural Gas Analyzers 10

Natural Gas Analyzer A and the A Extended Version

HayeSep A straight

The HayeSep A channel of the Natural Gas Analyzer A is

specified for the analysis of methane, carbon dioxide, ethane,

and propane.

Analysis of the NGA Gas Calibration standard results in the

chromatogram shown in Figure 1.

Analysis of the Universal Gas Calibration standard results in a

chromatogram similar to Figure 2

Figure 1 NGA Gas Calibration standard analyzed with the HayeSep A channel on Analyzer A

Seconds

010 20 30 40 50 60 70 80 90 100

100

150

200

250

300

Nitrogen

Methane

Carbon Dioxide

Ethane

Propane

Figure 2 Universal Gas Calibration standard analyzed with the HayeSep A channel on Analyzer A

Seconds

010 20 30 40 50 60 70 80 90 100

Carbon Dioxide

Ethylene

Ethane

Acetylene

Propane

Nitrogen

Methane

Andere Handbücher für 490 Micro GC

Inhaltsverzeichnis

Andere Agilent Technologies Messgerät Handbücher

Agilent Technologies

Agilent Technologies 8753ES Bedienungsanleitung

Agilent Technologies

Agilent Technologies E8362C Installations- und Betriebshandbuch

Agilent Technologies

Agilent Technologies 16700 SERIES LOGIC ANALYSIS SYSTEM 16700 Bedienungs- und Sicherheitshinweise

Agilent Technologies

Agilent Technologies HP 16500B Service-Handbuch

Agilent Technologies

Agilent Technologies Twelfth 4287A RF LCR Bedienungsanleitung

Agilent Technologies

Agilent Technologies 4349B Bedienungsanleitung

Agilent Technologies

Agilent Technologies N9039A Bedienungsanleitung

Agilent Technologies

Agilent Technologies PNA Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies 2100 Bioanalyzer System Betriebsanleitung

Agilent Technologies

Agilent Technologies J3919A Bedienungsanleitung

Agilent Technologies

Agilent Technologies 1146B Bedienungsanleitung

Agilent Technologies

Agilent Technologies 89410A Bedienungsanleitung

Agilent Technologies

Agilent Technologies E5071C Bedienungsanleitung

Agilent Technologies

Agilent Technologies u8903a Bedienungsanleitung

Agilent Technologies

Agilent Technologies 89604 Bedienungsanleitung

Agilent Technologies

Agilent Technologies Agilent 4396B Bedienungsanleitung

Agilent Technologies

Agilent Technologies E8363BU-014 Installations- und Betriebshandbuch

Agilent Technologies

Agilent Technologies ESA-E Series Handbuch

Agilent Technologies

Agilent Technologies E4411-60019 Installations- und Betriebshandbuch

Agilent Technologies

Agilent Technologies N5230C Bedienungsanleitung

Agilent Technologies

Agilent Technologies PNA Series Installations- und Betriebshandbuch

Agilent Technologies

Agilent Technologies E8362A PNA Series Kurzanleitung

Agilent Technologies

Agilent Technologies 4291B Bedienungsanleitung

Agilent Technologies

Agilent Technologies 4339B Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
