AJAX FireProtect Bedienungsanleitung
Updated April 22, 2021
FireProtect (FireProtect Plus) is a wireless indoor fire detector with an in-built
buzzer and a battery, ensuring up to 4 years of autonomous operation.
FireProtect can detect smoke and rapid temperature increase.
Aside from these functions, FireProtect Plus additionally can alert of dangerous
CO level. Both detectors can function independently from the hub.
Connecting to the Ajax security system via a secured radio protocol,
FireProtect (FireProtect Plus) communicates with the at a distance of up to
1,300 m in line of sight.
The detector can be a part of third-party security systems, connecting to them
via the or integration module.
The detector is set up via the for iOS, Android, macOS, and Windows.
The system notifies the user of all events through push notifications, SMS, and
calls
(
if activated
)
.
The Ajax security system can be connected to a central monitoring station of a
security company.
When smoke penetrates the detector chamber, it distorts infrared light between
the emitter and photoelectric receiver. This distortion triggers a smoke alarm.
When the temperature exceeds 60°Сor rises by 30°Сduring 30 minutes (not
necessary to reach 60°С), the detector registers temperature increase, which
triggers a fire alarm.
1. Siren hole
2. Light indicator (acts as the sensor and Test button)
3. Smoke chamber hole with the temperature detector behind the net
4. SmartBracket attachment panel
5. Power button
6. Tamper button
7. QR code
The life span of the FireProtect Plus detector lasts up to 7 years (up to 10 years for the
). In the event of a detector failure, you will receive a corresponding
notification — it will need to be replaced or submitted for .
FireProtect Plus has an additional sensor to detect a dangerous CO level. If the
concentration of CO in the air exceeds a certain level, the detector generates an
alarm.
The detector is triggered:
In case of alarm, the detector activates the built-in buzzer (the siren sound can
be heard from afar) and blinks with the light indicator. When connected to a
security system, both the user and the security company are notified of the
alarm.
The siren of the device can be turned off using three ways:
within 60–90 min at carbon oxide concentration 50 ppm / 0.005%
within 10–40 min at CO concentration 100 ppm / 0.01%
within 3 min at carbon oxide concentration 300 ppm / 0.03%.
1. By pressing the Ajax logo on the device lid (there is a touch button under the
logo).
2. Through the Ajax app. In case of fire alarm, you will see a pop-up message in
Please note that for this to work you need to priorly select Mute Interconnected
Fire Alarmcommand for this button in the KeyPad settings.
If smoke and/or temperature levels do not restore to normal values, in 10
minutes, the FireProtect/FireProtect Plus turns on the siren again.
3. Using the (if Interconnected FireProtect Alarms feature is enabled).
To turn off the built-in sirens in case of fire alarm, press the “*” button on the
KeyPad.
Before starting connection:
Only users with administrator rights can add the device to the hub
Pairing the detector with hub:
1. Following the hub user guide, install the . Create the account, add
the hub, and create at least one room.
2. Switch on the hub and check the internet connection (via Ethernet cable
and/or GSM network).
3. Make sure that the hub is disarmed and does not update by checking its
status in the Ajax app.
1. Select Add Device in the Ajax app.
2. Name the device, scan or type the QR Code (located on the detector body
and packaging), and select the location room.
3. Tap Add — the countdown will start.
To make sure that the detector is on, press the on/off button — the logo will light
up red for a second.
For detection and pairing to occur, the detector should be located within the
coverage area of the wireless network of the hub (at a single protected object).
The connection request is transmitted for a short time: at the moment of
switching on the device.
If pairing with the hub fails, the detector operates autonomously; switch off the
detector for 5 seconds and retry.
The detector connected to the hub is displayed in the list of devices in the app.
The update of the detector status in the list depends on the device inquiry time
set in the hub settings (the default value is 36 seconds).
To connect the detector to a third party security central unit using the
or integration module, follow the
recommendations in the manual of the respective device.
The smoke detector always operates in the active mode. When connecting
FireProtect to third party security systems, it is appropriate to place it in a
permanently active protection zone.
Parameter State
Temperature Temperature of the device. Measures on the
device processor and changes gradually
Jeweller Signal Strength Signal strength between the hub and the
detector
Connection Connection status between the hub and the
device
Battery Charge
Battery level of the device. Two states available:
Lid The tamper state of the device — reacts to the
detachment
ReX Displays the status of using the ReX range
extender
Smoke Shows if smoke is detected
Temperature Threshold Exceeded The state of temperature threshold exceeded
alarm
Rapid Temperature Rise The state of rapid temperature increase alarm
High CO Level (FireProtect Plus only) The state of dangerous CO level alarm
Backup Battery Charge Backup battery level of the device
Smoke sensor The state of the smoke detector
Smoke Sensor Dust Level The dust level in the smoke chamber
Temporary Deactivation
Shows the status of the device: active,
completely disabled by the user, or only
notifications about triggering of the device
tamper button are disabled
2. FireProtect | FireProtect Plus
ОК
Battery discharged
Setting Value
First field Device name, can be edited
Room Selecting the virtual room to which the device is
assigned
Dangerous CO Level Alarm (FireProtect Plus
only)
If active, the detector alerts of exceeding the
limits of carbon monoxide concentration
High Temperature Alarm If active, the detector reacts when the
temperature is 60°C and higher
Rapid Temperature Rise Alarm
If active, the detector reacts to rapid
temperature increase (30°Сfor 30 minutes or
less)
Alert with a siren if smoke is detected If active, added to the systemare
activated in case of smoke alarm
Alert with a siren if temperature threshold
exceeded
If active, added to the systemare
activated in case if temperature threshold
exceeded
Alert with a siren if rapid temperature rise
detected
If active, added to the systemare
activated in case if rapid temperature rise
detected
Alert with a siren if CO detected (FireProtect
Plus only)
If active, added to the systemare
activated in case if CO concentration is
dangerous
Jeweller Signal Strength Test Switches the device to the signal strength test
mode
FireProtect Self Test Starts FireProtect selftest
Allows the user to disconnect the device
1. Devices
2. FireProtect | FireProtect Plus
3. Settings
Temporary Deactivation
Note that a disabled device does not trigger an
interconnected alarm of fire detectors. But if
smoke is detected, the built-in siren will sound
User Guide Opens the detector User Guide
Unpair Device Deletes device and its settings
The function activates built-in sirens of all fire detectors if at least one of them is
triggered. Sirens are activated within the hub–detector ping interval according to
the Jeweller settings.
To enable Interconnected Alarms:
1. Open the Devices tab in the
2. Select a hub
3. Go to its Settings by pressing
4. Select the Service item
5. Go to the Fire detectors settings menu and activate the Interconnected
FireProtect Alarms option
Interconnected alarms are supported by FireProtect and FireProtect Plus detectors with
firmware versions 3.42 and later. Please note that when you turn on the interconnected
alarms, you cannot set the hub–detector ping interval (Jeweller settings) of more than 48
seconds.
Lid only— the system will ignore only
notifications about the triggering of the
device tamper button
minute.
The function works as follows:
1. One of the FireProtect/FireProtect Plus detectors detects an alarm.
2. Delay of Interconnected Alarms starts.
3. The built-in siren of the fire detector informs the alarm. Users receive
notifications in the Ajax app (if are enabled). At the
object, are activated (if the are enabled).
4. An alarm confirmation event is sent to the monitoring station and security
system users, and the system starts the interconnected alarm for fire detectors
if:
The interconnected alarm delay time has passed, and the triggered detector
is still registering an alarm.
