Ameriwood HOME 4942335COM Bedienungsanleitung

4942335COM

6 Drawer Dresser

B344942335COM0

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Date of Purchase ___ / ___ / ___

Lot Number:

Assembly Difficulty Meter

Easy Tough

WARNING: Manufacturer assumes no liability

for improper installation or excessive loads

placed on screws or bracket. This wall anchor

is not a substitute for proper adult supervision.

Keep your home and family safe

with the wall anchor kit that is

included with the product.

Serious or fatal crushing injuries can

occur from tipping furniture.

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 2 HOURS

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

Before You Start

Quick

Tip

Assembly

Please Note:

You may need to lightly tap the wood dowels to insert into the holes

during your assembly process.

wood dowel

Board Identification

Not actual size

Left Panel

34942335010

Right Panel

34942335020

Bottom

34942335050

Pattition

34942335030

Top

34942335040

Left Front Leg

34942335060

Left Upper Drawer Front

34942335100

Right Rear Leg

34942335090

Right Front Leg

34942335070 Left Rear Leg

34942335080

Right Upper Drawer Front

34942335110 Left Lower Drawer Front (x2)

34942335120

Right Lower Drawer Front (x2)

34942335130

Drawer Side (x12)

39991167346200C

DWR

BACK

DWR

SIDE

Drawer Back (x6)

39991167065490B Drawer Bottom (x6)

39991338066610D

DWR

BTM

Board Identification

Not actual size

Back Panel

K494200000

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

DWR

SIDE

DWR

SIDE

DWR

SIDE

DWR

SIDE

DWR

SIDE

DWR

SIDE

DWR

SIDE

DWR

SIDE

DWR

BACK

DWR

BACK

DWR

BACK

DWR

BACK

DWR

BTM

DWR

BTM

DWR

BTM

DWR

BTM

Part List

Actual Size

(x10)

#A22620

cam lock

(x10)

#A22610

cam bolt

(x18)

#A21660

wood dowel

(x60)

#A11080

#6 x 7/16" screw

(x12)

#A22910

connector bolt

(x74)

#A12120

#8 x 7/16" screw

(x12)

#A22920

connector

(x23)

#A21110

nail

(x12)

#A17400

8-32 x 7/8" truss

(x24)

#A21970

drive fastener

(x2)

#A23030

confirmat screw

Part List

Not Actual Size

Left Cabinet Member

Right Cabinet Member

Left Drawer Member

Right Drawer Member

(x6)

#A56750

drawer slide pkg.

14a

14b

14c

14d

(x1)

#A84050

safety bracket kit

(x12)

#A54520

drawer bracket

(x6)

#A51715

handle

(x1)

#A43105

plastic foot

(x3)

#A43490

spacer glide

(x6)

#A54900

drawer brace

12a

12b

12c

12d

15 16

STEP1

(x12)

#A22910

STEP2

(x2)

#A22620 (x2)

#A22610 (x6)

#A21660 (x6)

#A22920

You will need to tap the connector (9)

with a hammer to fully insert. Be sure

the connector is positioned as shown

before tapping into hole.

Proper orientation of CAM LOCK

Tip

Assembly

Quick
