Ameriwood HOME 5728872COM Bedienungsanleitung

B345728872COM00

Do Not Return This Product!

Contact our customer service team for help rst

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

–Unit can p over causing severe injury or death.

–Anchor unit to stud in wall (if instructed to)

–Do not allow children climb on unit

–Put heavy items on lower shelves or drawers

Remington Storage Cabinet

5728872COM

Date of Purchase: ____/____/_____

Lot Number:

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Easy Tough

Assembly Diculty Meter

Follow Ameriwood Home

042019PK

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team rst for help

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 30 MINUTES

Visit ameriwoodhome.com

Assembly Tips

ameriwoodhome.com

- Open your item in the area you plan to keep it for less heavy liing

- Idenfy, sort and count the parts before aempng assembly

- Compression dowels are tapped in with a hammer

- Slides are labeled with a R (right) and L (le) for proper placement

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge

- Use all the nails provided for the back panel and spread them out equally

- Back Panel must be used to make sure your unit is sturdy

- Do NOT use harsh chemicals or abrasive cleaners on this item

- Never push, pull, or drag your furniture

Before You Start

Cam Lock Fastening System

ameriwoodhome.com

This Cam Lock Fastening System will be usedthroughoutthe assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Cauon: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is ght.

Failure to do so may result in stripping the screw.

Quick

Tip

Assembly

Board Idencaon

Notactual size

ameriwoodhome.com

T5728872010PK

TOP PANEL

T5728872020PK

BOTTOM PANEL

T5728872030PK

LEFT SIDE PANEL

T5728872040PK

RIGHT SIDE PANEL

T5728872050PK

DOOR

T5728872080PK

FRONT DRAWER

T5728872090PK

LEFT SIDE DRAWER

T5728872060PK

SHELF

T5728872070PK

BRACE

8 9

2 3

Board Idencaon

Notactual size

ameriwoodhome.com

T5728872100PK

RIGHT SIDE DRAWER

T5728872110PK

BACK DRAWER

T5728872120PK

BOTTOM DRAWER

T5728872130PK

DRAWER SUPPORT

T5728872140PK

BACK PANEL

11 12

Part List

Actual Size

ameriwoodhome.com

x11

TPK0001

Cam Bolt

x11

TPK0003

Cam Lock 15-9

x10

TPK0004

DOWEL 8 X 30

TPK0009

CBS 4 x 50

x16

TPK0010

SCREW PH 4 X 30

x20

TPK0015

NAIL

TPK0006

SHELF HOLDER

x38

TPK0007

CBS 3.5 x 16

TPK0008

CBS 4 x 38

TPK3005

HANDLE SCREW

Part List

NotActual Size

ameriwoodhome.com

TPK2002

LEG BRACKET

TPK2004

ANTI TIPPING KIT

TPK2001

WOODEN LEG

TPK3004

ACRYLIC HANDLE

TPK4001

DOOR HINGES

TPK1001

DRAWER SLIDE 300MM

ameriwoodhome.com

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Step 1

Properly insert Cam Lock and dowel.

TPK0003

TPK0004

TPK0001

ameriwoodhome.com

Step 2

Slide (CL), screw posion on panel number 3. Slide (CR), screw posion on panel number 4.

TPK1001

TPK0007

ameriwoodhome.com

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Step 3

TPK0003

TPK0004

TPK0001

TPK2004

Aach An-Tipping kit as shown. Do not fully ghten yet in this step.

Properly insert Cam Lock

and dowel.
