Ameriwood HOME 5997303WCOM Bedienungsanleitung

5997303WCOM

Nightstand

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B345997303WCOM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

0299

8659974 2

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.com

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

35997303010

RightPanel

35997303020

Top

35997303030

Bottom

35997303040

Shelf

35997303050

KickPanel

35997303060

BackPanel

K599730300

Thispieceisofpaperboard

construction.Itisnotmade

fromwood,butisrequired

fortheassemblyofyour

unit.

EFG

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

(x12)

#A22510

cam bolt

(x12)

#A22570

cam lock

(x4)

#A12105

7/16" pan screw

(x2)

#A53600

angle bracket

(x20)

#A21110

nail

(x6)

#A21660

wood dowel

7

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

(x2)

#A22570

*rawedgesareshaded

(x4)

#A22510

(x1)

#A21660

Screwfourcamboltsintotheleftpanel(A).

Inserttwocamlocksandawooddowelintotheleftpanel(A).

8

ameriwoodhome.com

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

*rawedgesareshaded

(x1)

#A21660

(x2)

#A22570

(x4)

#A22510

Screwfourcamboltsintotherightpanel(B).

Inserttwocamlocksandawooddowelintotherightpanel(B).

9

ameriwoodhome.com

STEP3

Tube

You

(x4)

#A22510

Screwfourcamboltsintothetop(C).

10

ameriwoodhome.com

STEP4

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

(x4)

#A22570

(x2)

#A21660

Insertfourcamlocksandtwowooddowelsintotheshelf(E).

*rawedgesareshaded
