Ameriwood HOME 5990196COM Bedienungsanleitung

B345990196COM

Do Not Return This Product!

Contact our customer service team for help rst

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

–Unit can p over causing severe injury or death.

–Anchor unit to stud in wall (if instructed to)

–Do not allow children climb on unit

–Put heavy items on lower shelves or drawers

Carver 4 Drawer Dresser

5990196COM

Date of Purchase: ____/____/_____

Lot Number:

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Easy Tough

Assembly Diculty Meter

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team rst for help

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 1 HOUR

Visit ameriwoodhome.com

Assembly Tips

ameriwoodhome.com

- Open your item in the area you plan to keep it for less heavy liing

- Idenfy, sort and count the parts before aempng assembly

- Compression dowels are tapped in with a hammer

- Slides are labeled with a R (right) and L (le) for proper placement

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge

- Use all the nails provided for the back panel and spread them out equally

- Back Panel must be used to make sure your unit is sturdy

- Do NOT use harsh chemicals or abrasive cleaners on this item

- Never push, pull, or drag your furniture

Before You Start

Cam Lock Fastening System

ameriwoodhome.com

This Cam Lock Fastening System will be usedthroughoutthe assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Cauon: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is ght.

Failure to do so may result in stripping the screw.

Quick

Tip

Asse

Board Idencaon

Notactual size

ameriwoodhome.com

T5990196010

TOP PANEL

T5990196020

LEFT SIDE PANEL

T5990196030

RIGHT SIDE PANEL

T5990196040

BOTTOM PANEL

T5990196050

TOP MOLDING

T5990196090

BACK DRAWER

2 3

T5990196060

LEFT DRAWER SIDE

T5990196070

RIGHT DRAWER SIDE

T5990196080

FRONT DRAWER

Board Idencaon

Notactual size

ameriwoodhome.com

T5990196110

SIDE RAIL

T5990196120

LEG

T5990196100

DRAWER BOTTOM

T5990196130

FRONT & BACK RAIL

T5990196140

DRAWER SUPPORT

T5990196150

BACK PANEL

T5990196160

FRONT SUPPORT

T5990196170

BACK SUPPORT

16 17

Part List

Actual Size

ameriwoodhome.com

TUD0010

PH M4 X 18

x18

TUD0006

NAIL

x42

TUD0001

Cam Bolt

x27

TUD0009

CBS 4 x 38

x42

TUD0002

Cam Lock

15-12

x30

TUD0004

DOWEL 8 X 25

x76

TUD0008

CBS 3.5 x 16

TUD0020

L-BRACKET

Hardware Bag Reference Number:

25990196COM0

Part List

NotActual Size

ameriwoodhome.com

x1 set

TUD0021

ANTI TIPPING KIT

x4 SET

TUD0016

DRAWER SLIDE 12”

TUD0012

HANDLE

TUD0014

STOPPER 35MM

Hardware Bag Reference Number:

25990196COM0

ameriwoodhome.com

* raw edges are shaded

Step 1

TUD0001

Insert Cam Bolt and fully ghten it.

ameriwoodhome.com

* raw edges are shaded

Step 2

TUD0009

TUD0021

Fix top molding to the top panel. Fix an - pping kit,

do not fully  ghten in this step

ameriwoodhome.com

* raw edges are shaded

Step 3

TUD0001

Insert Cam Bolt and fully ghten it.
