Ameriwood HOME 9100222COM Bedienungsanleitung

9100222COM

5DrawerDresser

B349100222COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:2

ESTIMATEDASSEMBLYTIME:1HOUR

3

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

BeforeYouStart

Quick

Tip

Assembly

5

BoardIdentification

Notactualsize

LeftPanel

39100222010

RightPanel

39100222020

Top

39100222030

Bottom

39100222040

DrawerBack(x5)

39991167067890B

DrawerBottom(x5)

39991341068910D

Support(x4)

39100222060 DrawerFront(x5)

39100222080

DrawerSide(x10)

39991167346200C

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

BackPanel

K910000000

DWR

SIDE

DWR

BACK

DWR

BTM

6

BoardIdentification

Notactualsize

DWR

BACK

DWR

BTM

DWR

SIDE

DWR

SIDE

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

7

PartList

ActualSize

(x12)

#A22610

cambolt

(x12)

#A22620

camlock

(x12)

#A21670

wooddowel

(x4)

#A23030

confirmatscrew

(x50)

#A11080

7/16"flatheadscrew

(x50)

#A12120

7/16"round

headscrew

(x10)

#A52365

knob

(x10)

#A17400

7/8"bolt

(x20)

#A21970

drivefastener

(x12)

#A12420

5/8"round

headscrew

123

(x40)

#A21110

nail

Note: Your model may

contain extra hardware.

8

PartList

NotActualSize

(x10)

#A54520

drawerbracket

(x4)

#A54800

footbracket

(x4)

#A44320

foot (x5)

drawerslidekit

#A56770

rightdrawermember

leftdrawermember

rightcabinetmember

leftcabinetmember

12a

12b

12c

12d

(x1)

#A84050

Safety Bracket Kit

16d

16c

16b

16a

(x5)

#A54900

drawerbrace

9

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x4)

#A22610

1235

(x2)

#A22620

(x2)

#A21670

(x15)

#A11080

(x5)

#A56770

leftcabinetmember

Markedwitha"L"

16a

10

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

12 3 5

(x4)

#A22610

(x2)

#A22620

(x2)

#A21670

(x15)

#A11080

(x5)

#A56770

rightcabinetmember

Markedwitha"R"

16b
