Network Master Pro/Flex Release Notes

1 TAA-1ETNMX0054-20

2016-9-14

Anritsu Corporation

Network Master Pro/Flex Release Notes

Product Configuration

The following table shows the relationship between the changed application and modules described in the

Revision History.

Mainframe

Module

Changed Application

MT1100A/MT1000A

Common

―

[Framework][Remote]

MT1100A

MU110010A

MU110011A

MU110012A

MU100013A

[ETH][OTN][CPRI][FC][SDH/SONET][SDHPDH]

MT1000A

MU100010A

MU100090A

MU100020A

MU100021A

MU100022A

[OTDR][FTTA][OLTS]

MU100040A

[CPRI-RF]

Network Master Pro/Flex Release Notes

2 TAA-1ETNMX0054-20

Latest Installer File Name

MT1000A

MT1100A *1

7.00.MT1000A_SW

MX100001A-Setup-7.00-xxxxx.exe

MX100003A-1.0.0.76-xxxxx.exe

6.02.MT1100A_SW

MX100001A-Setup-6.02-xxxxx.exe *2

MX100003A-1.0.0.76-xxxxx.exe

*1) MT1100Ahas no change since the last release.

*2) When the versions of MT1000Aand MX100001A do not match, it does not work properly.

The following table shows the latest software and corresponding operation manuals.

Operation Manual

Doc. No.

MT1000A

MT1100A

MT1000A Network Master Pro

MT1100A Network Master Flex

Remote Scripting Operation Manual

M-W3736AE

11th

10th

MT1000A MU100010A Network Master Pro

Operation Manual

M-W3682AE

12th

10th

MT1000A MU100020A/MU100021A/MU100020A Network

Master Pro

Operation Manual

M-W3810AE

5rd

－

MX100003A MT1000A/MT1100A Scenario Edit

Environment Kit Operation Manual

M-W3858AE

3rd

2nd

MT1000A MU100040A Network Master Pro Operation

Manual

10580-00423

－

Network Master Pro/Flex Release Notes

3 TAA-1ETNMX0054-20

Installation Procedure

1. When using battery, make sure that there is 40% (or more) power in the battery of the instrument.

2. Remove the USB memory from the MT1000A/MT1100A.

3. Press the power button to shut down the MT1000A/MT1100A. Never force to power off by holding the

power button pressed for several seconds.

4. Remove the AC adapter or cable and see the power button turns to gray.

5. Copy installer (X.XX.MT1000_SW or X.XX.MT1100_SW) onto an empty USB memory stick.

6. Insert USB memory stick into MT1000A/MT1100A.

7. Boot MT1000A/MT1100Ato start installer.

The instrument will detect the USB stick, and start installing the software. After the installation has

finished the instrument will reboot and start with the new software.

8. Remove USB stick after installation is complete

You can check the installed version at System Information screen.

Network Master Pro/Flex Release Notes

4 TAA-1ETNMX0054-20

Installation Procedure via network.

1. When using battery, make sure that there is 40% (or more) power in the battery of the instrument.

2. Install the Control Software(MX100001A) on your PC.

(Please refer “3.5.1 Installation of Control Software” on MT1000A MU100010A Network Master Pro

Operation Manual or MT1100ANetwork Master Flex Operation Manual.)

3. Configure the Ethernet communication between the Control Software(MX100001A) and

MT1000A/MT1100A. (Please refer “3.5.2 Connection and Setup” on MT1000AMU100010A Network

Master Pro Operation Manual or MT1100ANetwork Master Flex Operation Manual.)Select the

update tab on Control Software to show the upgrading box.

4. Touch Select File to launch the dialog box.

5. Select the software file. Progress bar shows Upload Progress. Touching Cancel aborts the file

uploading.

6. After file uploading finishes, touch Start Installation.

Touching Start Installation will reboot the Network Master. Installation process cannot be remotely

monitored. Please reconnect after few minutes.

Network Master Pro/Flex Release Notes

5 TAA-1ETNMX0054-20

Revision History

Version

Date

Description

7.00

2016-09-14

KeyAdded Features

[New HW] Added New OTDR Module (MU100022A: 3wl.

1310/1550/1625nm model).

[OTDR]Added Construction function.

[OTDR]Added Bi directional mode.

[New HW] Added CPRI RF Module.

[Framework] Supports simultaneous installation of three module

types.

Fixed bugs

[Framework] Fixed bug in GPS utility preventing monitoring of

GPS signal receive status.(9172)

[Framework] Fixed bug in File Explorer causing main frame to

restart when erasing file.(9099)

[Framework] Fixed bug preventing display by laser emitting

indicator during measurement when Standard OTDR

application started after VIP started.(9144)

[ETH] Fixed bug causing incorrect Frame Loss rate calculation

when Total Repeat Steps set to ON at RFC2544 test.(6445)

[ETH] Fixed bug in Sync Test application preventing input of

negative value as one-way Delay Threshold value.(9235)

[FC] Fixed bug causing incorrect display of Frame Loss

Seconds and Pattern Loss Seconds even when Frame Loss

Seconds set to Ignore at BERT application.(9173)

[OTDR] Fixed bug preventing execution of Standard OTDR

Mission Control Power Meter Offset Zero function. (9217)

[OTDR] Fixed bug causing main frame to restart when opening

OTDR results file with Result File Browser when no OTDR

module installed in main frame. (8836)

[OTDR] Fixed bug in OTDR application preventing display of

Fiber Visualizer screen waveform window when far end not

found. (8806)

[OTDR] Fixed bug causing VFL to light for several seconds

when application quit and then restarted while VFL in ON

status. (8968)

6.02

2016-08-15

KeyAdded Features

[ETH] Changed specification for PRBS Sync Alarm and PRBS

Network Master Pro/Flex Release Notes

6 TAA-1ETNMX0054-20

Version

Date

Description

Pattern Error detection immediately after measurement start at

BER measurement using Ethernet BER application Cross

PRBS pattern (9130)

[OTN][SDH] Added measurement ON/OFF setting for following

items: (9062)

OTN: PLM

SDH/SONE: HP=PLM, LP-PLM, Threshold Alarm

[SDH]Added Generic-AIS detection function (8555)

Fixed bugs

[OTDR] Fixed bug in v6.00 causing display of "Include

Performance Verification data" checkmark at report generation

screen for results not actually displayed (9141)

6.01

2016-07-14

Fixed bugs

[ETH][OTN] Fixed bug preventing correct CFP Module

Transceiver setting and causing error when using V6.00

software with MU110011A CFP Interface (9116)

[FC] Fixed bug causing periodic Frame Loss when sending

FC1200 Frame signal (7877)

[OTN] Fixed bug in V5.01 and later software causing doubling of

output clock frequency when selecting any one of OTU1f/2f/2e

bit rates when using Tx Reference Clock Output with

MU110010A (9084)

[FTTA] Fixed bug causing disabled software key when moving

to TRACE tab at TTA application after starting measurement

(9138)

6.00

2016-06-23

KeyAdded Features

[New HW] Added MU110013Amodule and dedicated option

[Framework] Added autosave function for MT1100A CFP/CPF2

Interface transceiver settings (8568)

[ETH]Added following settings to Traffic Tx function

・Burst Tx Setting

・Frame Length Increment Tx

・Tx Rate Inter-Frame Gap Specification

・Tx Rate Millisecond Unit Lamp Tx Setting

・Tx Rate over 100% stream Setting

[ETH] Added Cross PRBS pattern setting to Payload patterns

for BERTApplication

Network Master Pro/Flex Release Notes

7 TAA-1ETNMX0054-20

Version

Date

Description

[ETH] Added function for automatically allocating IPv6 Tx

source address using RS/RAfunction

[OTDR] Added function for SCPI Remote command control to

OTDR application

Fixed bugs

[Framework] Fixed bug causing restart of mainframe when

inputting "e" character while file load/save dialog displayed

(8873)

[Framework] Fixed bug causing license error display when

loading settings file saved by MT1000A+MU100010A

configuration at MT1000A+MU1000xxA+MU100010A

configuration and corrected notification to comment on

configuration difference (8633)

[ETH] Fixed bug causing non-stop sending at Pause Frame

receiving even when Auto Negotiation set to off for

10/100/1000M electrical interface and "Respond to Pause

Frame" set (8643)

[ETH] Fixed bug causing output of all selection items when

outputting test results to CSV or XML file using Channel

Statistics application (8523)

[ETH] Fixed bug causing inclusion of MPLS label value in

Address Filter Stream ID conditions using Mon/Gen application

(8543)

[ETH] Fixed bug causing Skew value to be displayed as

">0.000" and incorrect measurement when selecting any

Interval result at "Relative Skew" results display of Result

screen (8838)

[ETH] Fixed bug preventing correct display of result table

service details at measurement results for Y1564 (8527)

[FC] Fixed bug causing monitoring of Frame Loss seconds even

when "ignore Frame Loss seconds for BERT measurement

results" set at BERT application (8730)

[PTP] Fixed bug causing locking for only up to 4 hours when

executing continuous measurements for 5 or more hours in

locking state using GPS utility. Currently possible to lock for 24

hours by changing setting (8548)

[OTDR] Fixed bug sometimes causing error in Reflectance analysis

Network Master Pro/Flex Release Notes

8 TAA-1ETNMX0054-20

Version

Date

Description

results when Auto Mode Test set to Advanced (8933)

5.04

5.03

2016-05-23

KeyAdded Features

[Framework] Added the One-Button Test..

Fixed bugs

[Framework] Fixed bug causing the unavailable access to USB

stick after the specific procedure on V5.01.(8826)

[Framework] Fixed bug causing main unit to restart when USB

memory stick removed while File Manager focused on

sub-folder in inserted USB memory.(8733)

[ETH] Fixed bug causing the application crashes when outputting

report of Ethernet RFC 2544 ”End to end network test” results

(8614)

5.01

2016-03-25

KeyAdded Features

[Framework] Added to fiberscope with 60 degrees tip (7961)

[OTDR] Expanded maximum settable pulse width for each

distance range (8044)

[OTDR] Changed dummy fiber (launch spool) display color to

clearly show the start of the fiber under test. (8045)

[ETH]Added auto MAC address resolution function when a

generating IPv6 Stream (NDP NS/NA) (7712)

[ETH]Added possibility to ignore Frame loss seconds count in

Ethernet BERT application (8057)

[ETH] In SyncTest application, added calibration parameter for

GPS antenna cable length. (8026)

[ETH] In SyncTest application, added high-resolution frequency

counter function (7945)

[OTN]Added LOS insertion function (7366)

[OTN] Added following APS trigger items (7775)

OTU3x/4: FAS-OTL, LOF-OTL, OOF-OTL, LOR-OTL, OOR-OTL,

OTU1x/2x/3x/4: OTU-AIS, OOM

[SDH]Added possibility to disable the display of Pointer

Movement measurements (7905)

Fixed bugs

[Framework] Fixed bug when disabling WLAN sometimes

causing instrument to temporarily freeze (8272)

[Framework] Fixed bug causing the NWM Flex with battery

option MU11001A from fully shutting down.(8391)

Network Master Pro/Flex Release Notes

9 TAA-1ETNMX0054-20

Version

Date

Description

[Framework] Fixed the problem that MU100090Apower On/Off

status isn’t stored properly occasionally. (8273)

[OTDR] Fixed bug that "Restore Default" operation does not

work after creating OTDR report.(8448)

[ETH] Fixed bug for 10GbE sometimes causing transmitter to

insert wrong IFG (7673)

[ETH] Fixed bug in IEEE1588 function sometimes causing UDP

checksum errors in transmitted PTP frames (7835)

[OTN] Fixed problem when starting applications with +OTN

option sometimes causing invalid option warning message

(7683)

[OTN][ETH] Fixed bug in Ethernet transmitter causing BER

alarm when Ethernet mapped over OTN using GFP-F.

(7519)(8075)

[OTN][ETH] Fixed bug causing BER alarms for MPLS mapped over

OTN using 46 byte frame size. (7844)

5.00

2016-02-19

KeyAdded Features

Added MU100090A Module

[ETH] Added IEEE1588 Time error measurement function.

(7892)

[ETH] Added ITU-T8275.1 profile for IEEE1588 functions

(7992)

[CPRI] Added APS measurement function to BERT application

(7099)

[Framework] Expanded MDIO Analysis functions for

CFP/CFP2/CFP4. (7976)

[OTN] Added mappings for packet based client signal.

(7975,7977,7978)

[OTN][SDH] Added BERT/APS/RTD switch mode to BERT

application (7980)

[OTN][SDH] Added SDH Transparent mapping for SDH over

OTN start (7981)

[Remote] Added support for VNC control via HTTP with JAVA

1.8 (6353)

[Remote] Added support for simultaneous SCPI and Remote

GUI control (7681)

[Remote][ETH] Added remote command for specifying save

Network Master Pro/Flex Release Notes

10 TAA-1ETNMX0054-20

Version

Date

Description

destination for IEEE1588/SyncE Frame capture data (8198)

- ETH:PORT1:PTP:FCAP:DIR

[Remote][ETH] Added following remote commands for

performing IEEE1588 ARP analysis and querying analysis

results (8157)

- ETHernet:PORT<Pt>:PTP:MAC:ARP

- ETHernet:PORT<Pt>:PTP:MAC:ARP:RESult?

Fixed bugs

[OTDR] Upgraded Event (fault point) detection (search)

accuracy (8034)

[Framework] Fixed problem causing Chinese and Japanese

UTF-8 encoded CSV reports to display garbage characters

when opened in MS-Excel. (7750)

Japanese: UTF-8 to Shift JIS

Chinese: UTF-8 to GB2312

[Framework] Fixed bug preventing re-acquisition of IP address

when switching WLAN access point (7360)

[Framework] Simplified Password dialog and fixed problem

when initially enabling system password protection requiring

user to know old (default) password. (7551)

[Framework] Fixed bug causing sudden shutdown when starting

with remaining battery charge of ≤6% (7662)

[ETH] Fixed bug only permitting insertion of less than assumed

block errors when inserting errors while testing at Frame rates

of >2000 bytes when testing at interface of10/40/100 Gbps

(7020)

[ETH] Fixed bug causing Frame loss when receiving IPv4 +

UDP header Ethernet Frame when Frame length not multiple of

8 bytes at 40/100GbE (7836)

[ETH] Fixed bug ristricting the minimum payload size of 38-byte

when selecting custom header at BERT application stream

setting (7725)

[ETH] Fixed bug causing [Timing: Bit rate Difference] to remain

unchanged at 0 even when clearing History at Ethernet test

(6884)

[ETH] Fixed bug causing IEEE15888 status Wall Clock Current

time affects from local MT1000A time setting (7850)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Anritsu Prüfgeräte Handbücher

Anritsu

Anritsu MS8911A Bedienungsanleitung

Anritsu

Anritsu MS8608A Bedienungsanleitung

Anritsu

Anritsu Site Master S113C Bedienungsanleitung

Anritsu

Anritsu MD1230B-26 Bedienungsanleitung

Anritsu

Anritsu Site Master S112 Bedienungsanleitung

Anritsu

Anritsu MT8850A Bedienungsanleitung

Anritsu

Anritsu OSL Series Gebrauchs- und Pflegehandbuch

Anritsu

Anritsu ME7840A Bedienungsanleitung

Anritsu

Anritsu Site Master S330A Bedienungsanleitung

Anritsu

Anritsu MT8860B Betriebsanleitung

Anritsu

Anritsu MG3681A Bedienungsanleitung

Anritsu

Anritsu MT8870A Bedienungsanleitung

Anritsu

Anritsu Precision AutoCal 36585 Series Bedienungsanleitung

Anritsu

Anritsu SQA-R MP1900A Referenzhandbuch

Anritsu

Anritsu MP1590B Bedienungsanleitung

Anritsu

Anritsu Precision AutoCal 36585 Series Bedienungsanleitung

Anritsu

Anritsu MG369 A Series Bedienungsanleitung

Anritsu

Anritsu Site Master S113B Bedienungsanleitung

Anritsu

Anritsu MX900030A Bedienungsanleitung

Anritsu

Anritsu MT9810B Bedienungsanleitung

Anritsu

Anritsu MT1000A Network Master Pro Bedienungsanleitung

Anritsu

Anritsu MN469xC Series Bedienungsanleitung

Anritsu

Anritsu MT8852B Bedienungsanleitung

Anritsu

Anritsu InterferenceHunter MA2700A Bedienungsanleitung

Beliebte Prüfgeräte Handbücher anderer Marken

SMART

SMART KANAAD SBT XTREME 3G Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies BERT Serial Bedienungsanleitung

Agilent Technologies

Agilent Technologies N3280A Bedienungsanleitung

Vernier

Vernier Go Direct Voltage Bedienungsanleitung

Lifeloc

Lifeloc R.A.D.A.R. Bedienungsanleitung

Fluke

Fluke T5-600 Bedienungs- und Montageanleitung

Mercury

Mercury TSL01 Bedienungsanleitung

MAHA

MAHA MBT Series Bedienungsanleitung

Fuji Electric

Fuji Electric P-61 Bedienungsanleitung

ETC

ETC SealerAtor Bedienungsanleitung

Skyfine

Skyfine ETHYWAY V2 Bedienungsanleitung

Appion

Appion G5 Twin Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 8159-0112A Bedienungsanleitung

BW Technologies

BW Technologies MicroDock II Bedienungsanleitung

Sun Nuclear

Sun Nuclear 1027 Bedienungsanleitung

Biomark

Biomark HPR LITE READER Bedienungsanleitung

Hioki

Hioki 3169-20 Bedienungsanleitung

Ashcroft

Ashcroft ATE-100 Bedienungsanleitung
