ARIESAUTOMOTIVE.COM •NEED ASSISTANCE? •8 7 7. 2 8 7. 8 6 3 4 •1110 315 -I NS- R A •PAGE 1

INSTALLATION MANUAL 1110315

Parts List

2Light mounting bracket

2Hex cap screw, M6

2Flat washer, M6

10 Set screw, M5

2Hex key, 2.5mm

1Hex key, 5mm

Maintenance

To protect the product, wax after installing. Regular waxing is recommended

to add a protective layer over the finish. Do not use any type of polish or wax

that may contain abrasives that could damage the finish.

Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive

cleaners, abrasive pads, wire brushes or other similar products that may damage the ﬁnish.

Product Photo

Torque Speciﬁcations

M5 bolt 1.8 ft-lbs.

M6 bolt 3 ft-lbs.

Use above torque setting unless otherwise noted

Level of Difﬁculty

Easy

NOTICE

Before you begin installation, read all instructions thoroughly.

Proper tools will improve the quality of installation and reduce the time required.

To help prevent damage to the product or vehicle, refer to the specified

torque specifications when securing hardware during the installation process.

Product Registration and Warranty

CURT Group stands behind our products with industry-leading warranties.

Provide feedback and help us to improve our products by registering your purchase at:

warranty.curtgroup.com/surveys

ARIESAUTOMOTIVE.COM •NEED ASSISTANCE? •8 7 7. 2 8 7. 8 6 3 4 •1110 315 -I NS- R A •PAGE 2

Step 1

Using the 2.5mm hex key, loosen the

five set screws to fully open the

light mounting bracket.

Step 4

Tighten all hardware to the

recommended torque specifications

listed on the first page of this manual.

With the mounting bracket installed,

periodic inspections should be

performed to ensure all mounting

hardware remains tight.

Congratulations on the installation of

your new ARIES light mounting brackets.

Step 2

Place the light mounting bracket into the

desired position on the vehicle. Using the

2.5mm hex key, tighten the five set screws

to secure the bracket onto the vehicle.

Step 3

Place the light onto the mounting bracket.

Using the 5mm hex key, secure the light using

the M6 hex Cap Screw and M6 flat washer.
