Atlantis Land WebShare A02-RA11 Bedienungsanleitung

Where solutions begin

Company certified ISO 9001:2000

WebShare 111/141

ROUTER ADSL2+

A02-RA111

A02-RA141

USER’S MANUAL

A02-RA11(4)1 _ME02

Where solutions begin

Company certified ISO 9001:2000

WebShare 111/141

INDICE

WebShare 111/141 1

ROUTER ADSL2+ 1

CHAPTER 1: INTRODUCTION 1

1.1 An Overview of WebShare 111/141 ADSL2+ Router 1

1.2 Package Contents 2

1.3 WebShare 111/141 Router ADSL2+ Features 2

1.4 WebShare 111/141 Router ADSL2+ Application 4

CHAPTER 2: USING WEBSHARE 111/141 ADSL2+ ROUTER 6

2.1 Cautions for using the WebShare Router ADSL2+ 6

2.2 The Front LEDs 6

2.3 The Rear Ports 8

2.4 Cabling 8

CHAPTER 3: CONFIGURATION 10

3.1 Before Configuration 10

3.1.1 Configuring PC for Windows 95/98/ME 11

3.1.2 Configuring PC for Windows NT4.0 13

3.1.3 Configuring PC for Windows 2000 14

3.1.4 Configuring PC for Windows XP 16

3.1.5 Configuring for MAC 18

3.1.6 Verification of Configuration 19

3.1.7 Browser Configuration 19

3.2 Factory Default Setting 20

3.2.1 Password 20

3.2.2 LAN and WAN Port Addresses 21

3.3 Reset of WebShare Router ADSL2+ 21

3.4 Informations from the ISP 21

3.5 Browser Configuration 22

3.6 Surfing in Web GUI Configuration 22

3.7 Configuring Password 23

3.8 Resetting the ADSL Router 24

3.8.1 Using The Reset Button 24

WebShare 111/141

CHAPTER 4: QUICK START 25

4.1 Wizard Setup Introduction 25

4.2 Encapsulation 25

4.2.1 PPP over Ethernet 25

4.2.2 PPPoA 25

4.2.3 RFC 1483 25

4.3 Multiplexing 26

4.3.1 VC-based Multiplexing 26

4.3.2 LLC-based Multiplexing 26

4.4 VPI and VCI 26

4.5 Quick Start 26

4.6 Wizard Setup Configuration: Connection Tests 29

CHAPTER 5: LAN SETUP 30

5.1 LAN Overview 30

5.1.1 LANs, WANs and the ADSL Router 30

5.2 DNS Server Address 31

5.3 DNS Server Address Assignment 31

5.4 LAN TCP/IP 31

5.4.1 Factory LAN Defaults 32

5.4.2 IP Address and Subnet Mask 32

5.4.3 RIP Setup 32

5.4.4 Multicast 32

5.5 Configuring LAN 34

CHAPTER 6: WAN SETUP 36

6.1 WAN Overview 36

6.2 PPPoE Encapsulation 36

6.3 PPTP Encapsulation 36

6.4 Traffic Shaping 36

6.5 Configuring WAN Setup 38

CHAPTER 7: NETWORK ADDRESS TRANSLATION (NAT) 43

7.1 NAT Overview 43

7.1.1 NAT Definitions 43

7.1.2 What NAT Does 43

7.1.3 How NAT Works 44

7.1.4 NAT Application 44

7.1.5 NAT Mapping Types 45

WebShare 111/141

7.2 SUA (Single User Account) Versus NAT 46

7.3 Virtual Server and DMZ 46

7.3.1 Port Forwarding: Services and Port Numbers 46

7.3.2 Virtual Server 48

Click on Advanced Setup then NAT. 48

7.4 Selecting the NAT Mode 50

CHAPTER 8: ACCESS MANAGEMENT 53

8.1 ACL 53

8.2 IP Filter 54

8.3 SNMP 56

8.4 UPnP 56

8.5 DDNS 57

CHAPTER 9: ADVANCED SETUP 59

9.1 Routing 59

9.1.1 Add Route 59

9.2 NAT 61

9.2.2 DMZ 61

9.2.3 Virtual Server 62

9.2.4 IP Address Mapping 63

9.3 ADSL 64

CHAPTER 10: MAINTENANCE 65

10.1 Administration 65

10.2 Time Zone 65

10.3 Firmware 66

10.4 SysRestart 68

10.5 Diagnostic 68

CHAPTER 11: STATUS 70

11.1 Device Info 70

11.2 System Log 71

11.3 Statistics 71

APPENDIX A: TROUBLESHOOTING 74

A.1 Using LEDs to Diagnose Problems 74

A.1.1 Power LED 74

WebShare 111/141

A.1.2 LAN LED 74

A.1.3 DSL LED 74

A.2 Telnet 75

A.3 Web Configurator 75

A.4 Login Username and Password 76

A.5 LAN Interface 76

A.6 WAN Interface 77

A.7 Internet Access 77

A.8 Remote Management 78

A.9 Remote Node Connection 78

APPENDIX B: TECHNICAL FEATURES 79

APPENDIX C:SUPPORT 80

A02-RA11(4)1_ME02 (V1.0 December 2005)

WebShare 111/141

The Atlantis Land logo is a registered trademark of Atlantis Land SpA. All other

names mentioned mat be trademarks or registered trademarks of their respective

owners. Subject to change without notice. No liability for technical errors and/or

omissions.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause

radio interference, in which case the user may be required to take adequate

measures.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which

the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, (example - use only shielded

interface cables when connecting to computer or peripheral devices) any changes

or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

WebShare 111/141

1) This device may not cause harmful interference, and

2) This device must accept any interference received, including interference that

may cause undesired operation.

WebShare 111/141

A02-RA111 / A02-RA141 Pag. 1

CHAPTER 1: Introduction

1.1 An Overview of WebShare 111/141 ADSL2+ Router

Welcome to the WebShare 111/141 ADSL2+ Router. Your WebShare 111/141

ADSL2+ Router is an “all-in-one” unit, combining an ADSL modem, ADSL router

and Ethernet network switch, providing everything you need to get the machines

on your network connected to the Internet over your ADSL broadband connection.

The WebShare 111/141 ADSL2+ Router complies with ADSL2+ standards for

worldwide deployment and supports downstream rates of up to 24 Mbps and

upstream rates of up to 1 Mbps. It is designed for small office, home office and

residential users, enabling even faster speed Internet connections. User can

enjoy ADSL services and broadband multimedia applications such as interactive

gaming, video streaming and real-time audio much easier and faster than ever

before.

The product supports PPPoA (RFC 2364 – PPP (Point-to-Point Protocol) over

ATM Adaptation Layer 5), RFC 1483 encapsulation over ATM (bridged or routed),

PPP over Ethernet (RFC 2516), and IPoA (RFC1577) to establish a connection

with ISP. The product also supports VC-based and LLC-based multiplexing.

It is the perfect solution to connect a small group of PCs to a high-speed

broadband Internet connection. Multi-users can have high-speed Internet access

simultaneously.

This product also serves as an Internet firewall, protecting your network from

being accessed by outside users. Not only provide the natural firewall function

(Network Address Translation, NAT), it also provides rich firewall features to

secure user’s network. All incoming data packets are monitored and filtered.

Besides, it can also be configured to block internal users from accessing to the

Internet.

The product provides two levels of security support. First, it masks LAN users’ IP

addresses which are invisible to outside users on the Internet, making it much

more difficult for a hacker to target a machine on your network. Secondly, it can

block and redirect certain ports to limit the services that outside users can access.

For example, to ensure that games and other Internet applications will run

properly, user can open some specific ports for outside users to access internal

services in network.

Integrated DHCP (Dynamic Host Control Protocol) services, client and server,

allow multiple users to get their IP addresses automatically on boot up from the

product. Simply set local machines as a DHCP client to accept a dynamically

assigned IP address from DHCP server and reboot. Each time local machine is

powered up; the router will recognize it and assign an IP address to instantly

connect it to the LAN.

For advanced users, Virtual Service function allows the product to provide limited

visibility to local machines with specific services for outside users. An ISP
