Audiovox GMRS1882CH Bedienungsanleitung

128-8333

1 of 30

CustomerService

1-800-290-6650

Released: Jan-28-08

128-8333

2 of 30

THISDEVICECOMPLIESWITHPART15OFTHEFCCRULES.

OPERATIONIS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1)THISDEVICEDOESNOTCAUSEHARMFULINTERFERENCE,AND

(2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIRED

OPERATION.

128-8333

3 of 30

CAUTION

SAFETY INFORMATION

Your wireless hand-held portable transceiver contains a low power

transmitter. When the PTT button is pushed (or the VOX mode is enabled)

itsends outradio frequency(RF) signals.The deviceis authorizedto operate

at a duty factor not to exceed 50%. In August 1996, the Federal

Communications Commissions (FCC) adopted RF exposure guidelines

with safety levels for hand-held wireless devices.

Important: To maintain compliance with the FCC' s RF exposure guidelines

hold the transmitter at least 1 inch (2.5 centimeters) from your

face and speak in a normal voice, with the antenna pointed up

and away. If you wear the handset on your body while using the

headset accessory, use only the Audiovox supplied carry clip

for this product and ensure that the antenna is at least 1 inch

(2.5 centimeters) from your body when transmitting. Use only

the supplied antenna. Do not use your transceiver with a

damaged antenna. Unauthorized antennas, modifications, or

attachments could damage the transmitter and may violate

FCC regulations.

Performance:

Your transceiver will only achieve its maximum operating range when

communicating with other transceivers across open and flat areas or

between elevated points. Normally occurring environmental factors such

as buildings, trees, terrain and weather, or interference from other radio or

electricalequipment,may haveadverseeffects onthe transceiver'seffective

range. These are not indicative of a fault condition.

Avoid placing the GMRS1882CH radio transceiver for prolonged periods of

time in direct sunlight or temperatures below -4°F (-20°C) or above

140°F (60°C).

Place the rubber cover on jacks when not in use.

128-8333

4 of 30

WARNINGS:

Battery Care

Never attempt to charge alkaline or dry cell batteries, as batteries may

burst causing personal injury and damage to the product. If rechargeable

batteries are used, such as Nickel Metal Hydride (Ni-MH), use only the

supplied Audiovox-approved rechargeable batteries. Use of the Audiovox

charger (also supplied) with other brands of batteries is not recommended,

as battery charging times will vary with different brands. Refer to the

Manufacturer’s instructions for charging other brands of batteries.

Battery Disposal

In general, if handled improperly, batteries pose a risk of fire or burns. Do

not disassemble, crush, puncture, short external contacts, or dispose of

the batteries in fire or water. Dispose of the batteries in a environmentally

safe manner and recycle whenever possible.

FCC WARNING

Replacement or substitution of transistors, diodes or other parts of a unique

nature, with parts other than those recommended by the manufacturer,

may cause a violation of the technical regulations of Part 15 of FCC Rules.

GMRSLICENSE:

USE OF THIS RADIO WITHINTHE UNITED STATES REQUIRESAN FCC

GMRSLICENSE. AN INDIVIDUAL18YEARS OFAGEOR OLDER,WHOIS

NOTAREPRESENTATAIVE OFAFOREIGNGOVERNMENT,IS ELIGIBLE

TOAPPLYFORAGMRSSYSTEMLICENSE. YOUWILLNEEDTWOFORMS

FROMTHE FCC:FCC FORM159,ANDFCCFORM 605(MAIN FORMAND

SCHEDULE F). YOU CAN FIND THE FORMS ONLINE AT:

HTTP://WWW.FCC.GOV/FORMPAGE.HTML,ORCALL1-800-418-3676.

128-8333

5 of 30

1. BatteryDoor

2. Monitor/BacklightButton

3. DetachableCarryClip

4. Push-To-Talk(PTT)Button

5. Antenna

6. ExternalSpeaker(SPK)/Micro-

phone(MIC)/Charge(CHG)

Jack

7. Built-inSpeaker

8. LiquidCrystalDisplay(LCD)

Model GMRS1882CH (FCC License Required)

9. Built-inMicrophone

10. UpChannel/VolumeButton

11. DownChannel/Volume

Button

12. MODE/WeatherButton

13. PowerOn/Off&Scan

Button

14. VOXButton

15. White Flashlight LED

16. FlashlightEnableButton

17. BatteryCharging Contacts

912

(REF)

18. CrankCharging Lever

128-8333

6 of 30

Model GMRS1882CH DISPLAY

1.Beep Tone Indicator: Icon appears when beep button confirmation

tone is selected; icon disappears when tone is off.

2.Key Lock Indicator: Icon appears when the keypad is locked. This

function disables keys such as channel up/down, SCAN and MODE.

3.Monitor Indicator: Icon appears when the Monitor (M) button is

pressed and the channel monitor function is activated.

4.Signal Strength Indicator: Icon appears when a signal is being

transmitted. The icon consists of five bars to indicate transmit signal

power level.

5.HI/LO Indicators: Power level indicator appears when the transmit

power is set to desired output power on the GMRS channels.

6.Large Segment Display: Indicates the channel number in use in

GMRS/FRS mode or WEATHER BAND mode.

7.Scan Indicator: This function allows the user to scan a channel (and

tone code, if present) every .5 second to search for a valid signal.

8.RogerBeep Tone On/Off Indicator: This icon appears when the

Roger Beep tone is on, and disappears when tone is not in use.

9.Battery Level Indicator: Icon indicates the battery charge level.

10.Signal Receive Indicator: RX icon appears when a signal is being

received.

11.Small Segment Display: Displays the CTCSS tone option for each

main channel from 01-38.

128-8333

7 of 30

13.Dual Watch Mode Indicator: Indicator appears when dual watch

mode is active.

14.Voice Activated Transmission (VOX) Indicator: This function

allows hands free conversation. The indicator appears when the

VOX mode is activated.

Equipment and Accessories Supplied

1. Radio (2) GMRS1882CH

2. Owner’s Manual 128-8333

3. Desktop Charger GMRS18DS

4. AC WallAdapter GMRS25AC

5. Rechargeable (NiMH) Batteries (8) GMRS6BAT

6. Detachable Carry Clip GMRS122BCLIP

Powering theTransceiver:

Your GMRS1882CH radio transceiver operates on four AAA Alkaline or

rechargeable batteries. Alkaline batteries will provide slightly better

performance than rechargeable batteries (supplied). Only Audiovox

approved rechargeable batteries should be recharged in the radio

transceiver using the charging accessories. This will ensure optimum

performance for the GMRS1882CH. Battery charging time is typically 6-7

hours for full charge, and 0.5-3 hours for fast charge (depending on existing

battery charge). (Refer to battery charging instructions later in this manual.)

Batteries may get warm during fast charge. Slow charging will automatically

occur after a quick charge of 75%, and may take up to 3-4 hours to achieve

an additional 20% charge. Batteries should not get warm during the slow

charge cycle. Use of theAudiovox charging equipment with other brands of

rechargeable batteries is not recommended as battery charging times will

vary. Refer to the manufacturer’s instructions for charging other brands of

batteries.

12. Weather Mode Indicator: Icon will be on steady when in the weather

band mode. When in the GMRS/FRS mode, the icon will blink when

the alert is active.

128-8333

8 of 30

Batteries

There are three methods of powering the GMRS1882CH:

1. Alkaline Batteries.

WARNING: Do not attempt to recharge Alkaline batteries.

2.AudiovoxRechargeableNi-MHBatteries-(RechargeableNi-MH

batteries and Charging Adapter included). Use only Audiovox

approved rechargeable batteries and charging equipment when

charging batteries internal to the unit.

NOTE: To extend battery life, avoid overcharging the batteries

3. Various Brands of Rechargeable Batteries - Use of the Audiovox

charger with other brands of rechargeable batteries is not

recommended, as battery charging times will vary with different

brands of batteries. Refer to the manufacturer’s instructions for

charging other brands of batteries.

Installing the batteries:

Battery installation is made more convenient when the carry clip is

removed. To do this, release the spring latch securing the clip to radio

and slide the clip downward and away from the radio body.Using

forefinger, grasp the battery cover behind the embossed arrow and pull on

the cover to lift to open. Insert four AAA batteries (alternate positive

ends (+) toward the right side of the transceiver (starting top-to-bottom).

2.Usingforefinger,pullonbatterycover

at"arrow"markandthenlifttoopen.

Removecover.

3.InsertfourAAAbatteries(positive(+)end

towardright side begining at top and

alternatingpositiveterminalsas shown).

1.Using forefinger, pullon

charging leverat"PULL"

marktoflip.

RELEASE

BUTTON

CARRY

CLIP

BATTERY

COVER

CHARGING

LEVER

PULL

128-8333

9 of 30

The following guidelines will improve performance and provide longer

operating times for the GMRS1882CH:

1. Do not mix old and new batteries.

2. The use of alkaline-type batteries is recommended to provide the

longest operating time.

3. Do not mix alkaline, standard (carbon-zinc) or rechargeable

batteries.

4. If the unit is not to be used for an extended period of time, remove the

batteries. Old or leaking batteries can cause damage to the unit and

will void the warranty.

INPUT: 120VAC

OUTPUT: 12VDC

DESKTOP CHARGING STAND

PARTNUMBERGMRS18DS

CHARGING STAND

PWR JACK

ADAPTER

POWER

PLUG

GMRS RADIO

CHARGING

COMPARTMENTS(2)

CHARGINGCOMPARTMENT

LEDs:

RED----FAST CHARGING

OFF----SLOW CHARGING

NOTE:

Only

Audiovox

approvedrechargeable

batteries(P/NGMRS6BAT)

can be recharged in the

radio transceiver.

AC WALL ADAPTER/

CHARGING TRANSFORMER

MODEL:GMRS25AC

128-8333

10 of 30

GMRS1882CH OPERATION MODE

WEATHERBAND

Weather CHANNEL

SELECT

ROGER

BEEP

BUTTON

BEEP

DUAL

WATCH

VOXLEVEL

SELECT

CALL

SELECT

POWER

SELECT (GMRSChannels

Only)

GMRS/FRSBAND

CTCSS

SELECT

CHANNEL

SELECT

NOTE: 1. To switch between GMRS/FRS

and Weather Band modes,

press and hold the MODE/WB

button for 2 seconds. Refer to

the appropriate section of this

manual for detailed operating

instructions for each mode.

2.To enter the VOX mode, press

and hold the VOX button for 1

second.

WeatherALERT

On/Off

Controls:

LEDFlashlight Button(16)

Press this button on the right side of the Transceiver to light the white LED

(15) on top of the unit, thereby activating the built-in flashlight function.

Power On-Off/SCAN Button (13)

Press and hold the power on/off button ( ) for 2 seconds.You will hear

a dual beep to indicate the unit is on. Press the on/off button again for 2

seconds to turn the unit off. When the unit is on and the button is pres-

sed momentarily, the scan mode is enabled or disabled; when enabled,

the scan icon (SCAN) appears on the display.

Adjusting the Volume (10, 11)

With the unit powered on, press the Up Channel/Volume button ( ) to

increase volume and the Down Channel/Volume button ( ) to decrease

Inhaltsverzeichnis

Andere Audiovox Radio Handbücher

Audiovox

Audiovox XAPH1 Bedienungsanleitung

Audiovox

Audiovox GMRS862CH Bedienungsanleitung

Audiovox

Audiovox GMRS500SLK Bedienungsanleitung

Audiovox

Audiovox XPRESSEZ XMCK-5P Bedienungsanleitung

Audiovox

Audiovox GMRS120 Bedienungsanleitung

Audiovox

Audiovox GMRS7001-2CH Bedienungsanleitung

Audiovox

Audiovox GMRS762CH Bedienungsanleitung

Audiovox

Audiovox SIR-CK3 Bedienungsanleitung

Audiovox

Audiovox XMCK20P - XPRESSR XM Radio Tuner Bedienungsanleitung

Audiovox

Audiovox XMRVRFM002 - Commander MT XM Radio Tuner Bedienungsanleitung

Audiovox

Audiovox GMRS-1200CH Bedienungsanleitung

Audiovox

Audiovox GMRS1202CH Bedienungsanleitung

Audiovox

Audiovox GMRS-1535 Bedienungsanleitung

Audiovox

Audiovox XM XpressRCi XDRC2 Bedienungsanleitung

Audiovox

Audiovox GMRS600SCH Bedienungsanleitung

Audiovox

Audiovox GMRS602PK Bedienungsanleitung

Audiovox

Audiovox CommanderMT 128-7902A Bedienungsanleitung

Audiovox

Audiovox SIR-PNP1 Montage- und Bedienungsanleitung

Audiovox

Audiovox Sirius SIR-PNP2 Bedienungsanleitung

Audiovox

Audiovox GMRS100 Bedienungsanleitung

Audiovox

Audiovox GMRS200 Bedienungsanleitung

Audiovox

Audiovox Satellite Radio Receiver Bedienungsanleitung

Audiovox

Audiovox MS160 Bedienungsanleitung

Audiovox

Audiovox GMRS-7000 Bedienungsanleitung

Beliebte Radio Handbücher anderer Marken

EisSound

EisSound KBSound iSelect Bedienungsanleitung

Midland

Midland 1001LWX Bedienungsanleitung

Konig

Konig HAV-SR41 Bedienungsanleitung

Roberts

Roberts exprssion Bedienungsanleitung

VDigi

VDigi DD3.0 Bedienungsanleitung

Radio Shack

Radio Shack 21-1863 Bedienungsanleitung

Roberts

Roberts Stream 207 Bedienungsanleitung

Sony

Sony Walkman SRF-M97 Bedienungsanleitung

Stanley

Stanley FatMax FMC770 Bedienungsanleitung

auna

auna DAB-Radio 10026947 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER UR190 Bedienungsanleitung

HYT

HYT TC-320 Bedienungsanleitung

auna multimedia

auna multimedia Yellowstone 10026851 Bedienungsanleitung

B-Tech

B-Tech GMRS-V2 Bedienungsanleitung

Weierwei

Weierwei VEV-V8 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER DAB750 Bedienungsanleitung

Telefunken

Telefunken TF-1505 Bedienungsanleitung

Makita

Makita LXRM03 Bedienungsanleitung
