Avision AV121 Bedienungsanleitung

Sheet-fed Scanner

Quick Guide

Avision Inc.

ENGLISH

Trademarks

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

Windows, Windows Vista, Windows 7 and Windows 8 are either

registered trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

IBM, IBM PC are registered trademarks of International Business

Machines Corp.

Other brands and product names herein are trademarks or

registered trademarks of their respective holders.

reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language,

in any form or by any means, electronic, mechanical, magnetic,

optical, chemical, manual, or otherwise, without the prior

written permission of Avision Inc.

Material scanned by this product may be protected by

governmental laws and other regulations, such as copyright

laws, the customer is solely responsible for complying with all

such laws and regulations.

Warranty

The information contained in this document is subject to

change without notice.

Avision makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties

of fitness for a particular purpose.

Avision shall not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance, or use of this material.

iii

Table of Contents

1. Introduction.............................................. 1-1

2. Scanner Installation.................................. 2-1

2.1 Installing the ADF Paper Tray Unit ................. 2-2

2.2 Installing the Output Paper Tray.................... 2-5

2.3 Installing the Scanner Driver and Connecting

the Cables.................................................. 2-6

2.3.1 Connecting to Power......................... 2-6

2.3.2 Turning on the Power ....................... 2-6

2.3.3 Installing the Scanner Driver ............. 2-7

2.3.4 Connecting to Computer ................... 2-8

3. Completing Your First Scan ....................... 3-1

3.1 Loading Your Paper ..................................... 3-1

3.1.1 Notice on Using the ADF.................... 3-1

3.1.2 Placing Your Document in the ADF

Paper Tray ...................................... 3-2

3.2 Verifying Your Scanner Installation ................ 3-3

3.3 A Glance of the Scanner Properties Dialog Box 3-5

4. ISIS Interface Operation........................... 4-1

5. Using the Buttons...................................... 4-1

5.1 Installing Button Manager V2 ........................ 5-2

5.2 Checking the Button Configurations before

Scanning ................................................... 5-2

5.3 Scanning From One Touch of the Buttons ....... 5-4

6. Maintenance.............................................. 6-1

6.1 Cleaning the ADF ........................................ 6-1

6.2 Cleaning the Glass....................................... 6-3

7. Troubleshooting ........................................ 7-1

7.1 Clearing a Paper Jam ................................... 7-1

1-1

1. Introduction

Congratulations on your purchase of the color sheet-fed

image scanner. Avision is one of the leading companies in

the world to develop high performance sheet-fed scanners.

Before you install and operate the new scanner, please take

a few minutes to read through this manual. It provides

proper instructions for you to unpack, install, operate and

maintain the scanner.

The following figure indicates the package contents. Please

check all the items against your checklist. If you do not

receive all the items, please contact your authorized local

dealer immediately.

1-2

1. Scanner Main Unit

2. ADF (Auto Document Feeder) Paper Tray

3. Output Paper Tray

4. USB Cable

5. Power Adapter/Power Cord

Note:

1. Using other AC adapters may damage the machine and

void the warranty.

2. Please unpack the packing carefully, and check the contents

against the checklist. If any items are missing or damaged,

please contact your dealer immediately.

1 2

2-1

2. Scanner Installation

Precautions

Keep the scanner out of direct sunlight. Direct

exposure to the sun or excessive heat may cause

damage to the unit.

Do not install the scanner in a humid or dusty place.

Be sure to use the proper AC power source.

Place the scanner securely on an even, flat surface.

Tilted or uneven surfaces may cause mechanical or

paper-feeding problems.

Retain the scanner box and packing materials for

shipping purposes.

2-2

2.1 Installing the ADF Paper Tray Unit

Attach the Paper Support to the ADF (Auto Document

Feeder) Paper Tray.

Paper SupportADF Paper

Tray

2-3

2. Pull out the Paper Jam Clearing Button to open the front

door to the left.

3. Insert four protrusions on the bottom of the ADF Paper

Tray into the holes on the front of the scanner.

Paper Jam

Clearning

Button

Protrusions

Front

Door

2-4

4. Insert two protrusions in the middle of the ADF Paper

Tray into the holes on the top of the scanner.

Protrusions

Holes

2-5

2.2 Installing the Output Paper Tray

Insert the right and left protrusion of the Output Paper Tray

into the holes on the front of the scanner.

Scanner

Output Paper Tray

Protrusion

Holes
