BAFANG DP C10.UART Bedienungsanleitung

USER MANUAL

DP C10.UART

USER MANUAL DP C10.UART

CONTENT

Important Notice....................................................4

For your safety........................................................5

Note.......................................................................6

Overview of Product ...........................................7

1 Speciﬁcations and Parameter of the Display..............7

2 Appearance and Dimensions....................................7

3 Funcion Overview and Key Deﬁnitions......................8

4 Normal Operation..................................................10

5 Parameter Setting...................................................12

6 Error Code Deﬁnitons.............................................19

Serive and Warranty Policy....................................20

CONTENT

3USER MANUAL DP C10.UART

USER MANUAL DP C10.UART

IMPORTANT NOTICE

Make sure you have read this Dealer Manual

carefully in order to use the product properly.

•This product conforms to <<The Technical

Speciﬁcation and Standard of design for

BAFANG's electrical component>> and is

based on << BAFANG Communication

Protocol-V5.6>>;The matching kits also

should be compatible with above

mentioned protocol and other BAFANG's

mpatible protocol.

USER MANUAL DP C10.UART

NOTE

HANDLING INFORMATION

USER MANUAL DP C10.UART

•Pluging or displuging the HMI with power

on is forbidden.

Please contact the seller for help when any

error codes show on the HMI or any failure

come .

Please use this product in the given

circumstance indicated in the manual.

1 Speciﬁcations and Parameters of the Display

• 24V / 36V / 43V / 48V Power Supply

• Rated Current: 10mA

• Maximum Operating Current: 30mA

• Power-off Leakage Current: < 1uA

• Operating Current Supplied to the Controller: 50 mA

• OperationTemperature: -20℃— +60℃

• Storage Temperature: -20℃— +60℃

• Waterproof Grade: IP65

• Storage Humidity: 30 % -- 70 %

2 Appearance and Dimensions

2.1 Materials and Dimensions

•

The shell is made of PC.

The liquid crystal display is made of hardened PMMA.

USER MANUAL DP C10.UART

OVERVIEW OF PRODUCT

The matching kits also should be compatible with above

mentioned protocol and other BAFANG's mpatible protocol.

•

This product conforms to <<The Technical

Speciﬁcation and Standard of design for

BAFANG's electrical component>> and is based

on << BAFANG Communication Protocol-V5.6>>

3 Function Overview and Key Deﬁnitions

3.1 Function Overview

• Use of a two-way serial communication protocol,

simple operation of the display via the external

5-key keypad.

• Speed display: displaying the real-time speed as

SPEED, the maximum speed as MAXS, the

average speed as AVG, remaining range TO

GO, Power W, Calory C .

• km or mile: The user can choose between km

and mile.

• Intelligent battery level indication: With an

optimization algorithm, a stable display of the

battery level is ensured, and the problem of ﬂuc-

tuant battery level indication common with other

displays is avoided.

• Automatic light-sensitive lights:The headlight,

taillight and display light will be automatically

turned on/ off depending on lighting conditions.

• 5 levels off display backlighting: Different levels

• 5-Level-Support: setting power Levels 1 to 5

• Trip distance indication:The maximum distance

displayed is 99999. Single-trip distances TRIP or

the total distance TOTAL can be displayed.

• Display of error messages

• Walk assistance

• Settings: Various parameters, e.g. mode, wheel

diameter, speed limit etc., can be set on the com

puter via a communication cable. See the setting

• Maintenance warning (this function can be deac -

tived): Maintenance warning information is dis-

played based on battery charge cycles and riding

distance. The display automatically estimates the

battery life and gives warnings when the number

of charge cycles exceeds the set value. A warning

will also be displayed when the accumulated total

riding distance exceeds the set value.

3.2 Information on the Display

USER MANUAL DP C10.UART

Headlight indication: only shows when headlight

or backlight are on

Speed display: display of the speed, km/h or mph

Error display: When a fault is detected the

symbol will be displayed.

ABattery level: 10-segment battery indication; the

voltage that each segment represents can be

customized

BUSB charge

GMax speed

HAvg speed

IRemaining mileage

Level indication: The chosen level 1–5 will be

displayed; if there is no numeric display, it means

that there is no assistance (by the motor). If the

rider is walking and pushing the e-bike, will

be displayed.

OVERVIEW OF PRODUCT

USER MANUAL DP C10.UART

3.3 Key Deﬁnitions

A up

B down

C headlight

D on/off

E mode

Speed mode: average speed (AVG km/h), maxi-

mum speed (MAXS km/h)

Maintenance warning: When there is a need for

maintenance the symbol will be dis-

played (riding distance or the number of battery

charge cycles exceed the set value, function can

be deactivated)

NTotal mileage

Walk assistance

MDistance mode: display of the single-trip distance

TRIP and the total distance TOTAL

Distance indication: display of the distance

depending on the setting.

4.1 On/Off Switch

Turn on the device. Press and hold for 2 seconds

to power on the display. Press and hold again for

2 seconds to power off the display. If the bike is not

used, after 5 minutes (time can be set) the display will

be automatically turned off.

4.2 Assist Mode Selection

In the manual gearshift mode, press the or

to choose the desired level of support by the motor.

The lowest level is Level 1, the highest Level 5. When

the display is on, the default mode is Level 1. When

there is no numeric mode display, there is no power

assistance.

Selecting the level for motor assistance

4.3 Switch between Distance Mode

and Speed Mode

Brieﬂy press to switch between distance and

speed. Single-trip distance (TRIP km) total distance

(TOTAL km) maximum speed (MAXS km/h)

average riding speed (AVG km/h)

successive order.

Switching between displays

DISPLAY (DP C10.UART)

USER MANUAL DP C10.UART

Remaining range

are displayed in

（TO GO km ） Power(w） Calory (c)

OVERVIEW OF PRODUCT

Normal Operation
