Barco Graphics 6300 Bedienungsanleitung

BARCO PROJECTION SYSTEMS

Date :

060199

INSTALLATION MANUAL

KIT LAMP FOR 6300 PROJECTORS

R9829900

Art. No. :

R5975949

Rev :

Lamp 6300

Kit

Due to constant research, the information in this manual is subject to change without notice.

Produced by BARCO NV, January 1999.

Trademarks are the rights of their respective owners.

BARCO n.v./Projection Systems

Noordlaan 5

B-8520 Kuurne

Belgium

Tel : +32/56/368211

Fax : +32/56/351651

E-mail : [email protected]

Visite Barco at the web : http://www.barco.com

Printed in Belgium

BARCO  3  Projection Systems

Safety

Who This procedure is intended for use only by qualified service technicians who have been

trained and authorized by BARCO !

Hot Surface and

Risk of

Explosion.

Switch the projector to stand by and let it cool down for at least 15 minutes before

starting with the lamp replacement.

These lamps consist of a quartz arc tube operating at very high temperature and high

pressure (20 bar) which may explode suddenly. There is a risk of personal injury and

property damage from hot quartz arc tube particles if handled incorrectly.

Risk of Electrical

Shock.

Power down the projector and unplug the power cord from the wall outlet.

Once the projector is cooled down and the power is off, continue with the replacement

procedure.

Lamp Life Time

Warning

The total lifetime of the lamp for safe operation is 750 hours maximum in normal power

mode.

Do not use it longer ! Always replace the lamp with the BARCO lamp kit for 6300

projectors.

BARCO  4  Projection Systems

Contents of the Kit

Lamp Type The kit contains a Metal Halide projection Lamp mounted in a housing together with the

reflector.

Precautions Do not touch the lamp with your fingers otherwise the lifetime of the lamp will be

reduced.

If the lamp is touched, finger prints can be removed by cleaning the lamp with alcohol.

Part Listing The following parts are in the kit :

R808017

R5975949

1FRMC G6300 LMP HSG +LMP

MAN INS G6300 LMP

Part Number Description Indication

Lamp Serial

Number

Each new lamp is marked with a serial number (6 digits). Write down this number in

the forseen area. The serial number has to be programmed when resetting the lamp

run time.

Serial number lamp : 0

Illustration of the

Kit

BARCO  5  Projection Systems

To be continued on next page.

Access to the Lamp Unit.

What has to be

done

- The lamp house door has to be opened.

- The lamp protection cover has to be removed.

Necessary Tools - a flat screwdriver 5 mm

Opening the

Lamp House

Door.

To open the lamp house door, follow the next procedure:

Turn with a screwdriver a quarter turn counter clockwise.

Open the door a little.

Unhook the door from its fixing points.

Step Action Image

Illustrations on

Opening the

Lamp House

Door.

Image 1

Image 2

BARCO  6  Projection Systems

Access to the Lamp Unit (Continued)

Removing the

Protection Cover

To remove the protection cover, follow the next procedure:

1Loosen with a screwdriver the four indicated bolts.

Pivote the plate a little downwards.

Take out the protection cover.

Step Action Image

Caution Hot surface.

Do not touch rotating fan blades.

High pressure lamp may explode if improperly handled. Refer servicing to qualified

service personnel.

Illustrations on

Removing the

Protection Cover

BARCO  7  Projection Systems

To be continued on next page.

Removing the Lamp Unit.

What has to be

done

- The lamp power connection has to be disconneced.

- The lamp assembly has to be removed.

Necessary Tools - No tools are necessary.

Disconnecting

the Lamp Power

Cable

To disconnect the lamp power cable, follow the next procedure:

Pull out the connector.

Take the connector between thumb and finger.

Push at the same time on both looking parts.

Unplug the connectors.

Step Action Image

Illustrations on

Disconnecting

the Lamp Power

Cable

The following images give an overview how to discoonect the power cable.

image 1

image 2

BARCO  8  Projection Systems

Removing the Lamp Unit (Continued)

Removing the

Lamp Assembly

To remove the lamp assembly, follow the next procedure:

1Slide the lamp assemble backwards

Take out the lamp assembly.

Step Action Image

Illustrations on

Removing the

Lamp Assembly

The following image gives an illustration on how to slide out the lamp.

image 1

image 2

BARCO  9  Projection Systems

To be continued on next page.

Installing the Lamp Unit.

What has to be

done

- The lamp assembly has to be installed.

- Reinstall the lamp power cable.

Precautions Do not touch the lamp with your fingers otherwise the lifetime of the lamp will be

reduced.

If the lamp is touched, finger prints can be removed by cleaning the lamp with alcohol.

Installing the

Lamp Assembly

To install the lamp assembly, follow the next procedure:

Take the lamp assembly out of its package.

Put the lamp assembly in the lamp house.

Slide the lamp assemble forwards until fits on its place.

Step Action Image

Illustrations on

Installing the

Lamp Assembly

Image 1

Image 2

BARCO  10  Projection Systems

Installing the Lamp Unit (Continued)

Image 1

Illustrations on

Connecting Lamp

Power Cable.

Reinstall the

Lamp Power

Cable.

To reinstall the lamp power cable, follow the next procedure:

Connect the connector at the lamp side into the connector

at the power side.

Put the connector under the metal slip.

Step Action
