VCC 50701 AW

Vacuum Cleaner

User Manual

EN IT RO SL SV CS HU

BG FR PL DE ES NL

01M-8812123200-4617-01

Please read this manual first!

Dear Valued Customer,

Thank you for preferring this Beko appliance. We hope that you get the best results

from your appliance which has been manufactured with high quality and state-of-the-

art technology. For this reason, please read this user manual and all other provided

documents carefully before using the appliance and keep it as a reference for future

use. If you hand over the appliance to someone else, give the user manual as well.

Follow the instructions by paying attention to all the information and warnings in the

user manual.

Remember that this user manual may also apply to other models. Differences between

models are explicitly described in the manual.

Meanings of the Symbols

Following symbols are used in various sections of this manual:

Important information and useful

hints about usage.

AWARNING:

Warnings against

dangerous situations concerning the

security of life and property.

Protection class for electric shock.

This product has been manufactured in environmental friendly modern plants without giving any harm

to the nature.

It does not contain PCB.

Made in P.R.C.

Vacuum Cleaner / User Manual 3 / EN

CONTENTS

ENGLISH 4-10

ITALIANO 11-19

ROMANIAN 20-29

SLOVENŠČINA 30-37

SVENSKA 38-45

ČESKY 46-53

MAGYAR 54-62

BULGARIAN 63-72

FRANÇAIS 73-81

POLSKI 82-94

DEUTSCH 95-103

ESPAÑOL 104-113

NEDERLANDS 114-122

4 / EN Vacuum Cleaner / User Manual

This section contains safety

instructions that will help protect

from risk of personal injury or

property damage.

Failure to follow these instructions

invalidates the granted warranty.

1.1 General safety

•This appliance complies with

the international security

standards.

•This appliance can be used by

children aged from 8years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have

been given supervision or

instruction concerning use of

the appliance in a safe way

and understand the hazards

involved. Children shall not play

with the appliance. Cleaning

and user maintenance shall not

be made by children without

supervision.

•Do not use it if the power

cable or the appliance itself is

damaged. Contact an authorized

service.

•Your mains power supply should

comply with the information

supplied on the rating plate of

the appliance.

•The mains supply of the

appliance must be secured with

a minimum 16 A fuse.

•Do not use the appliance with

an extension cord.

•In order to prevent the power

cable from getting damaged,

make sure that it doesn’t get

stuck, twisted or rub against

sharp surfaces.

•Do not touch the appliance or its

plug when it is plugged if your

hands are damp or wet.

•Do not pull the power cable when

unplugging the appliance.

•Do not vacuum flammable

materials and when vacuuming

cigarette ashes make sure that

it got cold.

•Do not vacuum water or other

liquid materials.

•Protect the appliance from rain,

humidity and heat sources.

1Important safety and environmental instructions

Vacuum Cleaner / User Manual 5 / EN

•Never use the appliance

in or near to combustible

or inflammable places and

materials.

•Unplug the appliance before

cleaning and maintenance.

•Do not dip the appliance or its

cable in water to clean it.

•Check the hose of the appliance

regularly. Do not use if it is

damaged and contact an

authorized service.

•Do not attempt to dismantle the

appliance.

•Only use the original parts or

parts recommended by the

manufacturer.

•If heavily used for cleaning dust

such as cement or grout the

dust indicator will lit earlier then

expected, in such case replace

the dust bag even it is empty.

•Do not use the appliance

without filters; otherwise it can

get damaged.

•When vacuuming the stairs,

the appliance should be located

below the user.

•If your store the package

material, keep it out of the reach

of children.

1.2 Compliance with WEEE

Directive and Disposing of the

Waste Product

This product complies with EU WEEE

Directive (2012/19/EU). This product

bears a classification symbol for waste

electrical and electronic equipment

(WEEE).This product has been manufactured with

high quality parts and materials which can be

reused and are suitable for recycling. Do not

dispose of the waste product with normal

domestic and other wastes at the end of its

service life. Take it to the collection center for the

recycling of electrical and electronic equipment.

Please consult your local authorities to learn

about these collection centers.

1.3 Compliance with RoHS

Directive

The product you have purchased complies with EU

RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the

Directive.

1.4 Package information

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations. Do not dispose

of the packaging materials together with the

domestic or other wastes. Take them to the

packaging material collection points designated

by the local authorities.

1Important safety and environmental instructions

6 / EN Vacuum Cleaner / User Manual

2.1 Overview

The values which are declared in the markings affixed on your appliance or other printed documents supplied with it represent the values which

were obtained in the laboratories pursuant to the pertinent standards. These values may vary according to the usage of the appliance and ambient

conditions.

2Your vacuum cleaner

1. Handle

2. Vacuum control

3. Telescopic tube

4. Telescopic tube adjustment latch

5. Dust container release latch

6. Suction nozzle

7. Hose cap

8. Top lid

9. Parquet/carpet brush

10. Power cable winding button

11. Parquet/carpet brush parking groove

12. Filter cap

13. On/Off button

14. Suction power adjustment knob

15. Dust indicator

16. Carriage handle

17. Hose

2.2 Technical data

Power :

800W

Supply voltage :

220-240V~, 50-60Hz

Sound level :

76 dbA

Dust capacity :

3,2 L

Operating radius :

8 m

Dust collecting

on carpet : C

Hard floor dust

collecting : A

Dust emission : A

Energy class : A

Rights to make technical and design changes are

reserved.

10111213

Vacuum Cleaner / User Manual 7 / EN

3Usage

3.1 Intended use

The appliance has been designed for household

use and is not suitable for industrial use.

3.2 Attaching/removing the

hose

1. To attach the hose (17), push the hose cap (7) in

the arrow direction in order to match it with the

suction nozzle and rotate it clockwise.

2. To remove the hose (17), rotate the hose cap (7)

counter-clockwise and pull it.

3.3 Attaching/removing the

telescopic tube

1. Attach the telescopic tube (3) to the handle (1).

2. Pull the telescopic tube (3) from the handle (1)

to remove it.

3. Push the telescopic adjustment latch (4) in the

arrow direction and pull the telescopic tube (3)

to adjust its length.

3.4 Attaching/removing the

parquet/carpet brush

You can install/remove the narrow end of the

telescopic tube (3) from/to the parquet/carpet

brush (9).

3.5 Adjusting the parquet/

carpet brush

Perform the following actions on the adjustment

latch (4) located on the parquet/carpet brush (9);

•Use " " position for hard floors and parquet.

•Use " " position for rugs and carpets.

3.6 Operation

1. Plug in the appliance after pulling the power

plug located at the back of the appliance.

2. Press the on/off button (13) to switch on your

appliance.

3.6.1 Adjusting the suction

power

1. You can adjust the suction power using the

suction power adjustment button (14) found

on the appliance. Rotating in the clockwise

direction will increase the suction power and

in counterclockwise direction will decrease the

suction power.

2. You can lower the suction power of the parquet

carpet brush by pulling backward the vacuum

adjustment control (2) located on the handle

(1) without the need to use the suction power

adjustment knob (14) found on the appliance.

8 / EN Vacuum Cleaner / User Manual

3.6.2 Dust indicator

Dust indicator (15) indicates the fullness of the

dust bag. When the indicator displays red zone

more than 50%, replace the dust bag. (see 4.1).

3.7 Accessories

Crevice tool

Suitable for cleaning surfaces dif-

ficult to clean, such as areas under

sofas and furniture.

AWARNING:

Do not perform

cleaning tasks using the end part of

the handle (1).

3.8 Switching off and parking

the appliance

1. Switch off the appliance with the on/off button

(13) and unplug it.

2. Wind the power cable by pressing the power

cable winding button (10).

Vertical parking feature

Insert the parking hook of the parquet/carpet

brush into the parking groove located at the

bottom section of the appliance.

Horizontal parking feature

Insert the parking hook of the parquet/carpet

brush into the parking groove (11) located at the

rear section of the appliance.

3Usage

Vacuum Cleaner / User Manual 9 / EN

4Cleaning and care

Switch off and unplug the appliance before

cleaning it.

AWARNING:

Never use gasoline,

solvent, abrasive cleaning agents,

metal objects or hard brushes to

clean the appliance.

4.1 Replacing the dust bag

1. Open the top lid by pressing the dust container

opening latch (5).

2. Remove the full dust bag from its guide, sliding

it in upwards direction.

3. Dispose the full dust bag.

4. Insert the new dust bag holding it in the arrow

direction indicated on it. Ensure that it is fully

seated.

5. Close the appliance's top lid (8).

AWARNING:

Do not force the top lid

(8) to close it, otherwise the plastic

sections can be damaged.

WARNING:

Dust bags purchased

from locations other than the

authorized dealers and services

are not original. Unoriginal dust

bags have a lesser quality and

they become torn in a shorter

period and render your appliance

nonoperational. Faults caused due

to using unauthentic dust bags are

not covered within the warranty.

AWARNING:

Do not wash the dust

bag.

4.2 Cleaning the filters

Motor

Protection Filter Foam filter HEPA filter

After each 5 dust bag replacement (may vary

depending on the frequency and area of usage),

clean the filters.

AWARNING:

Do not use appliances

producing hot air such as hair dryer

or heater to dry the filters.

WARNING:

Do not install the

filters without completely drying

them; otherwise, smell of moisture

may occur during use, water can leak

from the back of the appliance or the

filters may get damaged.

AWARNING:

Attach the filters into

their places after they have dried.

10 / EN Vacuum Cleaner / User Manual

4.2.1 Motor protection filter

1. Open the top lid by pressing the dust container

opening latch (5).

2. Press down on the latch of the filter cassette to

remove the cassette.

3. Remove the motor protection filter from the

cassette inside.

4. After washing the motor protection filter under

running water, wring it out slightly and let it dry

(for 24 hours minimum).

4.2.2 HEPA filter

1. Raise the filter cap in the arrow direction to

open it.

2. Remove the HEPA filter by pulling it from its

handle.

3. Shake off the HEPA filter to eliminate the dusts

on it. After that, you can wash it by holding its

clean side under running cool water.

4. If you wash the HEPA filter, dry it at room

temperature (for 24 hours minimum). Do not

use it before ensuring that it is completely dry.

4.2.3 Foam filter

1. Raise the filter cap in the arrow direction to

open it.

2. After removing the HEPA filter, pull out and

wash the foam filter located behind it.

3. After washing the motor protection filter under

running water, wring it out slightly and let it dry

(for 24 hours minimum).

4.3 Storage

•If you do not intend to use the appliance for a

long time, store it carefully.

•Unplug the appliance.

•Keep the appliance out of the reach of children.

4.4 Handling and

transportation

•During handling and transportation, carry

the appliance in its original packaging. The

packaging of the appliance protects it against

physical damages.

•Do not place heavy loads on the appliance or on

the packaging. The appliance may get damaged.

•Dropping the appliance may render it non-

operational or cause permanent damage.

4Cleaning and care

Inhaltsverzeichnis

Sprachen:

Andere Beko Staubsauger Handbücher

Beko

Beko VRT 84225 VB Bedienungsanleitung

Beko

Beko VCM 71602 AD Bedienungsanleitung

Beko

Beko VCC34801AR Bedienungsanleitung

Beko

Beko VCC 44822 AD Bedienungsanleitung

Beko

Beko BKS 1310 EY Bedienungsanleitung

Beko

Beko VCO32801AR Bedienungsanleitung

Beko

Beko VCO 20713 WV Bedienungsanleitung

Beko

Beko VCC 6480 T Bedienungsanleitung

Beko

Beko VRT 50121 VP Bedienungsanleitung

Beko

Beko 01M-8811553200-4719-05 Bedienungsanleitung

Beko

Beko VCC 44818 WR Bedienungsanleitung

Beko

Beko VCC34118WD Bedienungsanleitung

Beko

Beko VRR 70214 VB Bedienungsanleitung

Beko

Beko VRT 82821 BV Bedienungsanleitung

Beko

Beko BKS 1351 K Bedienungsanleitung

Beko

Beko BKS 5316 T Bedienungsanleitung

Beko

Beko 01M-8838073200-3019-06 Bedienungsanleitung

Beko

Beko VRS 82724 VB Bedienungsanleitung

Beko

Beko VRR 81214 VW Bedienungsanleitung

Beko

Beko VRT 94929 VV Bedienungsanleitung

Beko

Beko BKS 9316 Bedienungsanleitung

Beko

Beko VCC34818WD Bedienungsanleitung

Beko

Beko VCC 44821 AR Bedienungsanleitung

Beko

Beko VCS 50700 CW Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
