Beko VCC34801AR Bedienungsanleitung

VCC34801AR

VCC34802AB

VCC34803AD

Vacuum Cleaner

User Manual

EN DE FR ES RO IT

PL SL CS BG HU NL

01M-8832263200-3719-05

01M-8834873200-3719-05

01M-8835393200-3719-05

Please read this manual first!

Dear Valued Customer,

Thank you for preferring this Beko appliance. We hope that you get the best results

from your appliance which has been manufactured with high quality and state-of-the-

art technology. For this reason, please read this user manual and all other provided

documents carefully before using the appliance and keep it as a reference for future

use. If you hand over the appliance to someone else, give the user manual as well.

Follow the instructions by paying attention to all the information and warnings in the

user manual.

Remember that this user manual may also apply to other models. Differences between

models are explicitly described in the manual.

Meanings of the Symbols

Following symbols are used in various sections of this manual:

Important information and useful

hints about usage.

AWARNING:

Warnings against

dangerous situations concerning the

security of life and property.

Protection class for electric shock.

This product has been manufactured in environmental friendly modern plants without giving any harm

to the nature.

It does not contain PCB.

Vacuum Cleaner / User Manual 3 / EN

CONTENTS

ENGLISH 4-12

DEUTSCH 13-23

FRANÇAIS 24-33

ESPAÑOL 34-45

ROMANIAN 46-57

ITALIANO 58-68

POLSKI 69-79

SLOVENŠČINA 80-89

ČESKY 90-99

BULGARIAN 100-109

MAGYAR 110-119

NEDERLANDS 120-129

4 / EN Vacuum Cleaner / User Manual

This section contains safety

instructions that will help protect

from risk of personal injury or

property damage.

Failure to follow these instructions

invalidates the granted warranty.

1.1 General safety

•This appliance complies with

the international security

standards.

•This appliance is not intended

for use by persons (including

children) with reduced physical,

sensory or mental capabilities,

or lack of experience and

knowledge, unless they have

been given supervision or

instruction concerning use

of the appliance by a person

responsible for their safety.

•This appliance can be used

by children aged from 8 years

and above if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

Cleaning and user maintenance

shall not be made by children

unless they are aged from 8

years and above and supervised.

Keep the appliance and its cord

out of reach of children aged

less than 8 years.

•Children should be supervised

to ensure that they do not play

with the appliance.

•If the supply cord is damaged,

it must be replaced by the

manufacturer or its agent or

similarly qualified person in

order to avoid hazard.

•Do not use it if the power

cable or the appliance itself is

damaged. Contact an authorized

service.

•Your mains power supply should

comply with the information

supplied on the rating plate of

the appliance.

•The mains supply of the

appliance must be secured with

a minimum 16 A fuse.

•Do not use the appliance with

an extension cord.

1Important safety and environmental instructions

Vacuum Cleaner / User Manual 5 / EN

•In order to prevent the power

cable from getting damaged,

make sure that it doesn’t get

stuck, twisted or rub against

sharp surfaces.

•Do not touch the appliance or its

plug when it is plugged if your

hands are damp or wet.

•Do not pull the power cable when

unplugging the appliance.

•Do not vacuum flammable

materials and when vacuuming

cigarette ashes make sure that

it got cold.

•Do not vacuum water or other

liquid materials.

•Protect the appliance from rain,

humidity and heat sources.

•Never use the appliance

in or near to combustible

or inflammable places and

materials.

•Unplug the appliance before

cleaning and maintenance.

•Do not dip the appliance or its

cable in water to clean it.

•Check the hose of the appliance

regularly. Do not use if it is

damaged and contact an

authorized service.

•Do not attempt to dismantle the

appliance.

•Only use the original parts or

parts recommended by the

manufacturer.

•The plug must be removed

from the socket-outlet before

cleaning or maintaining the

appliance.

•If heavily used for cleaning dust

such as cement or grout the

dust indicator will lit earlier then

expected, in such case replace

the dust bag even it is empty.

•Do not use the appliance

without filters; otherwise it can

get damaged.

•Keep fingers, hair and loose

clothing from moving parts

and openings whilst using the

vacuum cleaner.

•When vacuuming the stairs,

the appliance should be located

below the user.

1Important safety and environmental instructions

6 / EN Vacuum Cleaner / User Manual

•If your store the package

material, keep it out of the reach

of children.

1.2 Compliance with WEEE

Directive and Disposing of the

Waste Product

This product complies with EU WEEE Directive

(2012/19/EU). This product bears a classification

symbol for waste electrical and electronic

equipment (WEEE).

This symbol indicates that this product

shall not be disposed with other

household wastes at the end of its service

life. Used device must be returned to

offical collection point for recycling of electrical

and electronic devices. To find these collection

systems please contact to your local authorities

or retailer where the product was puchased. Each

household performs important role in recovering

and recycling of old appliance. Appropriate

disposal of used appliance helps prevent potential

negative consequences for the environment and

human health.

1.3 Compliance with RoHS

Directive

The product you have purchased complies with EU

RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the

Directive.

1Important safety and environmental instructions

1.4 Package information

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations. Do not dispose

of the packaging materials together with the

domestic or other wastes. Take them to the

packaging material collection points designated by

the local authorities.

Vacuum Cleaner / User Manual 7 / EN

2.1 Overview

The values which are declared in the markings affixed on your appliance or other printed documents supplied with it represent the values which were obtained

in the laboratories pursuant to the pertinent standards. These values may vary according to the usage of the appliance and ambient conditions.

2Your vacuum cleaner

1. Handle

2. Vacuum adjustment control

3. Hose

4. Telescopic tube

5. Telescopic tube adjustment latch

6. Suction nozzle

7. Parquet/carpet brush

8. Dust container opening latch

9. Hose cap

10. Top lid

11. Dust indicator

12. Power cable winding button

13. Suction power adjustment knob

14. Carriage handle

15. On/Off button

16. Parquet/hard floor brush (VCC34802AB)

17. Turbo brush (VCC34803AD)

2.2 Technical data

Power :

800W

Supply voltage :

220-240V~, 50-60Hz

Sound level :

80 dbA

Dust capacity :

2.1 L

Operating radius :

7.5 m

Dust collecting

Rights to make technical and design changes are

reserved.

9 10 11

13 14

8 / EN Vacuum Cleaner / User Manual

3Usage

3.1 Intended use

The appliance has been designed for household

use and is not suitable for industrial use.

3.2 Attaching/removing the

hose

1. Insert the hose in the coupling on the appliance

and press as far as it will go.

2. To remove the hose press the buttons on the

sides of the hose.

3.3 Attaching/removing the

telescopic tube

1. Attach the telescopic tube (4) to the handle (1).

2. Pull the telescopic tube (4) from the handle (1)

to remove it.

3. Push the telescopic adjustment latch (5) in the

arrow direction and pull the telescopic tube (4)

to adjust its length.

3.4 Attaching/removing the

parquet/carpet brush

You can install/remove the narrow end of the

telescopic tube (4) from/to the parquet/carpet

brush (7).

3.5 Adjusting the parquet/

carpet brush

Perform the following actions on the adjustment

latch located on the parquet/carpet brush (7);

•Use " " position for hard floors and parquet.

•Use " " position for rugs and carpets.

3.6 Operation

1. Plug in the appliance after pulling the power

plug located at the back of the appliance.

2. Press the on/off button (15) to switch on your

appliance.

Vacuum Cleaner / User Manual 9 / EN

3.6.1 Adjusting the suction

power

1. You can adjust the suction power using the

suction power adjustment knob (13) found

on the appliance. Rotating in the clockwise

direction will increase the suction power and

in counterclockwise direction will decrease the

suction power.

2. You can lower the suction power of the parquet

carpet brush by pulling backward the vacuum

adjustment control (2) located on the handle

(1) without the need to use the suction power

adjustment knob (13) found on the appliance.

3.6.2 Dust indicator

Dust indicator (11) indicates the fullness of the

dust bag. When the indicator displays red zone

more than 50%, replace the dust bag. (see 4.1).

3.7 Accessories

Upholstery tool

Suitable for cleaning the floorings,

stair steps, inside of the cars, sofas,

armchairs etc.

Dust brush

Suitable for cleaning the curtains,

and sensitive and fragile objects.

Crevice tool

Suitable for the cleaning of the

surfaces which are difficult to

clean, such as the areas remaining

under the sofas and furniture.

AWARNING:

Do not perform

cleaning tasks using the end part of

the handle (1).

3.8 Additional brushes

3.8.1 Parquet/Hard floor brush

(VCC34802AB)

The hard floor brush (16) was developed for use on

hard floors such as tile, ceramic, parquet, wooden

floors etc.

It prevents potential scratches while cleaning hard

floors thanks to its specially-developed soft hair.

3.8.2 Turbo brush (VCC34803AD)

The turbo brush (17) allows you to clear the hair

on carpets in a faster and more efficient way. Thus

you can even remove the hair -which is hard to

remove such as dog hair or cat hair- easily.

3Usage

10 / EN Vacuum Cleaner / User Manual

3Usage

3.9 Switching off and parking

the appliance

1. Switch off the appliance with the on/off button

(15) and unplug it.

2. Wind the power cable by pressing the power

cable winding button (12).

Vertical parking feature

Insert the parking hook of the parquet/carpet

brush into the parking groove located at the

bottom section of the appliance.

Horizontal parking feature

Insert the parking hook of the parquet/carpet

brush into the parking groove located at the rear

section of the appliance.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Beko Staubsauger Handbücher

Beko

Beko VCC 5424 WI Bedienungsanleitung

Beko

Beko VRT 95929 VI Bedienungsanleitung

Beko

Beko 01M-8911593200-2322-05 Bedienungsanleitung

Beko

Beko BKS 9316 Bedienungsanleitung

Beko

Beko VRS 82740 VF Bedienungsanleitung

Beko

Beko VCO32802AD Bedienungsanleitung

Beko

Beko 01M-8832263200-1022-07 Bedienungsanleitung

Beko

Beko VCO 32801 AF Bedienungsanleitung

Beko

Beko 01M-8817043200-4720-06 Bedienungsanleitung

Beko

Beko VCO 42701 AB Bedienungsanleitung

Beko

Beko 01M-8838033200-1319-04 Bedienungsanleitung

Beko

Beko VCO 6325 AB Bedienungsanleitung

Beko

Beko VRT 71920 VR Bedienungsanleitung

Beko

Beko VCC 50701 AW Bedienungsanleitung

Beko

Beko VCO32801AR Bedienungsanleitung

Beko

Beko 01M-8834453200-2117-06 Bedienungsanleitung

Beko

Beko BKS 1255 T Bedienungsanleitung

Beko

Beko BKS 2420 Bedienungsanleitung

Beko

Beko 01M-8833043200-2517-05 Bedienungsanleitung

Beko

Beko VCC34818WD Bedienungsanleitung

Beko

Beko VCC34118WD Bedienungsanleitung

Beko

Beko VRR 60314 VW Bedienungsanleitung

Beko

Beko VCM 71602 AD Bedienungsanleitung

Beko

Beko BKS 1352 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
