VCO32801AR

Vacuum Cleaner

User Manual

01M-8814423200-3818-01

Please read this manual first!

Dear Valued Customer,

Thank you for selecting this Beko appliance. We hope that you get the best results

from your appliance which has been manufactured with high quality and state-of-the-

art technology. For this reason, please read this user manual and all other provided

documents carefully before using the appliance and keep it as a reference for future

use. If you hand over the appliance to someone else, give the user manual as well.

Follow the instructions by paying attention to all the information and warnings in the

user manual.

Meanings of the Symbols

Following symbols are used in various sections of this manual:

Important information and useful

hints about usage.

AWARNING:

Warnings against

dangerous situations concerning the

security of life and property.

Protection class for electric shock.

This product has been manufactured in environmental friendly modern plants without

giving any harm to the nature.

This product does not contain PCB’s

Vacuum Cleaner / User Manual 3 / EN

CONTENTS

1 Important safety and

environmental instructions 4

1.1 General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.2 Compliance with the WEEE Directive and

Disposing of the Waste Product. . . . . . . . . . . . . . . . 6

1.3 Compliance with RoHS Directive . . . . . . . . . . . 6

1.4 Package information . . . . . . . . . . . . . . . . . . . . . . . 6

1.4 Plug Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Your vacuum cleaner 7

2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2.2 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

3Usage 8

3.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.2 Attaching/removing the hose. . . . . . . . . . . . . . 8

3.3 Attaching/removing the telescopic tube. . . 8

3.4 Attaching/removing the

parquet/carpetbrush. . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.5 Adjusting the parquet/carpet brush . . . . . . . 9

3.6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.7 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.9 Switching off the vacuum cleaner and parking

feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Vertical parking feature . . . . . . . . . . . . . . . . . . . . . . . 10

Horizontal parking feature . . . . . . . . . . . . . . . . . . . . 10

4 Cleaning and care 11

4.1 Emptying the dust container . . . . . . . . . . . . . . 11

4.2 Cleaning the filters. . . . . . . . . . . . . . . . . . . . . . . . 11

4.2.1 Motor protection filter and HEPA filter . . 11

4.2.2 HEPA filter and outlet filter . . . . . . . . . . . . . 12

4.3 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.4 Handling and transportation . . . . . . . . . . . . . 12

5Guarantee 13

4 / EN Vacuum Cleaner / User Manual

This section contains safety

instructions that will help protect

from risk of personal injury or

property damage.

Failure to follow these

instructions invalidates the

granted warranty.

1.1 General safety

•This appliance complies with the

international safety standards.

•This appliance is not intended

for use by persons (including

children) with reduced physical,

sensory or mental capabilities,

or lack of experience and

knowledge, unless they have

been given supervision or

instruction concerning use

of the appliance by a person

responsible for their safety.

•This appliance can be used

by children aged from 8 years

and above if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

1Important safety and environmental instructions

Cleaning and user maintenance

shall not be made by children

unless they are aged from 8

years and above and supervised.

Keep the appliance and its cord

out of reach of children aged

less than 8 years.

•Children should be supervised

to ensure that they do not play

with the appliance.

•If the supply cord is damaged,

it must be replaced by the

manufacturer or its agent or

similarly qualified person in

order to avoid hazard.

•Do not use it if the power

cable or the appliance itself is

damaged. Contact an authorized

service.

•Your mains power supply should

comply with the information

supplied on the rating plate of

the appliance.

•The mains supply of the

appliance must be secured with

a minimum 13 A fuse.

•Do not use the appliance with

an extension cord.

Vacuum Cleaner / User Manual 5 / EN

1Important safety and environmental instructions

•In order to prevent the power

cable from getting damaged,

make sure that it doesn’t get

stuck, twisted or rub against

sharp surfaces.

•Do not touch the appliance or its

plug when it is plugged in if your

hands are damp or wet.

•Do not pull the power cable

when unplugging the appliance.

•Do not vacuum flammable

materials and when vacuuming

cigarette ashes make sure that

it got cold.

•Do not vacuum water or other

liquid materials.

•Protect the appliance from rain,

humidity and heat sources.

•Never use the appliance

in or near to combustible

or inflammable places and

materials.

•Unplug the appliance before

cleaning and maintenance.

•Do not dip the appliance or its

cable in water to clean it.

•Check the hose of the appliance

regularly. Do not use if it is

damaged and contact an

authorized service.

•Do not attempt to dismantle the

appliance.

•Only use the original parts or

parts recommended by the

manufacturer.

•The plug must be removed

from the socket-outlet before

cleaning or maintaining the

appliance.

•If heavily used for cleaning dust

such as cement or grout the

dust indicator will lit earlier then

expected, in such case replace

the dust bag even it is empty.

•Do not use the appliance

without filters; otherwise it can

get damaged.

•Keep fingers, hair and loose

clothing from moving parts

and openings whilst using the

vacuum cleaner.

•When vacuuming the stairs,

the appliance should be located

below the user.

6 / EN Vacuum Cleaner / User Manual

•If you keep the packaging

materials, store them out of the

reach of children.

1.2 Compliance with the WEEE

Directive and Disposing of the

Waste Product

This product complies with EU WEEE Directive

(2012/19/EU). This product bears a classification

symbol for waste electrical and electronic

equipment (WEEE).

This product has been manufactured

with high quality parts and materials

which can be reused and are suitable

for recycling. Do not dispose of the

waste product with normal domestic

and other wastes at the end of its service life. Take

it to the collection center for the recycling of

electrical and electronic equipment. Please consult

your local authorities to learn about these

collection centers.

1.3 Compliance with RoHS

Directive

The product you have purchased complies with EU

RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the

Directive.

1.4 Package information

Packaging materials of the product are

manufactured from recyclable materials

in accordance with our National

Environment Regulations. Do not

dispose of the packaging materials together with

the domestic or other wastes. Take them to the

packaging material collection points designated by

the local authorities.

1Important safety and environmental instructions

1.4 Plug Wiring

The moulded plug on this appliance incorporates

a 13 A fuse. Should the fuse need to be replaced

an ASTA approved BS1362 fuse of the same rating

must be used. Do not forget to refit the fuse cover.

In the event of losing the fuse cover, the plug must

not to be used until a replacement fuse cover has

been fitted. Colour of the replacement fuse cover

must be the same colour as that visible on the pin

face of the plug Fuse covers are availabe from any

good electrical store.

•Fiting a different plug

•As the colours of the wires in the mains lead

of this appliance may not correspond with the

coloured markings identifying the terminals on

your plug, proceed as follows:

•Brown cable = L (Live)

•Blue cable = N (Neutral)

•Green/yellow cable must be connected to

ground (E) line

•With the alternative plugs a 13 A fuse must be

fitted either in the plug or adaptore or in the

main fuse box. If in doubt contact a qualified

electrician.

Vacuum Cleaner / User Manual 7 / EN

2.1 Overview

2Your vacuum cleaner

1. On/Off button

2. Power cable winding button

3. Dust container

4. Suction nozzle

5. Hose cap

6. Hose

7. Dust container removal button

8. Parquet/carpet brush parking hook

9. Brush adjustment latch

10. High performance parquet/carpet brush

11. Telescopic tube adjustment latch

12. Telescopic tube

13. Vacuum control

14. Handle

15. Top lid

2.2 Technical data

Supply voltage :

220-240 V~, 50-60 Hz

Power :

800 W

Operating radius :

7.5 m

Energy class :

Annual consumption :

28 kwh/year

Dust collecting on

carpet :

Dust collecting on

hard surface :

Dust ejection :

Sound :

76 dB(A)

Rights to make technical and design changes are

reserved.

The values which are declared in the markings affixed on your appliance or other printed documents supplied with it represent the

values which were obtained in the laboratories pursuant to the pertinent standards. These values may vary according to the usage

of the appliance and ambient conditions.

6 3 1045

1314

8 / EN Vacuum Cleaner / User Manual

3Usage

3.1 Intended use

The appliance has been designed for household

use and is not suitable for industrial use.

3.2 Attaching/removing the

hose

1. To attach the hose (6), push the hose cap (5) in

the direction of arrow until it is aligned with the

housing (you will hear a click).

•Projecting parts on the hose cap should be

aligned correspondingly.

2. To remove the hose (6), press the unlocking

buttons on the sides of the hose cap (5) and pull

the hose.

3.3 Attaching/removing the

telescopic tube

1. Attach the telescopic tube (12) to the handle

(14).

2. Pull the telescopic tube (12) from the handle

(14) to remove it.

3. You can extend or shorten the telescopic tube

(12) by sliding the telescopic tube adjustment

latch (11) back and forth.

3.4 Attaching/removing the

parquet/carpet brush

1. Attach the telescopic tube (12) to the parquet/

carpet brush (10) in the arrow direction.

2. You can remove the telescopic tube (12) from

the parquet/carpet brush (10) by pulling it.

Vacuum Cleaner / User Manual 9 / EN

3.5 Adjusting the parquet/

carpet brush

Press the adjustment latch (9) located on the

parquet/carpet brush (10) and;

•Vacuum on firm ground and parquet; extend the

brush before vacuuming.

•Vacuum on carpets and rugs; retract the brush

before vacuuming.

3.6 Operation

1. Plug in the appliance after pulling the power

plug located at the back of the appliance.

WARNING:

Stop pulling the

appliance cable when it comes to

the yellow mark located on it. After

the yellow mark, the red mark will

come. Do not pull any more after

reaching the red mark.

2. Press the on/off button (1) to switch on your

appliance.

3.7 Accessories

Accessories have been designed in one piece to

save space and provide practical use.

Upholstery tool

Suitable for cleaning the floorings,

stair steps, inside of the cars, sofas,

armchairs etc.

Dust brush

Suitable for cleaning the curtains,

and sensitive and fragile objects.

Crevice tool

Suitable for the cleaning of the

surfaces which are difficult to

clean, such as the areas remaining

under the sofas and furniture.

AWARNING:

The crevice tool must

be adjusted to remain outside.

•Pull the accessory to remove it when the process

is complete.

AWARNING:

Do not make cleaning

by using the handle's (14) end part.

3Usage

10 / EN Vacuum Cleaner / User Manual

3Usage

3.9 Switching off the vacuum

cleaner and parking feature

1. Switch off the appliance with the on/off button

(1) and unplug it.

2. Press the cable winding button (2) to wind the

cable inside the appliance.

Vertical parking feature

Attach the hook of the parquet/carpet brush (8) to

the parking groove located at the bottom part of

the appliance.

Horizontal parking feature

Attach the hook of the parquet/carpet brush (8) to

the parking groove located at the rear side of the

appliance.

Andere Handbücher für VCO32801AR

Inhaltsverzeichnis

Andere Beko Staubsauger Handbücher

Beko

Beko BKS 9316 Bedienungsanleitung

Beko

Beko VCO 6325 FD Bedienungsanleitung

Beko

Beko 01M-8911593200-2322-05 Bedienungsanleitung

Beko

Beko VRT 51225 VB Bedienungsanleitung

Beko

Beko VCO 4320 WR Bedienungsanleitung

Beko

Beko VRT 61814 VR Bedienungsanleitung

Beko

Beko VRR 81214 VW Bedienungsanleitung

Beko

Beko 01M-8816523200-4720-03 Bedienungsanleitung

Beko

Beko VCO 6325 AB Bedienungsanleitung

Beko

Beko BKS 2422 Bedienungsanleitung

Beko

Beko VCC34118WD Bedienungsanleitung

Beko

Beko VCO 42701 AB Bedienungsanleitung

Beko

Beko VCC 5325 AR Bedienungsanleitung

Beko

Beko 01M-8816513200-4319-02 Bedienungsanleitung

Beko

Beko VCO 62607 AD Bedienungsanleitung

Beko

Beko VRT 70925 VB Bedienungsanleitung

Beko

Beko SD 8041 K Bedienungsanleitung

Beko

Beko VCC 50701 AW Bedienungsanleitung

Beko

Beko VRR 60314 VW Bedienungsanleitung

Beko

Beko 01M-8814353200-2621-03 Bedienungsanleitung

Beko

Beko BKS 9218 Bedienungsanleitung

Beko

Beko VRT 74225 VI Bedienungsanleitung

Beko

Beko VRR 70214 VB Bedienungsanleitung

Beko

Beko RS 8034 HM Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
