Hardware User’s Manual

Megapixel Day & Night

Mini Dome Network Camera

Quality Service Group

MD-500Ap & MD-300N Series

Review History:

1. Separate User Manual into HW and SW.

2. Merge MD-500Ap/MD-400Ap/MD-300Ap/MD-200Ap/MD-300Np/MD-200Np/MD-130Np

into this User Manual.

Product name:

Network Camera (MD-100A series)

Release Date:

2012/05

Manual Revision:

V3.0

Web site:

www.brickcom.com

Email:

support@brickcom.com

info@brickcom.com

Table of Contents

Before You Use This Product................................................................................1

FCC Warning...................................................................................................1

Regulatory Information........................................................................................2

Package Contents.............................................................................................3

Mini Dome Network Camera Overview ....................................................................4

Device Appearance Description.............................................................................7

Installation ......................................................................................................8

Hardware Installation...........................................................................................................8

Camera Connection...........................................................................................................11

LED Behavior.....................................................................................................................13

System Requirements........................................................................................................15

Software Installation...........................................................................................................16

EasyConfig ........................................................................................ 24

Before You Use This Product

In many countries, there are laws prohibiting or restricting the use of surveillance

devices. This Network Camera is a high-performance, web-ready camera which can be

part of a flexible surveillance system. It is the user’s responsibility to ensure that the

operation of this camera is legal before installing this unit for its intended use.

Upon opening the product’s package, verify that all the accessories listed on the

“Package Contents” are included. Before installing the Network Camera, read the

warnings in the “Quick Installation Guide” to avoid misuse. When installing the

Network Camera, carefully read and follow the instructions in the “Installation” chapters

to avoid damages due to faulty assembly or installation.

FCC Warning

This device complies with Part 15 of FCC rules.

Operation is subject to the following two conditions;

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operations.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance 20cm

between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

The availability of some specific channels and/or operational frequency bands are country

dependent and are firmware programmed at the factory to match the intended destination.

The firmware setting is not accessible by the end user.

- 3 -

Package Contents

Please check to make sure that the product package contains all the accessories listed below.

a. MD-500A Series/ MD-300Np Series

b. Product CD

c. Adjusting Lens Tool

d. Allen Key

e. Warranty Card

f. Screw Bags(2pcs)

g. Dry Bag / Double-Sided Tape

h. Alignment Sticker

i. Easy Installation Guide

j. Mounting Adapter

k. TV out Connector Cable (Optional)

l. M12 Connector(Optional)

- 4 -

Product Comparison

Model Name

Lens

Focal

Length

Cable Type

Power Input

USB port

for 3G/ 4G

DC12V

PoE

802.3af

M12

MD-500A

Series

MD-500Ap-A1

f=4.00mm

RJ45, DC12V



MD-500Ap-A2

f=3.60mm

RJ45, DC12V



MD-500Ap-B1

f=4.00mm

M12 Connector



MD-500Ap-B2

f=3.60mm

M12 Connector



MD-500Ap-C1

f=4.00mm

RJ45,

USB Connector



MD-500Ap-C2

f=3.60mm

RJ45, USB

Connector



MD-300N

Series

MD-300Np-A1

f=4.00mm

RJ45, DC12V



MD-300Np-A2

f=3.60mm

RJ45, DC12V



MD-300Np-B1

f=4.00mm

M12 Connector



MD-300Np-B2

f=3.60mm

M12 Connector



MD-300Np-C1

f=4.00mm

RJ45,

USB Connector



MD-300Np-C2

f=3.60mm

RJ45,

USB Connector



*This table compliant with MD-500A Series, MD-400A Series, MD-300A Series, MD-200A

Series, MD-130A Series,MD-300N Series, MD-200N Series, MD-130N Series.

- 5 -

Mini Dome Network Camera Overview

The Brickcom MD-500A series/ MD-300N series is a mini dome network camera designed for

outdoor use. MD-500A series/ MD-300N series has a compact and stylish design, also

provides Full HDTV video (1080p @ 30fps). IP67 certified, IK10 vandal-proof and EN50155

Anti Vibration and Shock, the MD-300A & MD-500A Series is perfect for outdoor surveillance,

and surveillance in buses, trains, subway cars and emergency vehicles.

The MD-500A series/ MD-300N series is designed to provide end users with high quality

video feed for an easily accessible security system. By offering H.264/M-JPEG/MPEG-4 triple

codec compression, it is able to offer a flexible system which does not require high bandwidth

and storage capabilities. The internal micro SD/SDHC memory card slot allows for local

storage, which prevents data loss if the data connection is lost. The MD-300A & MD-500A

Series comes with a wide-angle lens, and Pan 35°/ Tilt 0-90° / Rotation 180° wide angle

adjustment, allowing a wide open view for maximum coverage.

Different from other dome cameras, MD-500A series/ MD-300N series supports

exchangeable lenses for different conditions. Moreover, MD-500A series/ MD-300N

series supports 3G/4G (WiMAX/ LTE) wireless connectivity which allows the camera to

transmit video data over wireless networks.

The MD-500A series/ MD-300N series is designed for easy installation. With the BNC TV-Out

Connector, the camera can be connected to a monitor which makes it easier for installers to

adjust the picture focus while setting up the camera. The MD-500A series/ MD-300N series is

- 6 -

equipped with a special designed mounting adapter and can be installed on a curved surface.

The camera supports different power inputs such as PoE 802.3af, M12 and DC12Vs

- 7 -

Device Appearance Description

(*) These are optional features. Please refer to the Product List for the full list of

optional features that are available for this product.
