Colortrac SmartLF Cx 40M Bedienungsanleitung

CxTSG

Colortrac Ltd

Page: 1 of 17

Issue 4

Cx / Cx+ Troubleshooting Guide

Date: 11/07/13

This is a confidential controlled document and is the property of Colortrac Ltd.

It is not to be copied or reproduced in part or whole. It is intended for staff to read.

Cx Cx+ Troubleshooting Guide

Page 2 of 17

SmartLF Cx / Cx+ Scanners

Troubleshooting Guide

Issue 4

©Colortrac Ltd 2013

The product and the contents of this publication may be changed without prior notification.

Colortrac Ltd makes every effort to ensure this publication is free from error. Misprints, errors

or quality observations should be reported to Technical Support, Colortrac Ltd.

Colortrac Ltd shall not be liable for any damages, errors, issues or events that result from the

use of the equipment or this manual.

No part of this product or publication may be reproduced,

copied or transmitted in any form or by any means without

permission from:

International Technical Support Manager

Colortrac Ltd.

Units 3 –5 Brunel Court.

Burrel Road.

St Ives,

Huntingdon,

Cambridgeshire,

PE27 3LW.

United Kingdom.

Tel: +44 (0)1480 464618

Fax: +44 (0)1480 464620

www.colortrac.com

Cx Cx+ Troubleshooting Guide

Page 3 of 17

OVERVIEW

Common Fault

Possible Solution

Page

1. Noise When Scanning

Noisy Motor

Noisy Roller

Older Style Pinch Roller Plungers

Loose Belt

Loose Motor Drive Pulley

2. Image Does Not Look As It Should

Including: Lines On Image And Colour

Differences

Bad Normalisation

Out Of Stitch

Dirty / Scratched CIS Glass

Faulty CIS / Main Board

Main Drive Pulley

Lines On Image

CIS Tolerance

Firmware

Reset Flash to Factory

3. Error Messages

10006

10018

10022

C114

C20

Normalisation Error 14

4. USB Communication Problems

USB Cable

PC USB Port

Main Board

5. Blank Or No Display

Ribbon Cable From Main Board

Control Board

Main Board

Control Board ID Chip

PSU

6. Media Not Being Taken Into Scanner

Control Board

Paper Sensors

Paper Sensor Cable

Main Board

7. Miscellaneous Issues, Including:

Start / Stop During Scan.

Won’t scan highlighter pen.

Noise from fan.

Stitch values vary during a scan.

Scanned Image Wrong Width.

Extra boarder around a scan.

Stuck in ‘Initialise’.

Fringing on B&W horizontal lines.

Scanner locks up / hangs.

Black Scans.

Scanner keeps loosing stitch values.

Scanned image wrong length.

Cx Cx+ Troubleshooting Guide

Page 4 of 17

References within this Instruction Manual:

The Cx / Cx+ Service Manual can be found on:

www.colortracsupport.co.uk

User: colortrac

Password: available on request.

The firmware, driver and software updates can be found on:

www.colortrac.com/support/support_downloads.htm

Cx Cx+ Troubleshooting Guide

Page 5 of 17

1. Noise When Scanning

Fault

Possible Solution

Loud noise when scanning during operation.

1. Noisy Motor

2. Noisy Roller Bearings

3. Older Style Pinch Roller Plungers

4. Loose Belt

5. Loose Motor Drive Pulley

1.1 SUGGESTED PROBLEM AREAS

Cx Cx+ Troubleshooting Guide

Page 6 of 17

1.2 FLOW GRAPH

Cx Cx+ Troubleshooting Guide

Page 7 of 17

2. Image Does Not Look As It Should

Fault

Possible Solution

Image does not look as it should.

1. Bad normalisation

2. Out of Stitch

3. Dirty / Scratched CIS Glass

4. Faulty CIS / Main Board

5. Main Drive Pulley

6. Lines On Image

7. CIS Tolerance

8. Firmware

9. Reset Flash To Factory

2.1 IMAGE EXAMPLES

Original

Scanned Image

1. Bad image quality with washed out or

incorrect colours is normally down to the

scanner needing normalisation.

Insert the white target into the scanner with

the matt side face up.

Open the Utilities program, and on the front

page, press Full Normalisation and allow the

process to complete.

2. When the image between 2 CIS points has a

step, it is because the scanner needs to be

stitched, an electrical adjustment for making

the scanner see an image equally across all

the CIS arrays.

Open the Utilities program and stitch the

scanner as described in the service manual.

Cx Cx+ Troubleshooting Guide

Page 8 of 17

3. Fine lines down the image can be either dirt1or a scratches2on the glass or dirt being picked up

from the paper tray and dragged through. If the line is contineous through the scan, clean the glass

and re-normalise. If it starts and appears to disapear further down the scan, clean the paper tray

and try again. Scratched glass needs replacing.

Cx Cx+ Troubleshooting Guide

Page 9 of 17

Black Area

Black Section

4. A black area in an image can be down to CIS, cable or Main Board. A black area3completely over

one CIS can be either the CIS, the cable or the main board, where as a black section4of a CIS is

more likely to be the cable and / or CIS; the main board is not as likely. Easiest thing to try first, in

all cases, is the cable. Re-seat it at the Main Board end, making sure there are no broken cores or

damage visible. A CIS can be swapped within the CIS Mounting Bracket to check to see if the

problem is a CIS, or to move the faulty CIS to the end of the scanner if the customer does not use

the full width of the scanner. The Main Board is the next easiest thing to swap to see if the problem

goes away. Refer to service manual for procedures.

5. Early versions of the software created completely black scans of a 0mb file size. This was a bug in

the software. Make sure the software is up to the latest version from the Colortrac website:

http://www.colortrac.com/support/support_downloads.htm

Cx Cx+ Troubleshooting Guide

Page 10 of 17

Distorted Start of Scan

Colourmatch

6. A distorted image at the beginning of a scan,

or at the point where the scanner has stopped

and started during a scan, is down to the

Motor Drive Pulley being loose on the motor,

or the main timing belt being loose.

See service manual procedures.

7. Colour differences between 2 CIS can be

down to the scanner needing normalisation,

or the glass or paper hold down roller not

seating properly over the CIS, make sure

there is correct and even gap between the

paper hold down rollers and glass. Some

times the colour imbalance can be down to

the tolerance between 2 CIS, which is

common in all CIS scanners.

8. Some times image problems, particually if the image looks currupt and completely unrecognisable,

can be solved by resetting the scanner. Use the "Reset Flash to Factory" in the passworded area

of the utilities program to do this, making sure you record the motor speed and stitch values before

running this process, and re-insert them again afterwards. Normalisation completes the process.
