CYP CH-507TXWPUS Bedienungsanleitung
DRAFT
CH-507TXWPUS & RXWPUS
HDMI over CAT5e/6/7 Wall-Plate Extender with IR/
RS232/LAN/PoE
Operation Manual
Operation Manual
DRAFT
DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version 1.0 December 2010
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 30/09/13 Preliminary Release
DRAFT
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Hardware Description ........................... 3
6.1 Transmitter.........................................3
6.2 Receiver ............................................4
6.3 RS-232 Pin Denitions........................5
7. Connection Diagram ............................ 6
8. Specications ........................................ 7
8.1 CAT5e/6/7 Cable Specication .....8
DRAFT
1
1. INTRODUCTION
The HDMI over CAT5e/6/7 Wall-Plate Extender can transmit and
receive uncompressed audio/video over a single run of CAT5e/6/7
cable up to 100m with PoE, IR, RS232 and LAN. of a data transmission
rate of 100Mbps. A True HDBaseT 5Play solution to make your home or
ofce more efcient and easy with control.
2. APPLICATIONS
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. PACKAGE CONTENTS
• 1 x HDMI to CAT5e/6/7 with IR/RS232/LAN/PoE Transmitter
• 1 x CAT5e/6/7 to HDMI with IR/RS232/LAN/PoE Receiver
• 1 x IR Blaster
• 1 x IR Extender
• 1 x 24V/1.25A DC Power Supply
• 1 x Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source equipment such as DVD/Blu-ray(4K2K) player and
HDMI equipped output display(TV/display).
DRAFT
2
5. FEATURES
• HDMI with 3D, 4Kx2K supported, HDCP and DVI compliant
• Supports HDCP repeater and CEC bypass
• Simultaneous transmission of uncompressed data over a single
CAT5e/6/7 cable up to 100m/328ft
• HDBaseT 5Play convergence: uncompressed high denition Video
and Audio, LAN serving, Power over Ethernet and RS232/IR Controls
• Uncompressed video support up to 3840x2160@30Hz or
4096x2160@24Hz
• High denition audio support up to LPCM 7.1CH, Dolby TrueHD,
Dolby Digital Plus and DTS-HD Master Audio
• US 2 gang wall-plate design
DRAFT
3
6. HARDWARE DESCRIPTION
The following sections describe the hardware components of the unit.
6.1 Transmitter
LAN
HDMI IN
RS-232 IN
POWER LINK
IR 1
Blaster
IR 2
Extender
DC 24V
6 7 8
2
1
3
5
4
1RS-232 IN: This slot is connect with D-Sub 9-pin cable from PC/
Laptop device RS-232 commands sending.
2LAN: Connect to an active network for LAN serving and Telnet/
Web GUI control.
When the transmitter or any compatible LAN equipped receivers
are connected to a network, this allows the network access
(including internet access if available) to be shared between the
transmitter and all connected receiver. Connect any Ethernet
equipped device e.g. a Smart TV or games console to the LAN
port of a receiver for that device to share the network/internet
access.
3DC 24V: Connect the power adaptor included in the package
and then connect to AC power to activate the device..
DRAFT
4
4POWER LED: This LED will illuminate when the device is connected
to a power supply.
5LINK LED: This LED will illuminate when the both CAT5e/6/7 input
and output signal is connected.
6IR 2 Extender: This slot is to connect with the IR Receiver cable
included in the package for IR signal receiving.
7IR 1 Blaster: This slot is to connect with the IR Blaster cable included
in the package for IR signal transmitting.
8HDMI IN: This slot is to connect with HDMI source equipment such
as DVD/Blu-ray player with HDMI source signal.
6.2 Receiver
LAN
HDMI OUT
RS-232 OUT
POWER LINK
IR 1
Extender
IR 2
Blaster
5 6 7
2
1
4
3
1LAN: Connect to an active network for LAN serving and Telnet/
Web GUI control.
When the transmitter or any compatible LAN equipped receivers
are connected to a network, this allows the network access
DRAFT
5
(including internet access if available) to be shared between the
transmitter and all connected receivers. Connect any Ethernet
equipped device e.g. a Smart TV or games console to the LAN
port of a receiver for that device to share the network/internet
access.
2RS-232 OUT: This slot is to connect with D-Sub 9-pin cable from
device equipment for receiving RS-232 commands
3POWER LED: This LED will illuminate when the device is connected
to a power supply.
4LINK LED: This LED will illuminate when the both CAT5e/6 input and
output signal are connected
5IR 1 Extender: This slot is to connect with the IR Receiver cable
included in the package for IR signal receiving.
6IR 2 Blaster: This slot is to connect with the IR Blaster cable included
in the package for IR signal transmitting.
7HDMI OUT: This slot is to connect with HDMI TV/monitor for display
HDMI input source signal.
6.3 RS-232 Pin Denitions
Pin Dene TX/RX
1 N/C
2TxD/RxD
3RxD/TxD
4 N/C
5 GND
6 N/C
7 N/C
8 N/C
9 N/C
