CYP PU-106 Bedienungsanleitung
OPERATION MANUAL
PU-106
v1.3 HDMI over CAT6 Extender
Set with IR Pass-through
PU-106_Manual-EN.indd 1 26/04/2011 12:50:05
Table of Contents
1. Introduction 1
2. Features 1
3. Package Contents 1
4. Operation Controls and Functions 2
4.1 Front Panel Diagram 2
4.2 Rear Panel Diagram 3
5. Connection Diagram 4
6. Specications 4
PU-106_Manual-EN.indd 2 26/04/2011 12:50:19
Page 1
1. Introduction
All the PUMA, HDMI over CAT5e/6 transmitters and receivers are the perfect solution
to extend HDMI signals via CAT cabling up to 40m. The PU-106 also allows you to use
your existing Remote Control to control your device with the included IR Receiver &
Blaster.
2. Features
• v1.3 HDMI, HDCP 1.1 and DVI 1.1 compliant.
• HDMI over CAT6 Extender Set.
• Resolutions supported: PC - VGA to WXGA; HDTV - 480i to 1080p plus
1080p24fps.
• High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio plus LPCM.
• Compatible with CAT-5E and CAT-6 cables. CAT-6 is recommended for better
performance.
• Supports CEC functions.
• Supports ‘Deep Colour’ (10 & 12 bit).
• Equalises and recovers incoming TMDS data before re-transmitting to ensure
optimum signal quality.
• Supports xvYCC
• Supports 3D signals
3. Package Contents
• HDMI to CAT6 Transmitter.
• 5V DC power supply adaptor.
• Operation Manual.
PU-106_Manual-EN.indd 1 26/04/2011 12:50:33
Page 2
4. Operation Controls and Functions
4.1 Front Panel
1. HDMI input: Connect the HDMI input port to the HDMI or DVI output of your
source equipment such as DVD player or set-top-box.
2. Power: Plug the 5VDC power supply into the unit and connect the adaptor to AC
wall outlet. (1) power adaptor is required for both Transmitter box and receiver box,
the other box can select internal power supply.
3. HDMI output: Connect the HDMI output port to the HDMI or DVI output of your
displayer such as HD TV or HD monitor.
1 32
POWER 5V
HDMI INPUT
IR
Transmitter
POWER 5V IR
Receiver
HDMI OUTPUT
PU-106_Manual-EN.indd 2 26/04/2011 12:50:34
Page 3
4.2 Rear Panel
1. DDC input/output: Connect the DDC output of 106TX to the DDC input of the
receiver unit using CAT-6 cable.
2. Video input/output: Connect the video output to the video input of the receiver
unit using CAT-6 cable.
Note:
1. Cable tested with CAT-6E / 23AWG / Solid and therefore, cable with dierent
specication may result in dierent distance.
2. Cable distance tested with equipment PS3 20G, 37” Philips 8 bit LCD TV and 37”
Samsung 12 bit LCD TV.
3. Figures provided in this manual are reference gures only, actual gures may
depend on source and display use with cable specication.
1 1
2
DDC VIDEO
CAT6 OUTPUT
VIDEO DDC
CAT6 INPUT
PU-106_Manual-EN.indd 3 26/04/2011 12:50:34
Page 4
5. Connection Diagram
Input Port
Transmitter: 1x HDMI female port, 1x IR jack,
Receiver: 2 x CAT5e/6, 1 x IR Jack
Output Port
Transmitter: 2 x CAT5e/6, 1 x IR Jack
Receiver: 1x HDMI female port, 1x IR jack
Power Supply 2 x 5V/2.6A DC (US/EU standards, CE/FCC/UL
certied)
Dimensions (mm) 50(W) x 62(D) x 23(H)
Weight (g) 340
Chassis Material Aluminium
Silk Skin Colour Black
Operating Temperature Operating from 0°C ~ 40°C
6. Specications
PU-106_Manual-EN.indd 4 26/04/2011 12:50:39
Notes:
PU-106_Manual-EN.indd 5 26/04/2011 12:50:39
www.cypeurope.com
PU-106_Manual-EN.indd 6 26/04/2011 12:50:53
