CH-U330TX & RX

4K2K/HDCP2.2 Multi-Function Extender with video

over IP and KVM

Operation Manual

IP-6000TXRX

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of ﬁ re,

electrical shock and injury to persons.

• To prevent ﬁ re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufﬁ cient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 23/11/15 Preliminary Release

RDV2 26/04/16 1. Add Ethernet requirements

2. Add Web Link Pair Selection

and Dip Switch Table

3. Revised HDMI output resolution

4. Update Audio table

CONTENTS

1. Introduction...............................................................1

2. Applications..............................................................1

3. Package Contents ...................................................1

4. System Requirements...............................................2

5. Features.....................................................................2

6. Operation Controls and Functions..........................3

6.1 Transmitter ...........................................................3

6.1.2 Rear Panel.........................................................5

6.2 Receiver ...............................................................6

6.2.2 Rear panel ........................................................8

7. WebGUI ....................................................................9

8. Connection Diagram .............................................15

9. Support Timing & Audio Table ..............................16

10. Web Link Pair Selection and Dip Switch Table...20

11. Speciﬁ cations .......................................................21

1. INTRODUCTION

The 4K2K video and audio extender is multi-function extender supports

up to 4K2K ultra high-deﬁ nition signals transmission. This Transmitter and

Receiver solution is developed for any household and/or commercial

environment. The input interfaces are HMDI and VGA, further, the DVI

interface is compliant. The video and audio are capable to transmit

through IP. The transmission distance is 100m through single switching

hub, the distance could be extended further once every 100m install

with switching hub which offering convenience to share data and

set up Receiver apart. Install with compatible Gigabyte switching

hub, the transmission rate will up to 1 Gigabyte. Furthermore, this pair

of devices includes extra functions like RS232 & IR pass through, line-

out and microphone features that allows user to enjoy control over

distance and audio sound over favor audio equipment. Moreover,

the device allowing user with cascade with the same family type of

device to extend the transmission distance up to as long as it demand

and without signal loss or delay. For easily operation, the OSD is

available plus WebGUI, on-panel control. The video resolution supports

up to 4K2K@30Hz for high deﬁ nition display.

2. APPLICATIONS

• HDMI, USB, Audio, RS-232 & IR Extender

• Broadcasting system over single CAT5e/6

• Multimedia display and multi-data sharing

• Long distance data sending with cascade

• Matrix network system

• System control over RS-232 and equipment control over IR

• KVM control

3. PACKAGE CONTENTS

• HDMI/USB/RS-232/IR over single CAT5e/6 Transmitter

• HDMI/USB/RS-232/IR over single CAT5e/6 Receiver

• 5V/2.6A DC Power Adaptor x 2

• IR Blaster Cable x 2

• Operation Manual

4. SYSTEM REQUIREMENTS

• Input HDMI, VGA and USB source equipment such as DVD, Blu-ray

player and PC/Notebook with connection cables.

• Output display such as HDTV, monitor and active speaker or

ampliﬁ er with connection cables.

• Gigabit Ethernet network is required.

• Gigabit Ethernet switches must support “Jumbo Frames” and “IGMP

Snooping”.

• 8K Jumbo frame preferred.

5. FEATURES

• HDMI with 4Kx2K supported, HDCP 2.2 compliant

• Supports 1 HDMI and 1 VGA inputs

• Supports video and audio transmission over IP

• Supports input resolution of HDTV up to 4K2K@60Hz YUV 4:2:0 or

4K2K@30Hz YUV 4:4:4

• Supports output resolution up to 4K2K@30Hz YUV4:2:0

• Supports pass-through of audio formats of PCM 2CH, Dolby digital

5.1, DTS

• Supports bitstream data for data transmit over IP

• Supports audio line in for input audio to Transmitter and line out to

earphone

• Supports microphone in on Receiver

• Supports USB keyboard and mouse for easily operation

• Device could be controlled via OSD, WebGUI and on panel control

• Supports IR and RS232 bypass

• Compliant with DVI source

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter

RS232 LINK PAIR

SEL

BLASTER

POWER

LINK

MODELINK

VIDEO VGA BYPASS

1 2 3 4

1 2 3 4 5 6 7 8 9

1POWER LED: Connects with 5V power, the power indicator will

ﬂ ash in blue once power on and illuminate constantly in blue after

power on the unit.

2LINK LED:

a. When Transmitter disconnects with Receiver or power on, the

orange LED indicator will not illuminate.

b. When Transmitter connects with Receiver and get link without

source connection, the LINK LED indicator will ﬂ ash in orange.

c. When Transmitter connects with Receiver and get source

connection, the indicator will illuminate constantly in orange.

3RS232: This slot is to connect with D-Sub 9-pin female null modern

cable from PC’s system, the RS-232 command will pass through

from Transmitter to Receiver or Receiver to Transmitter. The default

baud rate is setting at 115200. For multicast scenario, every single

Receiver unit can pass through RS-232 command to Transmitter.

Further, Transmitter is able to pass through RS-232 to all Receivers

on same channel.

4IR Blaster: This slot is to connect with IR Blaster cable included in

the package for IR signal emitting and controlling the HDMI input

source equipment such as Blu-ray player. For multicast scenario,

the IR signal is able to transmit to all Receivers on same channel.

5IR: This IR window is for receiving the remote control signal and

sending it to Receiver side for IR signal blast out.

6LINK PAIR SEL: This dip switch allows user with matrix setting for

link up to 16 pairs of the devices with single IP router. Each pair

must have the same dip switch setting in order to pair to the right

device setting. The factory default setting is at 0000. Please reboot

Transmitter and Receiver after selecting.

7Video LINK: The link status will be disabled and enable after press

button.

Quick Function Keys:

1. Reset to default (auto IP): Presses Link button and release

the button until Power and Link LED indicator ﬂ ashing. Then

reconnects the power,the unit will goes to auto IP mode. The IP

will be assigned automatically by Transmitter. Please note that

the Transmitter and Receiver unit shall at same Network or the

connection between Transmitter and Receiver will fail.

2. Loopback function disabled: presses the link button for three

seconds, the loopback function will be disabled.

8Video MODE: Selects to video mode for streaming data. Please

continue to press this button for 3 seconds to setting Anti-Dither

mode 1 bit, 2 bit, or off for ATI Graphic card. Anti-Dithering Mode

is design to provide dithering output. Dithering output is used

to make coloring looks better than it's original color depth. This

presents great difﬁ culty for Video Compression to maintain low

bandwidth even if the source display seems static. If the source

content does not generate dithering output, please turn off

this function or it will create a blocking effect. The video mode

improves live video smoothly. Normally, this extender set has

capability to automatically ﬁ nal tune the live video. It is require to

access to video mode for further setting once video come with

slightly latency.

9VGA BYPASS: Connects with VGA terminal block to send video to

display in order to monitor the video content simultaneously.

6.1.2 Rear Panel

ETHERNET

LINE

OUT

AUDIO

HDMI IN VGA IN

VIDEO

SELECT

DC 5VUSB IN

1 2 3 4 5 6 7 8

1Ethernet: Connects with Hub or router for sending data to Receiver.

2HDMI IN: Connects with input source such as DVD or Blu-ray player

with connection cable.

3VIDEO SELECT: Select source type, source type either HDMI or VGA.

Please reboot the system once select new source type.

4VGA IN: Connects with VGA input source such as PC.

5AUDIO LINE IN: Connect from audio source equipment with 3.5mm

phone jack cable for audio signal sending to Receiver side.

6AUDIO LINE OUT: Connect to active speaker or Line in microphone

of input sound from Receiver end.

7USB IN: Connect with PC for loading Receiver’s USB for data

transmits to Transmitter over IP.

8DC 5V: Connects with adopter supplied in the package to power

on the device.

6.2 Receiver

RS232 LINK PAIR

SEL

BLASTER

POWER

LINK USB 1.1USB 2.0

MODELINK

VIDEO

1 2 3 4

1 2 3 4 5 6 7 8 9

1POWER LED: Connects with 5V power, the power indicator will

ﬂ ash in blue once power on and illuminate constantly in blue after

power on the unit.

2LINK LED:

a. When Transmitter disconnects with Receiver or power on, the

orange LED indicator will not illuminate.

b. When Transmitter connects with Receiver and get link without

source connection, the LINK LED indicator will ﬂ ash in orange.

c. When Transmitter connects with Receiver and get source

connection, the indicator will illuminate constantly in orange.

3RS232: This slot connects with D-Sub 9-pin female null modern

cable from PC’s system, the RS-232 command will pass through

from Transmitter to Receiver or Receiver to Transmitter. The default

baud rate is setting at 115200. For multicast scenario, every single

Receiver unit can pass through RS-232 command to Transmitter.

Further, Transmitter is able to pass through RS-232 to all Receivers

on same channel.

4IR Blaster: Connects with IR Blaster supplied in the package for IR

signal received from Transmitter side to blast out and to control the

desire device. For multicast scenario, the IR signal is able to pass

through to all Receivers on same channel.

5IR: This IR window is for receiving the remote control signal and

sending it to Transmitter side for IR signal blast out.

6LINK PAIR SEL: This dip switch allows user with matrix setting for

link up to 16 pairs of the devices with single IP router. Each pair

must have the same dip switch setting in order to pair to the right

device setting. The factory default setting is at 0000. Please reboot

the Transmitter & Receiver after selecting.

7Video LINK: Presses button to disable and enable the link status.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere CYP Extender Handbücher

CYP

CYP PRO-F12TX Bedienungsanleitung

CYP

CYP IP-7000RX Bedienungsanleitung

CYP

CYP PRO-3GSDIHDMI Bedienungsanleitung

CYP

CYP PU-1103 Bedienungsanleitung

CYP

CYP PU-506-KIT Bedienungsanleitung

CYP

CYP CH-506TXPLRXPL Bedienungsanleitung

CYP

CYP PU-HBTPL-ZE Bedienungsanleitung

CYP

CYP CLUX-SDI2OF Bedienungsanleitung

CYP

CYP PU-1107-KIT Bedienungsanleitung

CYP

CYP PU-USB-KIT Bedienungsanleitung

CYP

CYP Suprex SPX-7400 Series Bedienungsanleitung

CYP

CYP PU-232 Bedienungsanleitung

CYP

CYP CDVI-513TXL Bedienungsanleitung

CYP

CYP PU-USBX Bedienungsanleitung

CYP

CYP PU-IR01 Bedienungsanleitung

CYP

CYP CH-1529TXPL Bedienungsanleitung

CYP

CYP PU-1109KIT Bedienungsanleitung

CYP

CYP CH-1109TXC Bedienungsanleitung

CYP

CYP IR-EXT3 Bedienungsanleitung

CYP

CYP PU-515PL-TX Bedienungsanleitung

CYP

CYP PUV-1510RX Bedienungsanleitung

CYP

CYP PU-USB-AL Bedienungsanleitung

CYP

CYP CH-506TX Bedienungsanleitung

CYP

CYP CH-506TXPL Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung
