CYP CMSI-8H8HS Bedienungsanleitung
CMSI-8H8HS
8 x 8 HDMI Matrix
Operation Manual
Operation Manual
DRAFT
DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 11/11/11 Preliminary Release
RDV2 13/12/11 Power Supply Change
RDV3 15/02/12 LAN Function
VS0 29/03/12 Updated format, diagrams, and
statements
DRAFT
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Side Panel .........................................5
6.4 Remote Control................................5
6.5 RS-232 Pin Assignment .....................6
6.6 RS-232 Commands...........................7
7. Connection Diagram ............................ 8
8. Specications ........................................ 9
9. Acronyms ............................................. 10
DRAFT
1
1. INTRODUCTION
The 8×8 HDMI Matrix supports the transmission of Video (up to 1080p
Full HD/1920×1200@60 Hz) with multichannel digital audio from up to
eight high denition sources to up to eight HDMI outputs and allows
the display of any source device on any output display. Also, the unit
can be controlled via IR, RS-232 or the front panel button controls.
2. APPLICATIONS
• Video/TV wall display
• Commercial advertising and display
• Lecture room display and control
• Hyper market demonstration and control
3. PACKAGE CONTENTS
• 8×8 HDMI Matrix
• 1×24 V/6.25 A DC Adaptor
• 1×Remote Control
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI equipped input source devices with HDMI cables
• HDMI equipped output displays (TVs or monitors) or HDMI equipped
AV receivers with HDMI cables
DRAFT
2
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Supports HDMI v1.4 features including 3D
• Supports audio sampling rate up to 192 kHz
• Supports resolutions VGA~WUXGA and 480i~1080p dependent upon
the output display’s EDID settings
• Supports 3D signal display dependent upon the output display's
EDID settings
• Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters
at 12-bit resolution and HDMI output up to 15 meters at 8-bit/12-bit
• Supports IR extension
• Supports RS-232, remote control and on-panel control
• 2U size design
DRAFT
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER LOCK
MENU OUTA 1B2C3D4
IN
E5F6G7H8
8X8 HDMI MATRIX CMSI-8H8HS
2 3 4 5 61
1
LCD:Displays the source device input setting (1~8)of each of the
HDMI outputs (A~H).
2
POWER: Press this button to power the device on/off. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
3
LOCK: Press this button to lock all the buttons on the panel, press
again to unlock. The LED will illuminate green when locked.
4
IR: IR Receiver window (accepts the remote control signal of this
device only).
5
MENU: Press this button to change the EDID setting from STD
(internal) 1 to TV (external) 2 and then press it again to conrm the
selection.
Note: For the 'TV' EDID setting, the unit will read and store the
EDID information of the display connected to HDMI output A. For
the 'STD' EDID setting, the unit's built-in EDID setting will be used
(1080p@60 Hz/12-bit for video and LPCM 2-channle for audio).
6
1~8/A~H and OUT/IN: Press the Out or In button to select the
output or input mode and then press the required number button
to make the selection accordingly.
For example, if outputs A~D need to be set to input 1 and outputs
E~H need to be set to input 2 then the following sequence of
button presses need to be performed:
Press: Out →A→B→C→D→In→1→Menu,
and then press: Out→E→F→G→H→In→2→Menu.
Note: If the menu button is not pressed the selection will not be
changed.
DRAFT
4
6.2 Rear Panel
LAN
DC 24V
IR-In
RS-232 Service
A
HDMI Out
1
HDMI In
B
HDMI Out
2
HDMI In
C
HDMI Out
3
HDMI In
D
HDMI Out
4
HDMI In
E
HDMI Out
5
HDMI In
F
HDMI Out
6
HDMI In
G
HDMI Out
7
HDMI In
H
HDMI Out
8
HDMI In
12
34
V+
GND
GND
GND
V+
12
34
V+
GND
GND
GND
V+
2 3
3
4 71 6
5
1
LAN: Reserved.
2
RS-232: Connect to a PC or laptop with D-Sub 9-pin female cable
for the transmission of RS-232 commands.
3
IR In: Connect the supplied IR extender (included in the package)
for IR signal reception. Ensure that remote being used is within the
direct line-of-sight of the IR extender.
4
Service: Manufacturer use only.
5
HDMI Out A~H: Connect to HDMI equipped TVs or monitors for
display of the HDMI input source signal.
6
HDMI In 1~8: Connect to the HDMI input source devices such as a
DVD player or a Set-top Box with HDMI cables or DVI to HDMI cables.
7
DC 24V: Plug the 24 V DC power supply (included in the package)
into the unit and connect the adaptor to an AC outlet.
DRAFT
5
6.3 Side Panel
1
1
VENTILATOR: These are fan ventilator areas, DO NOT block these
areas or cover them with any object. Please allow adequate
space around the unit for air circulation.
6.4 Remote Control
1POWER: Press this button to
switch on the device or set it to
'Standby' mode.
2
IN: Input ports selection 1~8.
3
OUT: Output ports selection A~H.
1
23
DRAFT
