CYP CMSI-8H8HS Bedienungsanleitung
Operation Manual
Operation Manual
CMSI-8H8HS
8 x 8 HDMI Matrix
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.0 September 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 11/11/2011 PreliMINary Release
RDV2 13/12/2011 Power Supply Change
RDV3 15/02/2012 LAN's Function
CONTENTS
1. Introduction..............................................1
2. Applications.............................................1
3. Package Contents ..................................1
4. System Requirements..............................1
5. Features....................................................1
6. Operation Controls and Functions.........2
6.1 Front Panel..........................................2
6.2 Rear Panel...........................................3
6.3 Side Panel...........................................4
6.4 Remote Control..................................4
6.5 RS-232 Protocols .................................5
6.6 RS-232 Commands.............................6
7. Connection and Installation...................7
8. Specications ..........................................8
9. Acronyms.................................................9
1
1. INTRODUCTION
The 8 x 8 HDMI Matrix is a fabulous device for organizing and
distributing your HDMI signals. With 8 HDMI input ports and 8 HDMI
output ports this device allows a great amount of sources and display
to be used motivationally. Moreover, with plenty of control systems
such as IR, RS-232 and remote control allow user for all kinds of control
habit and occasion to be used. Further, the EDID control settings
unlocked the information display freely present.
2. APPLICATIONS
• Video/TV wall display
• Commercial advertising and displaying
• Lecture room display and control
• Hyper market demonstration and control
3. PACKAGE CONTENTS
•8 x8 HDMI Matrix
•24V/6.25A DC adaptor x1
•Remote control x1
•IR receiver cable x1
•Operation manual
4. SYSTEM REQUIREMENTS
Input source equipments with HDMI connection cables and output
display or audio amplier equipments with HDMI connection cables.
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Supports HDMI v1.4 features:
√ 3D
• Supports audio sampling rate up to 192kHz
• Supports resolutions to VGA ~ WUXGA and 480i~1080p follow by
output display’s EDID
• Supports 3D signal display follow by display TV’s EDID
• Supports HDMI input up to 15 meters with 8bits resolution or 10
meters with 12bits resolution and output up to 15 meters with
8/12bits
• Supports IR extension
• Supports RS-232, remote control and on panel control
• 2U size design
2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1 2 3 4 5 6
1LCM
This monitor displays your setting information with each input
and output selection.
2POWER button & LED
Press this button to turn on the device and the green LED will
illuminate when the power is on. When the LED illuminate in red it is
in standby mode
3LOCK button & LED
Press this button to lock all the buttons on the panel. To unlock, just
press it again.
4IR
This IR window accepts the remote control signal of this device
only.
5MENU
Press this button once to select EDID setting from STD
(internal) 1 or TV (external) 2 then press it again to conrm
the selection. Press this button every to conrm the
selection.
EDID TV: The device will read the EDID of HDMI output A and
record it.EDID STD: The device's built-in EDID is 1080p@60/12bits
forvideo and LPCM 2CH for Audio.
61 ~8 /A ~ H & Out/In buttons
Press Out/In button rst to select the output/input then press
the number button to make the selection accordingly. For
3
example, output A ~ D wish to select input 1 and E ~ H wish
to select input 2. Press Out →A→B→C→D→In→1→Menu,
and then press Out →E→F→G→H→In→2→Menu. If the menu
button is not press the selection will not be changed.
6.2 Rear Panel
1 2 3 4 6 75
1LAN
Reserved.
2RS-232
This slot is to connect with D-Sub 9pin cable from the PC/NB device
for RS-232 control.
3IR-IN
This slot is to connect with the IR extender included in the package
for IR signal receiving from the remote control of this device.
4SERVICE
This slot is to connect with USB cable for manufacturers’ rmware
update only.
5HDMI OUT A~H
These slots are to connect with display or monitor with HDMI cables
for output image display.
6HDMI IN 1~8
These slots are to connect with input source equipment such
as Blu-ray player or Set-Up-Box with HDMI cable or DVI to HDMI
converter cable for input signal sending.
4
7DC24V
This slot is to plug the power cord with adaptor included in the
package and then connect them with AC wall outlet for power
supply.
6.3 Side Panel
1
1VENTILATOR
These are fan ventilator area, DO NOT block these area or cover it
with any object.
6.4 Remote Control
1Power
Press this button to switch on the device or
set it to standby mode.
2IN
Input ports selection 1~8.
3OUT
Output ports selection A~H. H
8
1A
B
2
3
4D
5E
6F
7G
CR-110
IN OUT
1
2 3
C
5
6.5 RS-232 Protocols
CMSI-8H8HS
►
◄
Remote Control Console
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx2 Rx
3 Rx3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
