Ethernet SIO"
SIO-7300"
Serial Input and Output
Product Manual
Cypress Integration Solutions 35+ Years of Access Control Ingenuity CypressIntegration.com
©2020 Cypress Computer Systems 1778 Imlay City Road, Lapeer, MI 48446 800-807-2977
SIO-7300_MAN 210108
Page 2
Specifications
Part Number
SIO-7300
UPC: 816684003066
Ethernet Serial Input Output Unit
Physical
Aluminum enclosure
4.50” x 3.07” x 2.02” / 0.445 lbs
Environmental
Storage Temperature
-40˚C to 100˚C
Operating Temperature
-30˚C to 60˚C
Electrical
Supply Voltage
8-16Vdc Current 300mA
SPDT Relays
Max Switching
220Vdc 30W (resistive) 1A / 250Vac 37.5VA 1A
Running Spec with load
30Vdc 1A (resistive) / 125 Vac 0.3A (resistive), 1x105 operations @ 20˚C
Data I/O
Interface
Wiegand (4 - 248 bits)
Strobed Rising (MR-5) (4 - 248 bits)
Strobed Rising (Dorado 644) (4 - 248 bits)
Strobed Rising (MagTek) (4 - 248 bits)
Strobed Falling (4 - 248 bits)
Unsupervised F/2F (4 - 248 bits)
Network
Specifications
Network Interface
RJ45 Ethernet 10Base-T or 100Base-TX (auto-sensing)
Compatibility
Ethernet: Version 2.0/IEEE 802.3 (electrical), Ethernet II frame type
Protocols Supported
TCP/IP, ARP, UDP/IP, ICMP, DHCP, BOOTP, TFTP, Auto IP, HTTP, SMTP
Note: For standard use cases, the SIO-7300 uses TCP/IP
Cypress SIO-7300 - Specifications
Overview
The SIO-7300 is a TCP/IP device that supports Wiegand I/O, digital I/O, analog inputs and relay outputs, and is
controlled by a network controller using the SIO protocol. The SIO-7300 allows the use of a single Wiegand reader
without a traditional access control system. It can also be used as a remote Wiegand output device, controlled by a host
device on the network.
Page 3
Cypress SIO-7300 - Table of Contents
Topic
Page
Overview and Specifications
2
Dimensions
4
Pin Designations
5
Circuit Board Assembly Features
6
Status LED Behavior
7
RJ45 LED Behavior
8
Input Mode Wiring Diagram
9
Output Mode Wiring Diagram
10
DIP Switches
11-12
Configuring Network Settings (Overview and Connecting to the SIO-7300)
13-15
Configuring Network Settings (Connecting via Telnet)
16-19
Configuring Network Settings (Connecting via web browser)
20-22
Configuring Network Settings (Default network settings)
23
Packet Structure
24
Status Values
25-26
Reader Data Formats
27
Sample Packets
28-36
I/O Pins Overview
37-38
LED I/O
39
AUX I/O
40-41
Analog Inputs
42-43
Relay Outputs
44-45
Page 4
SIO-7300 Enclosure
Dimensions
Cypress SIO-7300 - Unit Dimensions
ø 0.120 X 4
3.065"
2.770"
4.0625"
2.660"
2.940"
SIO-7300
Dimensions in inches.
Page 5
Cypress SIO-7300 - Pin Designations
J1 - 2 pins
1 - Power (8-16V DC, 12V Nominal)
2 - Ground
J2 - 8 pins
1 - RS-485 A
2 - RS-485 B
3 - 5V DC (Output)
4 - Analog 2 (Input)
5 - Analog 1 (Input)
6 - LED (Input/Output)
7 - Wiegand Data 1 (Input/Output)
8 - Wiegand Data 0 (Input/Output)
J3 - 10 pins
1 - Relay 2 Normally Open
2 - Relay 2 Common
3 - Relay 2 Normally Closed
4 - Relay 1 Normally Open
5 - Relay 1 Common
6 - Relay 1 Normally Closed
7 - Ground
8 - AUX 1 (Input/Output)
9 - AUX 2 (Input/Output)
10 - AUX 3 (Input)
1 8 - 16VDC
2 Ground
Status LED
1 RS-485 A
2 RS-485 B
3 +5V Out
4 AN 2 IN
5 AN 1 IN
6 LED I/O
7 D1 I/O
8 D0 I/O
Relay 2 N.O. 1
Relay 2 COM 2
Relay 2 N.C. 3
Relay 1 N.O. 4
Relay 1 COM 5
Relay 1 N.C. 6
Ground 7
AUX 1 I/O 8
AUX 2 I/O 9
AUX 3 IN 10
SIO-7300
Page 6
Cypress SIO-7300 - Circuit Board Assembly Features
DIP Switches
J1 Header
Status LED
J2 Header
J3 Header
RJ45 Port
Heat Sink Screw
Page 7
Cypress SIO-7300 - Status LED Behavior
Status LED
Run Mode
Solid Red - SIO-7300 is powered on. "
Off- SIO-7300 is not powered on."
Configuration Mode
Solid Green - SIO-7300 is powered on and configuration settings have been applied."
Flashing Green - When the Network Settings are defaulted, the status LED will flash green for approximately 8
seconds until the network settings are applied. When the default network settings and configuration settings are
applied, the status LED will be solid green. "
Off- SIO-7300 is not powered on.
Page 8
Cypress SIO-7300 - RJ45 LED Behavior
Activity LED (right)
Link LED
(left)
RJ45 Port
Link LED (left)
Activity LED (right)
Color
Meaning
Color
Meaning
OFF
No Link
OFF
No Activity
Amber
10 Mbps
Amber
Half-Duplex
Green
100 Mbps
Green
Full-Duplex
Page 9
Cypress SIO-7300 - Input Mode Wiring Diagram
Card
Reader
Power
Ground
LED IN
Data 1
Data 0
1 8 - 16VDC
2 Ground
Status LED
1 RS-485 A
2 RS-485 B
3 +5V Out
4 AN 2 IN
5 AN 1 IN
6 LED I/O
7 D1 I/O
8 D0 I/O
Relay 2 N.O. 1
Relay 2 COM 2
Relay 2 N.C. 3
Relay 1 N.O. 4
Relay 1 COM 5
Relay 1 N.C. 6
Ground 7
AUX 1 I/O 8
AUX 2 I/O 9
AUX 3 IN 10
SIO-7300
Host Device
Network
DC Power
Supply
Power
Ground
Page 10
Cypress SIO-7300 - Output Mode Wiring Diagram
1 8 - 16VDC
2 Ground
Status LED
1 RS-485 A
2 RS-485 B
3 +5V Out
4 AN 2 IN
5 AN 1 IN
6 LED I/O
7 D1 I/O
8 D0 I/O
Relay 2 N.O. 1
Relay 2 COM 2
Relay 2 N.C. 3
Relay 1 N.O. 4
Relay 1 COM 5
Relay 1 N.C. 6
Ground 7
AUX 1 I/O 8
AUX 2 I/O 9
AUX 3 IN 10
SIO-7300
Host Device
Network
Ground
LED Out
Data1
Data 0
N.O.
COM
Access
Control
Panel
DC Power
Supply
Power
Ground
