This document will guide you through the

basic installation process for your new

D-Link Wireless Access Point.

Building Networks for People

DAP-3320

Documentation also available

via the D-Link Website

Quick Installation Guide

Wireless PoE Outdoor Access Point

Quick Installation Guide

Краткое руководство по установке

Guía de Instalación Rápida

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

D-Link DAP-3320 Quick Install Guide 1

ENGLISH

IMPORTANT INFORMATION

This product should ONLY be installed by an experienced installer who is familiar with local

building and safety codes and, wherer applicable, is licensed by the appropriate authorities.

Failure to employ an experienced installer may render the D-Link product warranty void and

may also expose the end user or the service provider to legal and financial liabilities. D-Link

and its resellers or distributors expressly disclaim any and all liabilities for injury, damage, or

violation of regulations due to the improper installation of outdoor units or antennas.

A safety grounding system is necessary to protect your outdoor installation from lightning

strikes and the build-up of static electricity. Direct grounding of an outdoor AP is very important

and can protect your networks from brutal outdoor environments and devastating ESD attacks.

The grounding system must comply with the National Electrical Code and safety standards that

apply in your country and/or region. Always check with a qualified electrician if you are in doubt

as to whether your outdoor installation is properly grounded.

D-Link DAP-3320 Quick Install Guide

ENGLISH

Before You Begin

This chapter describes safety precautions

and product information you must know and

check before installing this product.

Professional Installation

Required

1. Please seek assistance from a

professional installer who is well trained

in RF installation and knowledgeable

about local regulations.

2. This product is distributed through

distributors and system installers with

professional technicians and is not to be

sold directly through retail stores.

Safety Precautions

To keep you safe and to install the

hardware properly, please read and follow

these safety precautions:

1. If you are installing an access point for

the rst time, for your safety as well as

others’, please seek assistance from a

professional installer who has received

safety training on the hazards involved.

2. Keep safety as well as performance in

mind when selecting your installation

site, especially when there are electric

power and phone lines.

3. When installing your access point, note

the following:

• Do not use a metal ladder.

• Do not work on a wet or windy day.

• Wear shoes with rubber soles and

heels, rubber gloves, and a long

sleeved shirt or jacket.

4. When the system is operational, avoid

standing directly in front of the antenna.

Strong RF elds are present when the

transmitter is on.

5. A safety grounding system is necessary

to protect your outdoor installation

from lightning strikes and the build-up

of static electricity. When mounting

the product on an antenna mast, you

must connect the product to the same

grounding system as the AC wall outlet.

The grounding system must comply with

the National Electrical Code and safety

standards that apply in your country.

6. Always check with a qualied electrician

if you are in doubt as to whether

your outdoor installation is properly

grounded.

D-Link DAP-3320 Quick Install Guide 3

ENGLISH

Physical Installation

Remove the bottom cover

Lift the release tab in the middle of the

cover, then pull the cover off.

Connect an Ethernet cable

Connect an Ethernet cable(not included) to

the Ethernet port.

Connect the grounding wire

Use the grounding screw to attach the

grounding wire.

Quick Installation Guide

This installation guide provides basic

instructions for installing the DAP-3320

Wireless PoE Outdoor Access Point on your

network. For additional information about

how to use the Access Point, please see

the datasheet and user manual available on

the D-Link support website.

Minimum System Requirements

- Computer with Windows, Mac OS, or

Linux-based operating system, and an

Ethernet adapter installed

- Internet Explorer 7, Mozilla Firefox 12.0,

Safari 4.0, or Chrome 20.0 or newer

Package Contents

- DAP-3320 Wireless PoE Outdoor Access Point

- PoE injector with 48 V/0.5 A power

adapter (included with some models)

- Wall mounting bracket with mounting kit

- Two plastic mounting ties

- Grounding wire

If any of the above items are missing,

please contact your reseller.

D-Link DAP-3320 Quick Install Guide

ENGLISH

Mounting the AP

The DAP-3320 supports the IP55 water/

dustproof standard. It is recommended that

you place the AP under a roof, shelter, or

weatherproof container in severe weather

environments.

Mounting the AP to a Pole

Thread the plastic mounting ties through the

back of the DAP-3320 and around the pole.

Reattach the bottom cover.

You may need to break off the plastic port

covers to allow your cables to exit the AP.

Mounting the AP to a Wall

Screw the wall mounting bracket into the

wall, then attach the DAP-3320 to it. For

extra security, you can thread the plastic

mounting ties through the back of the

DAP-3320 and the wall mounting bracket

as shown.

D-Link DAP-3320 Quick Install Guide 5

ENGLISH

Conguration

If you are configuring the DAP-3320 locally,

connect a PC to same network that the

DAP-3320 is connected to.

A. Assign a static IP address to your PC

that is in the same network segment as

the DAP-3320. As the default IP address

of this unit is 192.168.0.50, you may

choose any address from 192.168.0.1 to

192.168.0.254, except 192.168.0.50.

B. Open a web browser and go to

http://192.168.0.50. Enter admin as your

username and leave the password blank

to log in to the web UI. Now you can

congure the DAP-3320 through the web

UI.

Connecting to the PoE Injector

A. Connect the Ethernet cable that is

connected to the DAP-3320 to the

P+DATA OUT port on the PoE injector.

B. Connect an Ethernet cable to the DATA

IN port on the PoE Injector. Connect the

other end of the Ethernet cable to your

network switch or router.

C. Attach the power adapter to the connector

labeled POWER IN on the PoE Injector,

and plug it into an electrical outlet.

Connecting to Your Network

You can connect the DAP-3320 to a PoE

switch, or you can use the included PoE

injector to power the AP.

Connecting to a PoE Switch

Connect the Ethernet cable that is

connected to the DAP-3320 to your PoE

switch.

PoE Switch Computer

LAN (PoE)

P+DATA OUT

DATA IN

PoE Injector

POWER IN

Router or Switch Computer

LAN (PoE)
