IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed. These instructions should be saved for future

reference:

• Read and familiarise yourself with all operating instructions before

using this Vacuum Cleaner.

• Before plugging your unit into the mains, visually check that the unit is

intact and has not su󰀨ered any transit damage.

• Check that the voltage indicated on the data plate corresponds with

that of the local network before connecting the appliance to the mains

power supply.

• This appliance can be used by persons with reduced physical,

sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

• Children shall not play with the appliance.

• Keep the appliance and its cord out of reach of children less than 8

years when it is energised or cooling down.

• Do not immerse the appliance or its cord in water or any other liquids.

• Do not leave the appliance unattended during use.

• Do not leave the appliance unattended whilst connected to the mains

supply.

• Do not use this appliance outdoors.

• It is imperative to unplug the power cord after the appliance has been

used, before it is cleaned and whilst being repaired.

• Repairs to electrical appliances should only be performed by a

qualied electrician. Improper repairs may place user at serious risk.

• Do not operate this appliance with a damaged plug or cord, after a

malfunction or after being dropped or damaged in any way.

• Regular, periodic checks should be carried out on the mains cable to

• ensure no damage is evident. Should there be any signs of damage

the appliance should not be used.

Tornado F1 Upright Vacuum

FLR00049

User Manual

• If the power cable is damaged, it should only be replaced by the

manufacturer or a suitable qualied after-sales-service in order to

avoid a hazard

• Do not allow the mains cable to hang over sharp edges or come in

contact with hot surfaces.

• Allow the unit to cool before storage.

• Before cleaning, disconnect the appliance from the mains supply and

allow to cool.

• This appliance is intended for household use only and should not be

used for industrial purposes.

• Do not use any accessories or attachments with this appliance other

than those supplied or recommended by supplier.

• Do not use this appliance for anything other than its intended use.

• Do not push objects into any openings as damage to the appliance

and/or electric shock may occur.

• Unplug after each use. Grasp the plug, not the cord.

• Do not pull or carry the Vacuum Cleaner by the electrical cord, use the

handles provided.

• Ensure ngers and other objects are never placed in any part of the

vacuum cleaner. Clothing or hair may become trapped if the vacuum

is used improperly.

• Keep hair, loose clothing, jewellery, ngers and all parts of the body

away from openings and moving parts.

• Keep all air vents clear and free of dust, lint, hair and anything else

that may reduce airow.

• Avoid directing the appliance towards naked ames as the air

discharged may extinguish gas res or pilot lights and may disturb

ashes in open res.

Tornado F1 Upright Vacuum

FLR00049

User Manual

Description of parts

Handle

Hose

Cylinder release

button

Cylinder lid

Cylinder

Floor head

Brush level

selector dial

Brush roller

Cylinder base

Filter assembly

Suction pressure

release valve

Hose anti

topple ring

On/O󰀨

button

Hose anti topple

hook

Lower cable

storage hook

Hose

connector

Power cord

Upper cable

storage hook

Hose hook

Handle pole

Cable clip

Rectangular

HEPA lter

Sponge lter

Cylinder HEPA

lter

Hose

Crevice and

upholstery

multi tool

Crevice and

upholstery

multi tool

Tornado F1 Upright Vacuum

FLR00049

User Manual

Pet brush

Assembly

Align the handle pole with

the top of the vacuum

body and insert until the

screw hole in the body

aligns with the screw hole

in the pole.

Insert the screw (supplied)

using a pozidrive screwdriver

(not supplied) and tighten.

Using your vacuum cleaner

The oor head of the vacuum

cleaner can be raised or lowered

to suit the oor surface to be

cleaned.

Turn the selector dial clockwise

to raise the oor head and anti

clockwise to lower the oor head.

NOTE: Ensure the vacuum cleaner is fully assembled before use.

Tornado F1 Upright Vacuum

FLR00049

User Manual

Unravel the cable from the storage hooks.

To do this simply rotate the upper storage

hook through 180 degrees and pull the

cable away, then unhook from the lower

cable hook.

Insert the plug into a suitable socket

outlet

For upright use, place your foot on

the oor head and pull back gently

on the handle (right) then turn on by

pressing the power ON/OFF button

with your foot. (see below)

Tornado F1 Upright Vacuum

FLR00049

User Manual

Using the hose and pet brush

For di󰀩cult to remove soiling on upholstery such as pet hairs, the pet

brush can be used.

This should be tted onto the hose as shown above.

The xed combs and rotating pneumatic brush clean up even the most

stubborn or matted hairs.

Remove the end of the hose from the hose

connector by twisting anti clockwise and

pulling upwards

Using the hose and multi tool

Attach the multi tool to the hose

by simply sliding onto the end of

the hose

The multi tool can be used as a

crevice tool or as an upholstery

brush.

To use the upholstery brush,

slide to the end of the multi tool

unit until it locks into place.

Tornado F1 Upright Vacuum

FLR00049

User Manual

To retract the uphostery

brush, push the button on

the side of the tool and push

the brush back

Note: To improve stability of the

vacuum cleaner when using the

hose, hook the hose anti topple

ring on the hose onto the hose

anti topple hook, which is on

the lower cable storage hook.

Turn the vacuum cleaner on and o󰀨 using the power ON/OFF button.

When cleaning stairs always place the

vacuum cleaner at the bottom of the

stairs so it is always positioned below

you and up against the bottom stair

(see right).

Clean the stairs using the multi tool

attachment or just the hose as

conditions demand.

Note: The brushroll rotates constantly

when the vacuum cleaner is on.

When upright the wheels will raise

the brushroll from the oor. To avoid

damage to your oor, ensure the

vacuum is upright when using the

hose.

Tornado F1 Upright Vacuum

FLR00049

User Manual

Emptying the cylinder

To release the cylinder from the main

body of the vacuum cleaner, press

the cylinder release button at the top

of the cylinder and pull the cylinder

away from the top.

To empty the cylinder, hold over a

dustbin and release the catch on

the bottom of the cylinder.

Shake the cylinder until all of the

dust is removed from the cylinder.

Tornado F1 Upright Vacuum

FLR00049

User Manual
