Daewoo TORNADO FREEDOM PRO Bedienungsanleitung

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

User Manual

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed. These instructions should be saved for future

reference:

•Read and familiarise yourself with all operating instructions before

using this Vacuum Cleaner.

•This appliance can be used by persons with reduced physical, sensory

or mental capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved.

•Children shall not play with the appliance.

•Keep the appliance and its cord out of reach of children less than 8

years when it is energised or cooling down.

•Do not immerse the appliance or its cable in water or any other liquids.

•Do not leave the appliance unattended during use.

•Do not leave the appliance unattended whilst connected to the power

supply.

•The Vacuum can be used outdoors but the power supply must remain

indoors.

•It is imperative to unplug the power supply after the appliance has

been used, before it is cleaned and whilst being repaired.

•Repairs to electrical appliances should only be performed by a qualified

electrician. Improper repairs may place user at serious risk.

•Do not operate this appliance with a damaged power supply or cable,

after a malfunction or after being dropped or damaged in any way.

•Regular, periodic checks should be carried out on the cable to ensure

no damage is evident. Should there be any signs of damage the

appliance should not be used.

•If the cable is damaged, it should only be replaced by the manufacturer

or a suitable qualified after-sales-service in order to avoid a hazard

•Do not allow the power cable to hang over sharp edges or come in

contact with hot surfaces.

•Do not run the cable under carpets, rugs, etc.

•The Vacuum Cleaner is not to be used if it has been dropped, if there

are visible signs of damage.

•Allow the unit to cool before storage.

•Before cleaning, disconnect the appliance from the mains supply and

allow to cool.

•This appliance is intended for household use only and should not be

used for industrial purposes.

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

•Do not use any accessories or attachments with this appliance other

than those supplied or recommended by supplier.

•Do not use this appliance for anything other than its intended use.

•Do not push objects into any openings as damage to the appliance

and/or electric shock may occur.

•Unplug after each use. Grasp the power supply, not the cable.

•Do not pull or carry the Vacuum Cleaner by the cable.

•Never use the appliance without the filter in place.

•Do not use the Vacuum with no Dust Tank attached.

•Use only on vehicle interior surfaces.

•Do not tilt the Vacuum towards the main body when vacuuming

liquids.

•Do not vacuum any large or broken objects such as glass.

•Do not vacuum anything that is burning or smoking such as cigarettes,

matches or hot ashes.

•Do not vacuum reactive liquids (solvents, corrosives, detergents)

•Do not vacuum flammable or explosive substances such as alcohol,

thinners etc.

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Description of Parts

Before the first time you use your Vacuum Cleaner

Please read these operating instructions thoroughly and keep them in a safe place for

future reference.

Remove all packing materials and discard responsibly.

1. Dust Compartment.

2. Filter.

3. Charging/Battery Indicators

4. Dust Compartment Release Button.

5. Handheld On/Off Button

6. Cleaner Release Button (for handheld use)

7. Charging Station.

8. Charging Socket

9. Handle Catch

10. Control Buttons

11. Handle Pivot

12. Charging Contacts

13. Floor Tool & Brush

14. Upright On/Off Button

15. Increase Speed/Suction Button

16. Decrease Speed/Suction Button

17. Floor Brush On/Off Button

18. Crevice Tool (for carpet edges & hard to

get at areas)

19. Upholstery Tool

20. Mains Charger

21. Small Power Plug

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Charging the internal Battery

Before use, please ensure that the internal rechargeable battery is fully charged as follows:

1. Place the vacuum onto the Charging Station (7) ensuring that the Handheld Vacuum is

mounted inside the upright section of the vacuum.

2. Insert the Small Power Plug (21) of the Mains Charger (20) into the Charging Socket (8) on

the right hand side of the Charging Station (7).

3. Plug the Mains Charger (20) into the nearest mains socket.

4. The Charging/Battery Indicators (3) will light in the sequence as in a, b, c below to show

the internal battery is charging.

5. Once the battery is fully charged (after approximately 5 hours), the Charging/Battery

Indicators (3) will all light as in ‘c’ below showing that the internal battery is fully charged

and the Mains Charger (20) can be removed.

NB the Charging/Battery Indicators will go out one at a time as the vacuum is being used, when

none of the indicators are illuminated the internal battery will need recharging.

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Using the Vacuum in the Upright Position

2. Left: Place your foot gently on the Floor Tool

& Brush (13) and pull the cleaner back by the

Handle and start vacuum cleaning.

Press the Upright On/off Switch (14) again at

the end of cleaning to switch the cleaner off.

1. Right: Grasp the vacuum cleaner firmly by the

Handle and press the Upright On/off Switch

(14) to power up the cleaner.

3. Right: During use, press the Increase

Speed/Suction Button (15) to

increase suction power or press the

Decrease Speed/Suction Button (16)

to lower the suction power according

to the floor surface being vacuumed.

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

4. Left: If Vacuuming hard floors such

as Tiles, laminate, etc. press the

Floor Brush On/Off Button (17) to

switch off the floor brush to

protect the hard surface being

cleaned.

5. Right/Below: Pull the Handle

Catch (9) upwards to allow the

handle to bend. This is useful for

cleaning under beds and hard to

get at areas as shown below:

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

Using the Vacuum Hand Held

1. Press the Cleaner Release Button (6 –

arrowed right) and lift out the cleaner from

the upright section to use the cleaner

handheld.

2. Press the Handheld On/Off Button (5) to

power up the cleaner, press the button

again to switch the cleaner off.

3. To aid cleaning, insert the Crevice or the Upholstery Tool

(18 & 19) into to the inlet on the vacuum as shown below:

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

1. Once the Dust Compartment (1) is

full it will need emptying and the

filter cleaned.

2. To empty the cleaner, hold the Dust

Compartment (1) and press the

Dust Compartment Release Button

(4) and remove the Dust

Compartment (1). Lift out the Filter

(2) and empty the dust out into a

bin.

3. Wash the Filter (2) in warm running water

until the Filter (2) is clean. Allow the filter

to thoroughly dry for 24 hours before

reuse.

Emptying and Cleaning Your Vacuum Cleaner

WARNING Always disconnect the cleaner from the Charger before cleaning.

WARNING do not continue to use your vacuum cleaner once the Dust Compartment (6) is

full otherwise permanent damage may occur to the appliance.

Care and Use of your Vacuum Cleaner

•Always disconnect the cleaner from the Mains Charger before cleaning.

•Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or abrasive

cleaners.

•Do not submerge the cleaner in water or any other liquids.

•Empty the Dust Compartment (1) as soon as it is full.*

•Wash the Filter regularly –see table below.

•Allow the filter to thoroughly dry out for 24 hours before reassembly and reuse.

Tornado Freedom Pro 22.2V 2 in 1 Vacuum Cleaner

FLR00004

User Manual

IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

WARNING do not continue to use your vacuum cleaner once the Dust Compartment (6) is full

otherwise permanent damage may occur to the appliance.

Recommended filter cleaning intervals

Filter Type

Recommended cleaning period

WARNING Ensure the filter is cleaned periodically according to the table above, failure to

clean the filter regularly will severely impair the performance and permanent damage may

occur to the appliance and may also invalidate your warranty.

NB Do not under any circumstances use the vacuum cleaner with the filter removed as

damage to the appliance will occur.

Technical Data

Model Number

FLR00004

Mains Charger

Input: AC 100-240V ~ 50-60Hz Output: 27V 500mA DC

Rated Power

120W

Battery

22.2V 2200mAh Li-Ion (6x 3.7V Batteries)

Capacity

0.6L

Unpacked Weight (approx.)

2.7 Kgs

Dimensions (approx.)

160mm (d) x 250mm (w) x 1150mm (h)

Vacuum (max)

>8kpa

•Shake

out

debris

when

you

empty

the dust

container

•

Rinse

under

war

water

once

month

•Allow to dry thoroughly for 24 hours before

reuse.

Cloth Filter (1)
