DH-DVR3104/3108/3116E

4/8/16 Channel CIF Mini 1U Standalone DVR

Features

>Up to 4/8/16 cameras with SXGA(1280×1024) realtime preview

>H.264 dual-stream video compression

>All channel@CIF realtime recording

>VGA / TV simultaneous video output

>All channel synchronous realtime playback, GRID interface & smart search

>3D intelligent positioning with Dahua PTZ dome camera

>Support 1 SATA HDD up to 4TB, 2 USB2.0

>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

DH-DVR3104/3108/3116E

Specifications

Model DH-DVR3104E DH-DVR3108E DH-DVR3116E

System

Main Processor Embedded processor

Operating System Embedded LINUX

Video

Input 4 channel, BNC 8 channel, BNC 16 channel, BNC

Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s)

Audio

Input 1 channel, RCA

Output 1 channel, RCA

Two-w a y Ta l k Same with audio input channel 1

Display

Interface 1 VGA, 1 TV, BNC(1.0Vp-p, 75Ω)

Resolution 1280×1024, 1280×720, 1024×768, 800×600

Display Split 1/4 1/4/8/9 1/4/8/9/16

Privacy Masking 4 rectangular zones (each camera)

OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording

Video/Audio

Compression

H.264 / G.711

Resolution

D1/4CIF(704×576/704×480) / CIF(352×288/352×240) /

QCIF(176×144/176×120)

Record

Rate

Main

Stream:

D1(1~6/7fps)/CIF(1~25/30fps)

Extra

Stream

QCIF(1~25/30fps)

Bit Rate 48~4096Kb/s

Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop

Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300

sec

Video Detection

Trigger Events Recording, PTZ movement, Tour, Email

Motion Detection Zones: 396(22×18), Sensitivity: 1~6 (level 6 is highest)

Playback & Backup

Sync Playback 1/4 1/4/9 1/4/9/16

Search Mode Time/Date, MD & Exact search (accurate to second)

Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file,

Next camera, P

revious camera, Full screen, Repeat, Shuffle, Backup

selection, Digital zoom(any size)

Backup Mode USB Device / Network

Network

Ethernet RJ-45 port (10/100M)

DH-DVR3104/3108/3116E

Network Functions

H T T P, IPv4/IPv6,

TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE,

DDNS, FTP, IP Filter, Alarm Server

Max. User Access 20 users

Smart Phone iPhone, iPad, Android, Windows Phone

Storage

Internal HDD 1 SATA port, up to 4TB

Auxiliary Interface

USB Interface 2 ports (1 Rear), USB2.0

RS485 PTZ control

Environmental

Power Supply DC12V/2A

Power Consumption 10W(without HDD)

Working

Environment -10 ~+55°C / 10~90%RH / 86~106kpa

Dimension(W×D×H) Mini 1U, 325mm×245mm×45mm

Weight 1.5KG(without HDD)

System Connection

DVR3116-E System Connection

Dahua Technology Co., Ltd.

1187 BinAn Road, Binjiang District, Hangzhou, China

Tel: +86-571-87688883

Fax: +86-571-87688815

Email: overseas@dahuatech.com

www.dahuatech.com

*Design and specifications are subject to change without notice.
