Installation Guide
DEVIreg™ Touch
Electronic Intelligent Timer Thermostat
DEVIreg™ Touch
3Installation Guide
1 Introduction
DEVIreg™ Touch is an electronic programmable timer
thermostat used for controlling electrical floor heating
elements. The thermostat is designed for fixed installation
only and can be used for both direct heating of the entire
room and for comfort heating of the floor. Among others,
the thermostat has the following features:
• A touchscreen display with backlight.
• An easy-to-follow menu-driven programming and
operation.
1 Introduction . . . . . . . . . . . . . . . . . . . . . 3
1.1 Technical Specifications . . . . . . . . . . . 4
1.2 Safety Instructions . . . . . . . . . . . . . . . 6
2 Mounting Instructions . . . . . . . . . . . . . . . 7
3 Settings . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Initial Settings. . . . . . . . . . . . . . . . . 10
3.2 Forecast . . . . . . . . . . . . . . . . . . . . 14
3.3 Window Open . . . . . . . . . . . . . . . . 16
3.4 Maximum Floor Temperature . . . . . . . 17
4 Symbols . . . . . . . . . . . . . . . . . . . . . . . 19
5 Warranty. . . . . . . . . . . . . . . . . . . . . . . 20
6 Disposal Instruction . . . . . . . . . . . . . . . 20
Table of Contents
DEVIreg™ Touch
Installation Guide4
• An installation wizard with room/floor type-specific
setup.
• Support for multiple frame systems.
• Compatible with several 3rd party NTC sensors.
• Thermostat settings can be specified before instal-
lation and imported to the thermostat using a
web-generated code, or copied from a thermostat in a
similar installation.
• Smart access to thermostat settings after installa-
tion by using a web code interface for easy setup or
remote troubleshooting.
More information on this product can also be found at:
touch.devi.com
1.1 Technical Specifications
Operation voltage 220-240 V~, 50/60 Hz
Standby power consumption Max. 0.40 W
Relay:
Resistive load
Inductive load
Max. 16 A / 3680 W @ 230 V
cos φ= 0.3 Max. 1 A
Sensing units NTC 6.8 kOhm at 25°C
NTC 10 kOhm at 25°C
NTC 12 kOhm at 25°C
NTC 15 kOhm at 25°C (Default)
NTC 33 kOhm at 25°C
NTC 47 kOhm at 25°C
DEVIreg™ Touch
5Installation Guide
Sensing values:
(Default NTC 15 K)
0°C
20°C
50°C
42 kOhm
18 kOhm
6 kOhm
Control PWM (Pulse Wide Modulation)
Ambient temperature 0° to +30°C
Frost protection temperature 5°C to +9°C (default 5°C)
Temperature range Room temperature: 5-35°C.
Floor temperature: 5-45°C.
Max. floor: 20-35°C (if unrecov-
erable seal is broken then up to
45°C). Min. floor: 10-35°C, only
with combination of room and
floor sensor.
Sensor failure monitoring The thermostat has a built-in
monitoring circuit, which will
switch off the heating if the
sensor is disconnected or short-
circuited
Cable specification max. 1x4 mm2or 2x2,5 mm2
Ball pressure test temperature 75°C
Pollution degree 2 (domestic use)
Controller type 1C
Software class A
Storage temperature -20°C to +65°C
DEVIreg™ Touch
Installation Guide6
IP class 21
Protection class Class II -
Dimensions 85 x 85 x 20-24 mm
(in-wall depth: 22 mm)
Weight 103 g
Electrical safety and Electro-Magnetic Compatibility for
this product is covered by the compliance with the EN/IEC
Standard “Automatic electrical controls for household and
similar use”:
• EN/IEC 60730-1 (general)
• EN/IEC 60730-2-9 (thermostat)
1.2 Safety Instructions
Make sure the mains supply to the thermostat is turned off
before installation.
Important: When the thermostat is used to control a floor
heating element in connection with a wooden floor or
similar material, always use a floor sensor and never set the
maximum floor temperature to more than 35°C.
Please also note the following:
• The installation of the thermostat must be done by an
authorized and qualified installer according to local
regulations.
DEVIreg™ Touch
7Installation Guide
• The thermostat must be connected to a power supply
via an all-pole disconnection switch.
• Always connect the thermostat to continuous power
supply.
• Do not expose the thermostat to moisture, water,
dust, and excessive heat.
2 Mounting Instructions
Please observe the following placement guidelines:
Place the thermostat at a suitable height on the wall
(typically 80-170cm.).
The thermostat should not be placed in wet rooms.
Place it in an adjacent room. Always place the ther-
mostat according to local regulation on IP classes.
Do not place the thermostat on the inner side of an
exterior wall.
Always install the thermostat at least 50 cm. from
windows and doors.
DEVIreg™ Touch
Installation Guide8
Do not place the thermostat in a way that it will be
exposed to direct sunlight.
Note: A floor sensor enables a more accurate
temperature control and is recommended in all floor
heating applications and mandatory under wooden
floors to reduce the risk of over-heating the floor.
Place the floor sensor in a conduit in an appropriate place
where it is not exposed to sunlight or draft from door openings.
• Equally distant and >2cm from two heating cables.
• The conduit should be flush with the floor surface -
countersink the conduit if necessary.
• Route the conduit to the connection box.
• The bending radius of the conduit must be min 50mm.
DEVIreg™ Touch
9Installation Guide
Follow the steps below to mount the thermostat:
1. Open the thermostat:
Important: Do NOT press on the display screen when
removing the front part.
Press your fingers under the side of the front part and
pull toward you:
2. Connect the thermostat according to the connection
diagram.
The screen of the heating cable must be connected to
the earth conductor of the power supply cable by
using a separate connector.
Note: Always install the floor sensor in a conduit in the
floor.
N
IP21
T30
Dtouch
Mains
220-240V
50-60 Hz
Maximum
Load 16 (1) A
Sensor
Standby maximum 0.4W
L
L
L
O
A
D
NTC N
L
O
A
D
DEVIreg™ Touch
Installation Guide10
3. Mount and reassemble the thermostat.
• Fasten the thermostat to a socket or an exterior wall
box by driving the screws through the holes in each
side of the thermostat.
• Put the frame on.
• Click the display module back in place.
Important: Do NOT press on the display screen when click-
ing the display module back in place.
Initially main supply the thermostat for 15 hours to fully
charge the battery. The current time and day is then kept
for 24 hours if mains supply is off. All other settings are
stored permanently.
3 Settings
3.1 Initial Settings
Initial settings must be specified when the unit is activated
for the first time:
