Danfoss ECtemp™ Smart
Intelligent Electronic Timer Thermostat
with Wi-Fi connectivity and App control
Installation Guide
Danfoss ECtemp™ Smart
Installation Guide2
1 Introduction
ECtemp™ Smart is an electronic programmable timer
thermostat used for controlling electrical oor heating
elements. The thermostat is designed for xed installation
only and can be used for both direct heating of the entire
room and for comfort heating of the oor. Among others,
the thermostat has the following features:
1 Introduction . . . . . . . . . . . . . . . . . . . 2
2 Technical Specications . . . . . . . . . . . . 4
3 Safety Instructions . . . . . . . . . . . . . . . 6
4 Mounting Instructions . . . . . . . . . . . . . 8
5 Display Symbols. . . . . . . . . . . . . . . . 12
6 Conguring . . . . . . . . . . . . . . . . . . . 18
7 Settings . . . . . . . . . . . . . . . . . . . . . 19
8 Warranty. . . . . . . . . . . . . . . . . . . . . 22
9 Radio Equipment Directive . . . . . . . . 25
10 Disposal Instruction . . . . . . . . . . . . . 26
Table of Contents
Danfoss ECtemp™ Smart
3Installation Guide
• A touchscreen display with light.
• An easy-to-follow menu-driven programming and
operation.
• An installation wizard with room/oor type-specic
setup (requires an app).
• Support for multiple frame systems.
• Compatible with several 3rd party NTC sensors.
• Thermostat settings can be specied before instal-
lation and imported to the thermostat using a
web-generated code, or copied from a thermostat in
a similar installation.
• Smart access to thermostat settings after installa-
tion by using a web code interface, for easy setup or
remote troubleshooting.
Regarding Connectivity:
• 10 smart devices (like Smartphone or Tablet) can be
connected to 1 thermostat.
• 2 smart devices can be in contact with the thermo-
stat at the same time.
ECtemp™ SMART REQUIRES WORKING WIFI
TO FUNCTION
Danfoss ECtemp™ Smart
Installation Guide4
More information on this product can also be found at:
http://heating.danfoss.com/new-solutions/ectemp-smart
2 Technical Specications
Operation voltage 220-240 V~, 50/60 Hz
Standby power consumption Max. 0,40 W
Relay:
Resistive load
Inductive load
Max. 16 A / 3680 W @ 230 V
Max. 1 A cos φ= 0,3
Transmission Frequency 2,4 - 2,483.5 GHz
Transmission Power < 20 dBm
Sensing units NTC 6,8 kOhm at 25°C
NTC 10 kOhm at 25°C
NTC 12 kOhm at 25°C
NTC 15 kOhm at 25°C (Default)
NTC 33 kOhm at 25°C
NTC 47 kOhm at 25°C
Sensing values:
(Default NTC 15 K)
0°C
20°C
50°C
42 kOhm
18 kOhm
6 kOhm
Control PWM (Pulse Wide Modulation)
Danfoss ECtemp™ Smart
5Installation Guide
Ambient temperature 0 ° to +30 °C
Frost protection
temperature
5 °C to +9 °C (default 5 °C)
Temperature range Room temperature: 5-35 °C.
Floor temperature: 5-45 °C.
Max. oor: 20-35 °C (if unrecov-
erable seal is broken then up to
45 °C). Min. oor: 10-35 °C, only
with combination of room and
oor sensor.
Sensor failure monitoring The thermostat has a built-in
monitoring circuit, which will
switch o the heating if the
sensor is disconnected or short-
circuited
Cable specication max. 1x4 mm2
Ball pressure test temperature 75 °C
Pollution degree 2 (domestic use)
Controller type 1C
Software class A
Storage temperature -20 °C to +65 °C
IP class 21
Protection class Class II -
Danfoss ECtemp™ Smart
Installation Guide6
Dimensions 85 x 85 x 20-24 mm
(in-wall depth: 22 mm)
Weight 127 g
Electrical safety and Electro-Magnetic Compatibility for
this product is covered by the compliance with the EN/IEC
Standard“Automatic electrical controls for household and
similar use”:
• EN/IEC 60730-1 (general)
• EN/IEC 60730-2-9 (thermostat)
3 Safety Instructions
Make sure the mains supply to the thermostat is turned
o before installation.
Important: When the thermostat is used to control a
oor heating element in connection with a wooden oor
or similar material, always use a oor sensor and never set
the maximum oor temperature to more than 35 °C.
Danfoss ECtemp™ Smart
7Installation Guide
Please also note the following:
• The installation of the thermostat must be done by an
authorized and qualied installer according to local
regulations.
• The thermostat must be connected to a power supply
via an all-pole disconnection switch.
• Always connect the thermostat to continuous power
supply.
• Do not expose the thermostat to moisture, water,
dust, and excessive heat.
• This thermostat can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge, if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved, by a
person responsible for their safety.
• Children should be supervised to ensure that they do
not play with the thermostat.
• Cleaning and user maintenance shall not be made by
children without supervision.
Danfoss ECtemp™ Smart
Installation Guide8
4 Mounting Instructions
Please observe the following placement guidelines:
Place the thermostat at a suitable height on the wall
(typically 80-170 cm.).
The thermostat should not be placed in wet rooms.
Thermostat must be placed outside zone 2. Place it
in an adjacent room and use oor sensor only.
Always place the thermostat according to local
regulation on IP classes.
Do not place the thermostat on the inner side of a
poorly insulated exterior wall.
Always install the thermostat at least 50 cm from
windows and doors, due to draft, when using regu-
lation in: oor and room mode or room alone mode.
Do not place the thermostat in a way that it will be
exposed to direct sunlight.
Danfoss ECtemp™ Smart
9Installation Guide
Note: A oor sensor is recommended in all oor
heating applications and mandatory to thin mats
under wooden oors to reduce the risk of
overheating the oor.
• Place the oor sensor in a protecting plastic conduit
in the oor construction in an appropriate place,
where the oor is not exposed to sunlight or draft
from door openings.
• Equally distant and >2 cm from the heating cables
on both sides.
• The conduit should
be ush with the oor
surface, countersink
the conduit if neces-
sary and possible.
• Route the conduit to
the connection box.
• The bending radius of the conduit must be min 50
mm.
12
≥
Danfoss ECtemp™ Smart
Installation Guide10
Follow the steps below to mount the thermostat:
1. Unpack thermostat
2. Connect the thermostat according to the connection
diagram.
The screen of the heating
cable must be connected to
the earth conductor of the
power supply cable by using
a separate connector.
Note: Always install the oor sensor in a conduit in
the oor.
3. Fasten the thermostat rmly to a ush mounted wall
box or an exterior wall box by driving the screws
through the holes in each side of the thermostat.
4. Add the frame before assembling
of top part to the snap locks/bot-
tom part.
5. Click the front part module in
place. Pay attention, in relation to
IP21
T30
Mains
220-240V~
50-60 Hz
Maximum
Load 16 (1) A
Sensor
NTC
Danfoss A/S
Nordborgvej 81
6430 Nordborg
Denmark
NLL
L
O
A
DN
L
O
A
D
Standby maximum 0.4 Watt
