Quick Start Guide
MI-Q-TVE/E2-0
Installing the Hard Drive
The hard drive for the unit is provided un-installed.
1) Unlock the keylock on the front of the TransVu Express and withdraw
the caddy.
2) Remove from the protective packaging from the Hard drive and insert
into the caddy. Ensure the pins on the hard drive are pointing away
from the front of the caddy drawer and the label on the hard drive
is facing upwards and visible when the hard drive is placed in the
caddy.
3) Carefully slide the caddy back into the TransVu Express. Remember
to lock the caddy into the TransVu Express using the keylock. Failure
to do so will prevent the unit starting up.
Connections
Please ensure the following are available and have been tested prior to the
installation:
• 10~30VDCVehiclePowerSource
• Crossednetworkcablerequiredforwebpagesetup
• Activevideosignals.
• Correctlyterminatedcableloom,pleaseseeTransVuExpress
installation manual for further information.
• DeskorLaptopPCwithCDROMdrivewithInternetExplorer5.5
upwardsforunitconguration
• Notethatpin35oftheconnectorprovidesaswitchedoutputofthe
inputvoltageNOTa12Vregulatedsupply
WARNING: Operate the TransVu Express from the power source
indicated on the label. Failure to do so may cause injury, and
will invalidate the warranty. Under no circumstances make
connections to this unit whilst power is applied
.
37 way Connector Layout
Numbers looking at the front of the male connector.
1 19
3720
Read the Instructions First
Read all safety and operating instructions and labels before working with the
TransVu Express. This Quick Start Guide is not for use in isolation and should
always be used in conjunction with the main user manuals.
Pleasecontactthesupplierwithanyproblems.Reportanydifcultieswiththis
guidetoDedicatedMicrosattheUKofce.Addressesandphonenumbers
are given in the user guides and also in the Contacts area of the website at:
http://www.dedicatedmicros.com
Servicing
Donotattempttoservicethisunit.Openingorremovingcoversmayexpose
dangerousvoltagesorotherhazards.Referallservicingtoqualiedservice
personnel.
Lifting and Handling
Alwaysfollowhealthandsafetyguidelineswhenliftingtheunitfromthebox
or installing the TransVu Express unit.
Unpacking
Remove all the items from the box and check components listed below are
included.
The TransVu Express package contains the following items:
• TransVuExpressunit
• MountingPlate
• RubberShockMounts
• InstallationCDROM
• InstallationGuide
• Conguration&OperationGuide
• SetupGuide
• QuickStartGuide(thisdocument)
Ifanyoftheseitemsaremissing,pleasecontactthedistributerCustomer
Services department.
Location
• Drillingextraholesinthecasingoftheunitwillimmediatelyinvalidate
the warranty.
• Theunitshouldbemountedawayfromanypossibleplaceswhere
water may puddle during vehicle operation as the TransVu Express
casing is not rated for submersion.
The unit should be mounted on a secure base free from resonance and
secondary vibrations using the mounting plate provided.
• Atmentareaof290mmx190mmx90mm(11½”x7½”x3½”)is
required.
• Extraspaceisrequiredaroundtotheplugareatoensureeasy
removal.
• RefertoTransVuExpressInstallationandConguration&Operation
Guides for more information.
Pin Description
1
MonitorOutput(1Vp-pCVBSvideo)
2 Video ground
3 Camera8(1Vp-pCVBSvideo)
4 Camera5(1Vp-pCVBSvideo)
5 Videoground
6 Camera4(1Vp-pCVBSvideo)
7 Camera1(1Vp-pCVBSvideo)
8 Audioground
9 AudioInput2(mic-level)
10Relayoutput(negativeside)
11COM3port:RS-232TXD
1210/100Ethernetport:TX+
1310/100Ethernetport:TX-
14AlarmInput1
15AlarmInput3
16 Switched power output – negative
17Powerinput-negative:ground
18Powerinput-negative:ground
19Videoground
Pin Description
20Camera7(1Vp-pCVBSvideo)
21Camera6(1Vp-pCVBSvideo)
22 Video ground
23Camera3(1Vp-pCVBSvideo)
24Camera2(1Vp-pCVBSvideo)
25Videoground
26AudioInput1(line-level)
27Relayoutput(positiveside)
28Alarmground
29AlarmInput2
30Ignitionsenseinput
31COM3port:RS-232RXD
32COM3ground
3310/100Ethernetport:RX+
3410/100Ethernetport:RX-
35Switchedpoweroutput–positive(1A)
36Powerinput-positive:10V–30VDC
37Powerinput-positive:10V–30VDC
15 way Expansion Port Layout
Numbers looking at the front of the male connector.
1
6
5
10
15
11
PIN NO. FUNCTION
1 POWERMANGERRS232-RXD
2 POWERMANGERRS232-TXD
3 GND
4 COM1RS232-RXD
5 COM1RS232-TXD
6 COM2-RS485+/RS422_TX+
7 COM2-RS485-/RS422_TX-
8 GND
9 COM1CTS
10 COM1RTS
11 COM2-RS422_RX+
12 COM2-RS422_RX-
13 GND
14 AUDIOOUT0linelevel
15 AUDIOOUT1linelevel
