Installation Guide

Professional Digital Vehicle Video System and

Live Streaming Gateway

860-00201-00 Rev 0.9

November 2013

transmitted in whole or part in any form or by any means electronic, mechanical, recording, photocopying, or in any other manner

without the prior written approval of Digital Ally, Inc.

Digital In-Car Video System

Installation Guide

On behalf of the Digital Ally team, I want to thank you for this order. We appreciate the trust and

confidence you have shown us.

We will strive to do everything we can to provide you with the best products, support and customer

service. Please know we have a team of engineers, sales, manufacturing, customer service,

accounting, technicians and support personnel who work to provide the excellent customer

experience and satisfaction you demand and of which is the cornerstone of our business.

Below are a few comments and suggestions before you get started with the installation of your

Digital Ally DVM-Live system:

•

The DVM-LiVE is designed to be easily installed into virtually any make or model of

vehicle.

•

Please check the packing list against the items enclosed to make sure you have received all

the items.

•

Pictures of the various components of the system are shown throughout this guide to assist

you.

•

Please refer to the DVM-Live Operation Guide for operating instructions. You can print this

document off of the CD you received with your order.

•

The default passwords to access the DVM can be located on page 4-1 of this document.

•

A system diagram is provided on page 2-5 of this document, and wiring connections chart is

provided on page 2-6.

If you need any help, have any questions, or just want to provide some comments, please feel free to

Best regards,

Stanton Ross, CEO

Digital Ally, Inc.

9705 Loiret Blvd

Lenexa, KS 66219

Ph: 800-440-4947 or 913-814-7774

Fax: 913-814-7775

Email: support@digitalallyinc.com

Website: www.digitalallyinc.com

Table of Contents

SECTION - 1: BEFORE YOU BEGIN ............................................................................................................1-1

TOOLS NEEDED ....................................................................................................................................................1-1

CAUTIONS AND NOTES .........................................................................................................................................1-1

SECTION - 2: PARTS LISTS AND SYSTEM DIAGRAMS..........................................................................2-1

STANDARD PARTS KIT..........................................................................................................................................2-1

OPTIONAL PARTS LIST .........................................................................................................................................2-2

DVM LAYOUT CONFIGURATION...........................................................................................................................2-4

SYSTEM DIAGRAM ...............................................................................................................................................2-5

WIRING CONNECTIONS CHART.............................................................................................................................2-6

SECTION - 3: INSTALLATION INSTRUCTIONS .......................................................................................3-1

STEP 1: FACTORY MIRROR REMOVAL...........................................................................................................3-1

Screw Mount Rearview Mirror Removal ......................................................................................................3-1

Wedge (screw-less) Mount Rearview Mirror Removal .................................................................................3-1

Cam Lock Rearview Mirror Removal...........................................................................................................3-1

STEP 2: DVM INSTALLATION .......................................................................................................................3-2

STEP 3: INTERFACE BOX INSTALLATION .......................................................................................................3-3

Interface Box ................................................................................................................................................3-3

Mount the IO box..........................................................................................................................................3-3

DVM to Interface Box Cable Installation.....................................................................................................3-3

STEP 4: POWER, GROUND, AND INPUT SENSOR CONNECTIONS.....................................................................3-4

Power Cable Installation..............................................................................................................................3-4

I/O Cable Installation...................................................................................................................................3-4

Determine the Device Trigger(s) Signal Level .............................................................................................3-5

Output Alarm Trigger ...................................................................................................................................3-6

RJ45 to Terminal Connector Adapter (optional)..........................................................................................3-7

Siren Adapter Interface ................................................................................................................................3-7

STEP 5: WIRELESS MIC INSTALLATION .........................................................................................................3-7

DWM800 Wireless Microphone Cable Installation ......................................................................................3-8

STEP 6: FRONT CAMERA INSTALLATION ......................................................................................................3-9

STEP 7: GPS ANTENNA ................................................................................................................................3-9

STEP 8: WI-FI ANTENNA ..............................................................................................................................3-9

STEP 9: LIVE STREAMING GATEWAY ............................................................................................................3-9

Video Connections........................................................................................................................................3-9

Power Connections ....................................................................................................................................3-10

Antenna Connections..................................................................................................................................3-10

SECTION - 4: TESTING THE INSTALLATION ..........................................................................................4-1

INITIAL POWER UP...............................................................................................................................................4-1

RECORD AN EVENT...............................................................................................................................................4-1

VIEWING THE BACKUP CAMERA (IF INSTALLED).................................................................................................4-1

INPUT SENSOR & WIRELESS MICROPHONE TESTS................................................................................................4-1

SECTION - 5: SUPPORT..................................................................................................................................5-1

HOW TO RESET THE DVM-LIVE SYSTEM ............................................................................................................5-1

BASIC TROUBLESHOOTING...................................................................................................................................5-1

SECTION - 6: CONTACT INFORMATION ..................................................................................................6-1

SECTION - 7: INTERFACE BOX SENSOR WORKSHEET .......................................................................7-1

Digital Ally, Inc. | Before you Begin

1-1

Section - 1: Before you Begin

This document references the installation of the DVM-LiVE system, external cameras, and the cabling

harnesses.

Tools Needed

#2 Phillips head screwdriver

#20 Torx screwdriver or bit

1/8" (4 mm) flat-blade screwdriver

Digital Volt Meter

Tie wraps

Cautions and Notes

Please read and follow the instructions and precautions in this installation guide when installing DVM-

LiVE product.

•For assistance, a qualified installation technician or mechanic should be consulted.

•Do not use excessive force when removing the mirror from the windshield. The mirror mounting

plate may become separated from the windshield and/or the windshield may break if excessive

force is used. If you are unfamiliar with rearview mirror removal seek professional assistance.

•Do not route wiring and cabling over sharp metal edges where they may become damaged or

cut.

•To prevent electrical shorts or breakage in the wiring and cabling, do not allow wiring and

cabling to be pinched behind trim pieces, panels, or other physical objects.

•Do not run wires or cables in areas where they may become damaged by heat from the engine

or the exhaust system.

•Do not install any DVM components or wiring in the deployment path of the air bag(s).

•When installing the cables or making wire connections, it is recommended you leave a little

‘slack’ in the cable connections to allow for service loops and for movement of the mirror so the

connections do not get pulled or accidentally disconnected.

•Where possible, avoid running cables parallel to other wiring and/or antenna coax that may be

installed in the vehicle.

•Where possible, do not leave excessive cable above the headliner. We recommend at least 2

feet of distance between our cabling and that of other systems which may carry a signal for

transmit and/or receive

Digital Ally, Inc. | Parts Lists and System Diagrams

2-1

Section - 2: Parts Lists and System Diagrams

Standard Parts Kit

Part Number

Description

001-00049-32

DVM-Live Package, 32GB

566-00127-00

Camera, CAM-10XC, 10x with built-in controls

008-01443-00

Cable, DVM-LiVE to 10xC Camera and BNC

002-05095-00

Wireless Mic, DVM-LiVE System

008-01455-00

Cable, DWM-800 to DVM-LiVE

004-09058-00

Cable, Back Seat Microphone to DWM-LiVE, 20ft.

2.5mm plug

001-00010-00

Wi-Fi Assembly

006-08210-00

IO box (model IFE-20)

008-01388-00

Vehicle Power to IO box Cable 3.1m (10.1ft.)

008-01386-00

IO Box to DVM Power Cable 2.5m (8.0ft.)

008-01362-00

IO Box RJ45 Sensor Cable 7.6m (25ft.)

008-01410-00

GPS Module

001-00500-00

2 Channel Live Video Streaming Module

860-00202-00

Quick Reference Guide

006-08255-00

Visor Mount For external front Camera

008-01419-25

BNC cable 25ft (2)

Digital Ally, Inc. | Parts Lists and System Diagrams

2-2

Optional Parts List

Part Number

Description

008-01386-01

008-01386-02

008-01386-03

IO Box to DVM Power Cable 4.6m (15ft.)

IO Box to DVM Power Cable 6.1m (20.0ft.)

IO Box to DVM Power Cable 8.1m (26.5ft.)

566-00038-00

License Plate Backup Camera ( includes mounting

screws, pigtail cable, center mount & side mount

license plate brackets)

566-00040-00

Aux Surface Mount Backup Camera Normal Image

(includes mounting h/w & mounting bracket)

008-01390-01

Backup Camera Cable 12.2m (40.0ft.)

008-01382-00

008-01382-01

008-01382-02

008-01382-03

Backup Camera 25ft Extension Cable

Backup Camera 40ft Extension Cable

Backup Camera 60ft Extension Cable

Backup Camera 15ft Extension Cable

006-08193-00

Assembly, DVM-250 Camera Switch Box

002-00028-00

SD Card Reader

363-00050-00

32GB External SD card

740-00388-00

Panel Mount Remote Activation Switch

740-00399-00

Footswitch, Maintained (18/2AWG, 6ft, bare leads)

002-05107-00

Terminal Block Kit (for input sensors)

002-05030-00

Drop Mount Adapter

Digital Ally, Inc. | Parts Lists and System Diagrams

2-3

002-05102-00

Kit, Big Ball Mount Adapter

002-05112-00

Windshield Mount Adapter Kit, Dodge Charger

001-00501-00

4 Channel Live Video Streaming Module

860-00151-00

VuVault™ Stand Alone Software DVD

860-00152-00

VuVault™ Server/Client Software DVD

860-00153-00

VuVault™ Enterprise Software DVD

Digital Ally, Inc. | Parts Lists and System Diagrams

2-4

DVM Layout Configuration

LCD Display: Used for viewing video.

Internal microphone: Records audio from the passenger compartment.

Manual Record key: This key is used to start/stop a manual event recording when

pressed.

Status Indicators (Passenger facing & Road facing): These visible indicators give the

operator feedback on the operational status of the DVM.

Infrared Illuminators: Automatically provides Infrared illumination for the passenger

facing camera during low light conditions.

Passenger facing camera: Records video of the vehicle passenger area

Ambient Light Sensor: Senses ambient light to automatically adjust LCD brightness

Menu and Playback Buttons: Used to navigate the DVM menus, play back videos, and log

into the system.

External SD Card (optional): An optional external SD card can be installed behind the

external SD door. The SD card is installed at a slight angle and positioned with the

connector pads as shown above.

External SD door: Provides access to the external SD card.

External Camera 1 Port: An external camera can be connected to the DVM with this port.

USB Port: For data transfer and Wi-Fi download

External Camera 2 Port: Reserved for future use

External GPS Port: The supplied GPS antenna is connected here.

Power port: This port is used to provide power to the DVM or can be used to attach the

interface box to the system.

Reset Button: Used to perform a hard reset of the system.

BNC Video Output: Connects to the Streaming Gateway video input.

External Audio Input: The DWM-LiVE audio cable is connected here.

Digital Ally, Inc. | Parts Lists and System Diagrams

2-5

System Diagram

DWM-800 Wireless Microphone

& Charger (page 3-10)

GPS Antenna

Input Sensor Connections

(See page 2-6 and 3-5)

DVM-LiVE™

Rear Panel

Interface Box (page 3-3)

I/O Box to DVM Cable

BTR800 Cable

(page 3-7)

Front Camera

DWM800 Wireless

Microphone Connections

(See page 2-6 and 3-8)

Main power cable

connections

(See page 2-6 and 3-4)

Chassis Ground

Live Streaming Gateway

BNC Cable

3G or 4G

Antenna

Front Camera Y Cable

Gateway power cable

connections

(See page 3-10)

Wi-Fi Antenna

BNC Cable

Digital Ally, Inc. | Parts Lists and System Diagrams

2-6

Wiring Connections Chart

Input Signal

Color

Pin #

Description

Main Power Cable (page 3-4)

Battery

Red

+12VDC Un-switched Power. REQUIRED. Digital Ally recommends

connecting directly to the engine compartment battery

Ignition

+12VDC Switched. +12V power only when ignition is in the ACC or On

position. Ignition is used to cycle the system power on and off.

Ground

Black

Chassis Ground. Secure directly to vehicle frame

Input Sensor Cable (page 3-5)

Reverse

Red

Connect to reverse gear relay, or reverse light bulb

Emergency Lights

Orange

Emergency Light interface. +12VDC when lights are activated. Connect

to light bar controller

Brakes

Blue

Connect to brake pedal switch or 3rd brake light. +12VDC when brake is

active

Siren

Connect to +12VDC when siren is ON.

Sensor 5

Configurable input sensor

Mic Trigger Out

Green

Connect to Green wire of DWM800 Wireless Microphone Cable

Mic Trigger In

Brown

Connect to Brown wire of DWM800 Wireless Microphone Cable

Ground

Black

Chassis Ground

DWM800 Wireless Microphone Cable (page 3-8)

Battery

Red

+12VDC Un-switched Power. Digital Ally recommends connecting

directly to the engine compartment battery

Ground

Black

Chassis Ground

Mic Trigger Out

Green

Connect to Green wire of Input Sensor Cable

Mic Trigger In

Brown

Connect to Brown wire of Input Sensor Cable

Remote Accessory

Out

Violet

Connect to auxiliary equipment (optional connection)

Inhaltsverzeichnis

Andere Digital-Ally DVR Handbücher

Digital-Ally

Digital-Ally DVM-100 Bedienungsanleitung

Digital-Ally

Digital-Ally DVM-250 Bedienungsanleitung

Digital-Ally

Digital-Ally FirstVu HD Bedienungsanleitung

Digital-Ally

Digital-Ally FirstVu HD One Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
