16CH DVR Quick Start Guide V1.5 P.2
1. DVR
2. Quick Start
3. IR Remote Control *Pressed "DVR1" Button before use
4. Battery
5. CD
6. Hard Disk Mount
7. Screws
8. IDE to SATA Power Cord
9. Power Cord
10. SATA Cord
Note: Standard shipping products do not include HDD
16CH DVR Quick Start Guide V1.5 P.3
Step 1) Fix the HDD to rack mount with the screws as indicated.
Step 2) Place the HDD on the HDD plate and screw it as indicated.
Step 3) Connect the power and the SATA cables as indicated.
Note: After installation, please initialize Hard Disk before starting to record. For more detailed
information, please check out User Manual 4-9 System Tools for reference.
16CH DVR Quick Start Guide V1.5 P.4
DVD-RW Installation
(
Standard shipping products do not include HDD and DVD-RW)
Step 1:
Remove the front cover from DVR.
Step 2:
Put the DVD-RW into the unit as indicated.
Step 3:
Put DVR bottom up, screw to fix the
DVD-RW as indicated.
Step 4:
Connect the power and the flat
cables as indicated.
16CH DVR Quick Start Guide V1.5 P.5
①②③④⑤⑥⑦
⑧⑨⑩⑪ ⑫ ⑬ ○
14
Control Keys
Description
1. DVD Writer
Optional DVD-RW backup device.
2. LED Display
(From left to right)
Power:Power is on.
HDD: Hard disk is in use.
LAN: Connected to the internet (in red): Remote user logged in.
REC: Recording.
PLAY: Playing back.
3. /
In SETUP mode, press to move cursor down. In PLAYBACK mode, press
to stop playing back.
/SLOW
In SETUP mode, press to move cursor up. In PLAYBACK mode, press to
slow down.
/
In SETUP mode, press to increase value. In PLAYBACK mode press to
play forwards.
/
In SETUP mode, press to reduce value. In PLAYBACK mode, press to
play rewind.
4. REC
Start or stop recording.
5. PLAY
Play back in normal speed.
6. T-SH
Display the search menu.
7. BACKUP/ESC
In LIVE mode, press to display the BACKUP menu. In SETUP mode,
press to return to previous page.
8. USB 2.0 Port
Port for USB external devices (USB flash drive devices use, the mouse
behind the back of the USB ports installed)..
9. IR Sensor
Input sensor for the remote control.
16CH DVR Quick Start Guide V1.5 P.6
10. ENTER / MODE
In SETUP mode, press to enter values. In PLAYBACK mode, switch
between full, quad, 9-channel, 16-channel display in order.
11. PIP
In LIVE mode, display with picture in picture format.
12. ZOOM
In LIVE or PLAYBACK mode, enlarge the display of a channel.
13. AUTO
Auto Sequence display.
14. MENU / II
In LIVE mode, press to display menu. In PLAYBACK mode, press to pause
playback.
16CH DVR Quick Start Guide V1.5 P.7
1. MAIN monitor
BNC port for the main monitor. You can switch to SPOT
Monitor by GUI setting.
2. VIDEO IN
BNC input ports for cameras, 16 in total.
3. AUDIO OUT
RCA output port for audio signal.
4. EXTERNAL I/O
EXTERNAL I/O port.
5. Fan
DC 12V 40mm X 40mm fan.
6. AUDIO IN
RCA input port for audio signal. 4 ports available for 4CH/8CH.
16 ports available for 16CH.
7. IR JACK
IR extension cable jack.
8. HDMI
HDMI port.
9. VGA
VGA port.
10. USB 2.0 port
USB port. (Device USB Mouse).
11. LAN
Network port.
12. DC 12V
Socket for a DC 12V input.
13. ON/OFF
Power Switch.
14. e-SATA
External SATA hard disks port for expanding recording space.
EXTERNAL I/O
7
1
8 9 10 11 12 13 14
23 5
4
6
