Elcometer 320

Climate Monitoring System

Operating Instructions

This product meets the Electromagnetic Compatibility Directive and the Low Voltage Directive.

ElcoShip

®and

ElcoMaster

®are registered trademarks of Elcometer Limited.

®and Bluetooth®are trademarks owned by Bluetooth SIG Inc and licensed to Elcometer Limited.

All other trademarks acknowledged.

retrieval system or otherwise) or translated into any language, in any form or by any means (electronic,

mechanical, magnetic, optical, manual or otherwise) without the prior written permission of

Elcometer Limited.

A copy of this Instruction Manual is available for download on our Website via www.elcometer.com.

Doc.No. TMA-0478 Issue 02

Text with Cover No: 22783

CONTENTS

Section Page

1 About this gauge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2 Hardware Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3 Software Set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4 Maintenance and Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

6 Spare Parts and Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7 Related equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Thank you for your purchase of this Elcometer 320 Climate Monitoring System. Welcome to Elcometer.

Elcometer are world leaders in the design, manufacture and supply of inspection equipment for coatings

and concrete. Our products cover all aspects of coating inspection, from development through application

to post application inspection.

With the purchase of this product you now have access to the worldwide service and support network of

Elcometer. For more information visit our website at www.elcometer.com

1 ABOUT THIS GAUGE

The Elcometer 320 Climate Monitoring System allows the user to observe the climatic conditions

throughout their entire paint shop or factory over an existing network. The Elcometer 320 Climate

Monitoring System uses Elcometer’s market leading Elcometer 319 handheld Dewmeter® gauge backed

with specifically designed hardware and software to provide a user with the most complete solution to

ensure that conditions within an industrial coating setting are at their optimum level.

1.1 SYSTEM FEATURES

• Autonomous data collection

• Ready to connect to a local network

• Automatic daily reporting

• Minimal maintenance or intervention required

1.2 WHAT THE BOX CONTAINS

• Elcometer 319 Top Gauge

• Light and audible alarm system with power supply

• Elcometer 320 Climate Monitoring System Base Unit and power supply

•FlashCard

• Connection cables

• Elcomonitor Log and Elcomonitor View Software

• Bluetooth USB dongle

Your gauge is packed in a cardboard package. Please ensure that this packaging is disposed of in an

environmentally sensitive manner. Please consult your local Environmental Authority for further guidance.

To maximise the benefits of your new Elcometer 320 Climate Monitoring System please take some

time to read these Operating Instructions. Do not hesitate to contact Elcometer or your Elcometer

supplier if you have any questions.

2 HARDWARE SET-UP

Begin by inserting the Flash Memory card into the Elcometer 320 Climate Monitoring System Base Unit.

This card contains all of the software required to make the components work together and should be

present in the machine before it is switched on. Secondly, plug the Bluetooth USB dongle into a free USB

port on the Elcometer 320 Climate Monitoring System Base Unit. This will allow a connection to the

Elcometer 320 Climate Monitoring System in the event of a network problem.

The light system requires its own power socket and connection to the base unit via the socket marked

“COM1”. The Elcometer 319 gauge has a USB port underneath a rubber flap on the base of the gauge. It

may be connected by any of the other available USB ports on the base unit and is powered from this;

batteries are not required for the gauge to function as part of the Elcometer 320 Climate Monitoring

System. Finally, connect the Elcometer 320 Climate Monitoring System Base Unit to your network with a

suitable Ethernet cable and the Climate Station is ready. The on switch for the device is located on the

back of the Elcometer 320 Climate Monitoring System Base Unit.

The Elcometer 319 gauge may be used with an external temperature sensor if required. A K-type

connector is located beneath a rubber flap on the top of the gauge. Connect a sensor here and the gauge

will automatically switch from using the integrated surface temperature sensor to the external one. Note

that the integrated surface temperature sensor will be disabled and no measurements will be gathered

from it.

3 SOFTWARE SET-UP

3.1 INTRODUCTION

The Elcometer 320 Climate Monitoring System is provided with two pieces of software; Elcomonitor Log

and Elcomonitor View. Both pieces of software need to be present on the network in order for the system

to function. The software can be run in a client/server configuration on multiple machines or as a

standalone installation on one PC. If using the client/server configuration the Elcomonitor Log application

should be installed on a Windows 2003 or later server and the Elcomonitor View application should be

installed on Windows XP or later PCs. This configuration allows multiple view applications to be run on

separate workstations simultaneously.

If using the standalone installation the log application should be started up first followed by the view and in

all situations the log application must be running for the system to work.

3.2 THE ELCOMONITOR LOG APPLICATION

Begin by installing the Log Application onto your PC and following the on screen wizard. Once this is

complete, open the application.

The main screen will list all of the Climate Stations that the application has made a connection to via

Bluetooth or over a network. It will initially be empty as no stations have been added yet.

Search for Climate Stations via Bluetooth

If your PC is Bluetooth enabled you may connect to a Climate Station with this method when in range. The

button opens a wizard that allows you to find stations in range. The search process may take a

few minutes. Once complete, the application will indicate the stations located (if any) and checking the box

next to them will add them to the log. Click the Finish button to close the wizard

If the wizard is unable to find the Bluetooth Climate Station try again. Repeated failures may indicate that

the station is out of range.

Search for Networked Climate Stations

The application can search for Climate Stations hardwired to the same network with the button.

The wizard will search a range of IP addresses on a network and attempt to locate a Climate Station at

each address. This process will take several minutes to complete. Any new stations the wizard has found

will be displayed after the search has finished and these can be added to the log by checking the boxes

and pressing “Finish” on the wizard.

Manually Adding Climate Stations

If the search wizard is unable to locate some Climate Stations these may be added manually using the

button. A wizard will prompt for the host name or IP address of the station. The host name is a

unique label that is attached to every device on a network. Often this is the same as the “computer name”

that you can edit manually in windows. Every computer on a network also features a unique IP address,

which is what the network uses to route data to individual devices. Once the information is entered the

application will attempt to connect to the station at this address. If successful, the station will be added to

the log.

The main log screen will now be populated with the Climate Stations that have been added and the

application will attempt to connect to them and periodically request data. Information is displayed on

screen about when the last measurement set was downloaded from each station.

Additional Settings

The log software generates a daily report at 12:15am every day for the previous day’s data. To specify the

folder in which they are placed click the “Settings” tab and browse for the desired location. Leaving this

area blank will disable report creation.

Also available on this screen is a facility to protect the database with passwords for administrators and

users as well as a choice of units for the specific humidity reading. Finally, a logo can be placed in the top

right corner of the automatically generated report. Pressing the browse button allows you to locate any

compatible .jpg or .bmp image file in windows explorer.

Renaming a Station

Stations can be renamed into something more meaningful. Select the “Stations” tab, highlight the relevant

station and click the button. A window prompting for a new name will appear.

Starting and Stopping Stations

Individual Climate Stations can be started and stopped remotely using the button. Stopping a

station stops all climate data from being logged and hides the data in the Elcomonitor View software.

Stopped Stations may be restarted at any time with the button.

3.3 THE ELCOMONITOR VIEW APPLICATION

The Elcomonitor View software allows remote monitoring of the individual Climate Stations. All of the

readings the Climate Stations are taking are displayed here along with any warnings and notifications.

Install the Elcomonitor View software on any PC where you need to view the climatic conditions at each of

the Climate Stations. Ensure that the Elcomonitor Log application is running on the computer you have

chosen as the server before you continue.

When started for the first time, the software will request the address of the computer running the

Elcomonitor Log application. If this is the same as the computer on which you are installing the view

application on then leave this as “localhost”. The program will now start and you will be presented with a

dialog box requesting what level of access is required for a choice of either “Administrator” or “User”. The

features offered to both are as follows.

Note: Should you be unsure about the IP address of the server it is displayed in the “About” menu of the

Log application.

Stations

Stations are displayed in an alphabetically sorted grid with the individual climatic parameters selected by

the user. Measurements that have had limits defined are shown colour coded red, yellow or green in the

measurement panel as well as along the bottom of the screen.

Administrator User

View Station State ••

Generate Report ••

Setup Station •

Setup Filter on Station •
