Electrolux PURE i9 Bedienungsanleitung

Instruction Book

GB INSTRUCTION BOOK

CS 広㢝󱂖

VI 6&++ű஌1*'ଡ଼1

KO ꩡ끞꫙ꐺ꫑

TH   

CT 崹㢝㓚␙

ID BUKU PETUNJUK

Safety precautions

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision

or instruction concerning use of the appliance in a

safe way and understand the hazards involved.

The robot should only be used for normal

vacuuming in a domestic/indoor environment.

Make sure the robot is stored in a dry place.

All service or repairs must be carried out by an

authorized Electrolux service centre.

Remove the robot from the charger before

cleaning or maintaining your robot.

Do not allow children to play with the appliance.

Packaging material, e.g. plastic or fabric bags

should not be accessible to children to avoid

suocation.

The robot is designed for a specic voltage. Check

that your supply voltage is the same as that stated

on the rating plate on the charging adaptor.

Use only the original charging station and adaptor

designed for the robot.

Never use the robot:

• In wet areas.

• Close to ammable gases, etc.

• When the product shows visible signs of damage.

• On sharp objects or uids.

• On hot or cold ashes, lighted cigarette butts, etc.

• On ne dust, for instance from plaster, concrete,

our, hot or cold ashes.

• Do not leave the robot in direct sunlight.

• Avoid exposing the robot to strong heat.

• The battery pack within must not be dismantled,

short circuited or placed against a metal surface.

Use only the battery pack designed for the robot.

• Batteries must be removed from the appliance

before it is disposed of.

• The appliance must not be plugged in when

removing the battery.

• The battery is to be disposed of safely.

• Never use the robot without lter.

• Do not touch the brush roll while the cleaner is

switched on and the brush roll is turning. Do not

touch the wheels while the robot is operating.

Using the robot in a manner that conicts with

above recommendations may cause serious

personal injury or damage to the product. Such

injury or damage is not covered by the warranty or

by Electrolux.

The warranty does not cover reduction in battery

runtime due to battery age or use, as the life of the

battery depends upon the length and number of

times the robot is used.

Before cleaning, remove small and fragile objects

such as clothing, curtain strings, papers and power

cords from the oor. If the device passes over

a power cord and pulls it, there is a risk that an

object could be pulled o a table or shelf.

The robot is designed to not move any larger

objects in its way. Objects such as chairs can

therefore be left on the oor as the robot will clean

around them.

Strong light, mirrored walls, oor-to-ceiling

windows and very shining objects could disturb

the 3D Vision system.

Visit our website to:

Get usage advice, brochures,

trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories and Consumables for

your appliance:

www.electrolux.com/shop

Safety precautions

Recommended operation, charging and storage

environment for Electrolux battery products

1. Operation, charging and storage conditions

This product is intended to be used in normal

household environment and should not be

exposed to abnormal temperature.

To protect the internal parts of product it should

not be stored, charged or operated in:

• An ambient temperature below 10 °C or

exceeding 30 °C.

• If the product is stored in temperature below 10

°C or exceeding 30 °C. Please wait a few hours

so that the internal components of the products

can cool down or warm up and dry before usage.

Usage and storage outside temperature interval

might harm the product or reduce lifetime.

• Below 20% or over 80% humidity levels (Non-

Condensing)

Charge the product for minimum 24 hours:

• Before rst use.

• Before storage for a longer time period. (Remove

batteries from the robot before long time

storage.)

• After storage for a longer time period.

2. Dew condensation warning

Dew condensation may form inside the product

under the following conditions:

• The unit is moved from a cold to a warm place.

• Under conditions of very high humidity.

• After heating a cold room.

Please wait a few hours for the internal

components of the products to warm up and dry

before usage.

3. To preserve the battery life and performance:

• Always keep the robot charging when not in use.

• Charge it as soon as possible after the cleaning

cycle. Waiting too long might aect the

batteries.

Environmental concerns

This symbol on the product indicates

that this product contains a built-in

rechargeable battery which shall not be

disposed with normal household waste.

This symbol on the product or on its

packaging indicates that the product may

not be treated as household waste.

To recycle your product, please take it to an

ocial collection point or to an Electrolux

service center that can remove and recycle

the battery and electric parts in a safe and

professional way. Follow your country’s

rules for the separate collection of electrical

products and rechargeable batteries.

Customer care and service

When contacting the Electrolux service center,

ensure that you have following data available:

- Model number

- PNC number

- Serial number

The information can be found on the rating plate.

Model number

PNC number Serial number

安全注意事项

对于8岁及以上的儿童和存在身体、感觉或精神障

碍以及缺乏相关经验和知识的人士，在得到有关

安全使用的监督或指导并能理解相关危害的情况

下，才可以使用设备。

机器人只能用于家庭/室内环境中的正常吸尘用

途。

确保机器人存放在干燥位置。

所有维护或修理必须由授权的 Electrolux 服务中心

提供。

在清洁或维护机器人之前，将机器人从充电器处

断开。

请勿让儿童玩耍此设备。

所有包装材料（如塑料或织物袋）应置于儿童接

触不到的地方，以防窒息。

该机器人吸尘器设计用于特定电压。检查您的电

源电压是否与充电适配器铭牌上所标示的电压相

同。

只能使用专为本机器人吸尘器设计的原装充电基

座和适配器。

切勿在以下情况使用机器人吸尘器：

• 潮湿的地方。

• 接近易燃气体等。

• 产品出现明显的损坏迹象。

• 存在尖锐物体或液体。

• 存在热或冷的灰烬、点燃的烟头等

• 存在细粉尘，例如石膏、水泥、面粉、热或冷的

灰烬。

• 请勿将机器人置于阳光直射的地方。

• 避免将机器人暴露在强热环境中。

• 内部电池组不得拆卸、短接或放置在金属表面。

仅使用为此机器人吸尘器设计的电池组。

• 在处理之前，务必从设备上取下电池。

• 取出电池时，切勿将设备与电源连接。

• 电池应安全处理。

• 切勿在不使用滤网的情况下使用机器人吸尘器。

• 在清洁器打开且辊刷转动时，切勿触摸辊刷。机

器人运行时切勿触摸滚轮。

如果未按照上述建议使用机器人可能会导致严重

人身伤害或产品损坏。此类损伤或损坏均不在保

修范围内或由Electrolux承担责任。

保修不包括由于电池寿命或使用而导致的电池运

行时间缩短，因为电池寿命取决于机器人吸尘器

的使用时间长短和次数。

清洁前，从地板上清除衣物、窗帘绳、纸张和电

源线等小而易碎的物体。如果设备经过电源线并

拉动电源线，则存在将物体从桌子或架子上拉下

的风险。

机器人设计不会移动途中任何较大物体。因此，

椅子等可以留在地板上，因为机器人将在避开而

在它们周围清洁。

强光、镜面墙、落地窗和非常炫目的物体可能会

干扰3D视觉系统。

请访问我们的网站：

获取使用建议、产品说明，或和伊莱克斯

客户服务中心联系取得服务信息或获取耗

材和配件购买信息：

www.electrolux.com.cn

客服电话：

95105801

800-820-0096

安全注意事项

Electrolux电池产品的推荐操作、充电和储存环境

1.操作、充电和储存条件

本产品适用于正常家庭环境，不应置于异常温度

中。

为了保护产品的内部零件，不应在以下场所存

放、充电或操作：

• 环境温度低于10°C或超过30°C。

• 如果产品的储存温度低于10°C或超过30°C。请

等待几个小时，在产品的内部组件冷却或升温及

干燥后方可使用。在室外温度范围使用和存储设

备可能会损害产品或降低使用寿命。

• 湿度低于20%或超过80%（非冷凝）

以下情况产品充电至少24小时：

• 首次使用前。

• 在长时间存放之前。（长时间存放之前请取出机

器人的电池。）

• 长时间存放之后。

2.露水冷凝警告

在以下条件下可能在产品内部形成露水冷凝：

• 本机从寒冷处移动到温暖处。

• 在极高湿度条件下。

• 加热寒冷的房间后。

请等待几个小时，以便产品的内部组件在使用前

升温和干燥。

3.为维持电池寿命和性能：

• 始终保持机器人在不使用时充电。

• 在清洁周期后尽快充电。等待太久可能会影响电

池。

* 如有必要，授权服务中心将要求您提供购买发票

或其他购买凭据作为维修依据。

*型号会根据销售国家

级产品颜色或配置不

同而不同

环境问题

产品上的此符号表示本产品包含内置的可充

电电池，不得与普通生活垃圾一起处理。

产品或包装上的此符号表示该产品不能作为

家庭废弃物来弃置。

要回收您的产品，请将其送至官方收集点或

Electrolux服务中心，以便以安全和专业的方

式清除和回收电池和电气部件。按照您所在

国家的规定，单独收集电气产品和可充电电

池。

客户服务

联系Electrolux服务中心时，

请务必提供以下数据：

- 型号

- PNC编号

- 序列号

可以在铭牌上找到相关信息。

型号*

PNC编号

序列号

66 Overview of the robot / 机器人吸尘器概述

15 20

413

English 简体中文版

Before starting

• Unpack your Electrolux PUREi9 robot vacuum cleaner and check that all accessories are

included.*

• Read the instruction manual carefully.

• Pay special attention to the Safety advice chapter.

We recommend that you download the ”PUREi9” App, and update the software before the rst use.

Enjoy your Electrolux PUREi9 robot vacuum cleaner!

Table of contents:

Safety precautions ................................................................2

Consumer information and sustainability policy .......................................2

How to use the robot ..............................................................8

How to connect to the ”PUREi9”APP .................................................9

Tips on how to get the best results .................................................11

Emptying the Dust container ......................................................13

Cleaning/Replacing the Filter ......................................................13

Cleaning and maintenance ........................................................14

Changing the batteries............................................................15

Error handling ...................................................................15

Troubleshooting ................................................................16

Description of your robot vacuum cleaner

1 Display / Control panel

2 ECO function button

3 SPOT cleaning button

4 Play/Pause button / O button (long press)

5 Home button

6 Clock

7 Dust container indicator

8 WIFI connection indicator

9 Scheduled cleaning indicator

10 Warning indicator

11 Battery status indicator

12 Fan unit

13 Air outlet

14 Bumper

15 Side brush

16 3D Vision System (Camera)

17 Main wheels

18 Charging connectors

19 Brush roll lid

20 Brush roll

21 Battery compartments

22 Dust container release button

23 Dust container lid

24 Filter

25 Filter frame (and mesh net)

26 Dust container

27 Charging base

28 Charging connectors

29 Power adaptor and cord

* Accessories may vary from model to model.

使用前指南

• 打开Electrolux PUREi9机器人吸尘器包装，并检查是否包括所有附

件。

• 请仔细阅读本说明手册。

• 应特别注意安全建议章节。

我们建议您下载“PUREi9”应用，并在首次使用之前更新软件。

享受Electrolux PUREi9机器人吸尘器的服务！

安全预防措施 ..................................... 4

消费信息和可持续政策. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

如何使用机器人吸尘器. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

如何连接到“PUREi9”应用 ........................... 9

如何发挥理想效果的提示 .............................11

清空集尘盒 .......................................13

清洁/更换滤网 .....................................13

清洁和维护 .......................................14

更换电池 .........................................15

错误处理 .........................................15

疑难解答 .........................................17

机器人吸尘器的说明

1 显示/控制面板

2 节能模式功能按钮

3 SPOT定点清洁按钮

4 运行/暂停按钮/关闭按钮（长按）

5 主页按钮

6 时钟

7 集尘器指示灯

8 WIFI连接指示灯

9 计划清洁指示灯

10 警告指示灯

11 电池状态指示灯

12 风扇装置

13 出风口

14 防撞缓冲器

15 侧边毛刷

16 3D视觉系统（摄像机）

17 主滚轮

18 充电接头

19 辊刷盖

20 辊刷

21 电池仓

22 集尘盒释放按钮

23 集尘盒盖

24 滤网

25 滤网框架（和网格网）

26 集尘盒

27 充电基座

28 充电接头

29 电源适配器和电源线

* 配件可能因型号而异。

Content / 内容

88 How to use the robot vacuum cleaner / 如何使用机器人吸尘器

1. Place the Charging base on the floor against the wall.

Plug the adaptor to the power jack on the side of the base.

Connect the Power cord plug to the main socket. Wind up

excessive cord on the back of the base. Make sure there is

an empty area of 0.5 m on the sides and 1.5 m in front of

the Charging base.

WiFi model: Place the base in range of the WiFi router.

2. Place the side brush.

Note: If the robot is used to clean rooms with wall-to-wall

carpet, remove the side brush for best cleaning results.

3. Place the robot on the Charging base.

The Battery icon will pulse, to indicate that the robot is

recharging.

3. 将机器人吸尘器放在充电基座上。

电池图标将闪烁，表示机器人吸尘器正在充

电。

Installation of the robot vacuum cleaner

安装机器人吸尘器

1. 将充电基座放在地板上，靠在墙边。将适配器

插入底座侧面的电源插孔。将电源线插头连接

到主插座。收起基座背面过长的电源线。确保

充电基座两侧有0.5 m的空间，前面有1.5 m的

空间。

WiFi型号：将基座放在WiFi路由器的范围内。

2. 安上侧毛刷。

注意：如果机器人吸尘器用于清洁完全覆盖地

毯的房间，请取下侧毛刷，以获得理想清洁效

果。

2. To preserve the battery life and performance:

- Always keep the robot charging when not in use.

- Charge it as soon as possible in the charging base after the

cleaning cycle. Waiting too long might affect the batteries.

2. 为维持电池寿命和性能：

- 始终保持机器人吸尘器在不使用时充电。

- 在清洁周期后，在充电基座中尽快充电。等待

太久可能会影响电池。

3. Storage (not plugged): In case the robot is stored

without being charged for a longer period of time, remove

the batteries and store them separately. (Charge batteries

before removing them).

To remove the batteries see instruction page 15.

3. 存放（未插入插座）：如果机器人吸尘器需在

较长时间不充电的情况下存放，请取出电池并

单独存放。（在取出电池之前对其充电）。

如何取出电池，请参见第15页说明。

1. Red battery (A) indicates that the robot needs to get

charged.

Red light pulse (B):The robot is charging – Low

charging level.

White light pulse (C):The robot has charged enough to

be used. (Press Play/Pause button to clean.)

White light (D):The robot is ready for use.

Full charging time is ~

3 hours.

1. 红色电池 (A) 图标表示机器人吸尘器需要充

电。

红灯闪烁 (B)：机器人吸尘器正在充电 – 电量

较低。

白灯闪烁 (C)：机器人吸尘器所充电量已足够

使用。（按运行/暂停按钮进行清理。）

白灯 (D)：机器人吸尘器准备就绪。

充满电约需 3 小时。

电池/充电状态

Battery/Charging status

A B C D

0.5

1.5

Large rooms will be divided into cells of at most 2 x 2 m.

Note: The cleaning pattern is more ecient if the robot is

started next to a wall.

2. 大房间将分为最大2 x 2米的区域。

注意：如果机器人吸尘器靠近墙壁启动，清洁

模式将更高效。

~2m

How to use the robot vacuum cleaner / 如何使用机器人吸尘器

1. Download the ”PUREi9”App in the App Store or

Google play and then follow the instruction to create the

account and connect to the robot.

Note: Make sure that the phone is connected to the home WiFi

(2.4 GHz).

2. During the process the App will ask you to turn the

robot upside down to activate the WiFi module and scan

the serial number bar code (A) or enter it manually (B).

Then continue following the instruction from the App.

Note: before turning the robot, make sure that it has been

switched on for at least one minute.

3. When the setup is completed, turn the robot back

to its normal position.TheWiFi symbol (A) will be lit

up to indicate that the robot is connected to your home

network. Note: it could take a few moments for the robot

clock to automatically synchronise with your mobile device.

Note: Pulsing WiFi symbol indicates that the robot is trying

to connect to the network.

1. 按下运行/暂停按钮 (A) 开始清洁。

启动几秒钟后，清洁程序将开始。机器人吸尘

器将开始沿着墙壁

向内清洁。

注意：按下“运行/暂停” (A) 按钮暂停清

洁，长按该按钮则会终止清洁。

在App Store或Google Play中下载“PUREi9”应用，

然后按照说明创建帐户并连接到机器人吸尘器。

注意：确保手机已连接到家庭WiFi (2.4 GHz)。

2. 在此过程中，应用会要求您翻转机器人吸尘器

以激活WiFi模块并扫描序列号条形码 (A) 或手

动输入条形码 (B)。然后继续按照App的指示操

作。

注意：在翻转机器人吸尘器之前，确保机器人

吸尘器已经打开至少一分钟。

3. 设置完成后，将机器人吸尘器翻转回正常位

置。WiFi标志 (A) 将亮起，表示机器人吸尘器

已连接到家庭网络。

注意：机器人吸尘器时钟可能需要一段时间才

能与移动设备自动同步。

注意：WiFi标志闪烁则表示机器人吸尘器正在

尝试连接到网络。

Cleaning modes

How to connect to the ”PUREi9” APP We recommend to download the App and update the software before the first use.

我们建议在首次使用之前下载应用并更新软件。

清洁模式

如何连接到“PUREi9”应用

1. Press Play/Pause button (A) to start cleaning.

After a few seconds of start-up, cleaning will be

commenced.The robot will start cleaning alongside

walls, working its way inwards.

Note: Press “Play/Pause” (A) briey to pause cleaning, or

press and hold to terminate cleaning.

Cleaning schedule

清洁计划

Cleaning can be scheduled in the APP (Days & time)

可以在APP中制定清洁计划（日期和时间）

PUREi9

2.4 GHz

5 GHz

1010

When cleaning is completed, the robot automatically

returns to the charging base.

Note: If the robot is not started from the charging base,

it will return to the start position when nished.

Should recharging be needed during cleaning,

the home button will light up and the robot will return to the

charging base. Home button (A) is lit. The battery and Play/

Pause button (B) ash to indicate that the robot is charging

and that it will resume where it stopped.

The robot will recharge up to 80% to resume cleaning quicker.

Charging time is ~2 hours.

清洁完成后，机器人吸尘器自动返回充电基座。

注意：如果机器人没有从充电基座启动，

完成后将返回到开始位置。

如果在清洁过程中需要充电，

主页按钮将亮起，机器人吸尘器将返回充电基

座。主页按钮 (A) 亮起。电池和运行/暂停按钮

(B) 闪烁，表示机器人吸尘器正在充电，并将在

其停止的位置恢复运行。

机器人吸尘器将充电至最多80%以更快地恢复清

洁工作。充电时间约2小时。

Auto Docking/Charging

ECO Mode Docking SPOT Cleaning

自动返回基座/充电

节能模式返回基座定点清洁

Auto charging during cleaning cycle Crossing threshold

在清洁周期中自动充电跨越门槛

How to use the robot vacuum cleaner / 如何使用机器人吸尘器

ECO mode: For a lighter cleaning, press the ECO button to

reduce the power, prolong the running time and reduce noise

level.The robot will stay in ECO mode until the button is

pressed again.

Stop cleaning and send the robot to the charging base:

Press the Home button. If the robot is not started from the

charging base, it will return to the starting position.

SPOT cleaning (small area, ~1 m): Place the robot facing

the spot and press the SPOT button. The robot will will clean

the area twice.

节能模式：对于较轻松的清洁工作，请按ECO按

钮降低功率，延长运行时间并降低噪音水平。

再次按下此按钮之前，机器人吸尘器将保持经

济模式。

停止清洁并使机器人吸尘器返回充电基座：

按主页按钮。如果机器人吸尘器不是从充电基座

启动，它将返回起始位置。

定点清洁（小面积，大约为1平米）：将机器人

吸尘器面向定点区域放置，然后按SPOT按钮。机

器人吸尘器将清洁该区域两次。

Before crossing a threshold or climbing over any

obstacle, the robot will stop and check:

- the heights (A & B) on both sides of the threshold/obstacle

- that the area on the other side is clear to operate (C)

在跨越任何门槛之前，机器人吸尘器将停止并

检查：

- 门槛/障碍物两侧的高度（A和B）

- 另一侧区域是否开阔方便运行 (C)

Andere Handbücher für PURE i9

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Electrolux Staubsauger Handbücher

Electrolux

Electrolux TWINCLEAN CYCLONIC Bedienungsanleitung

Electrolux

Electrolux ERGORAPIDO Bedienungsanleitung

Electrolux

Electrolux Ergorapido EER73BP Bedienungsanleitung

Electrolux

Electrolux VOLTA Campus U4710 Bedienungsanleitung

Electrolux

Electrolux Z4680 SERIES Bedienungsanleitung

Electrolux

Electrolux JANITOR Z1516 Bedienungsanleitung

Electrolux

Electrolux Classic Silence ZCS2000 Bedienungsanleitung

Electrolux

Electrolux Jetmaxx Green ZJG-6800 Bedienungsanleitung

Electrolux

Electrolux ZVE 4110FL Bedienungsanleitung

Electrolux

Electrolux ZB 2901 Bedienungsanleitung

Electrolux

Electrolux AEG Ergorapido Bedienungsanleitung

Electrolux

Electrolux ZB2932 Bedienungsanleitung

Electrolux

Electrolux ULTRAONE Z8822GP Bedienungsanleitung

Electrolux

Electrolux CANISTER Bedienungsanleitung

Electrolux

Electrolux Ultrasilencer EUS8ALRGY Bedienungsanleitung

Electrolux

Electrolux Sanitaire C5800 Series Bedienungsanleitung

Electrolux

Electrolux TRILOBITE Bedienungsanleitung

Electrolux

Electrolux ZB 206 Bedienungsanleitung

Electrolux

Electrolux VAMPYRETTE 400 Bedienungsanleitung

Electrolux

Electrolux Rapido Vacuum Cleaner Bedienungsanleitung

Electrolux

Electrolux Ergorapido Ion Bedienungsanleitung

Electrolux

Electrolux Ultraactive Bedienungsanleitung

Electrolux

Electrolux Ergirapido ZB3011 Bedienungsanleitung

Electrolux

Electrolux PURE D9 PD91-ANIMA Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
