EverFocus EDSR100 Bedienungsanleitung

EDSR100

INSTRUCTION MANUAL

Digital Single Channel Recorder

About this manual

Before installing and using this unit, please read this Manual carefully.

Be sure to keep it handy for later reference.

V1.3

WARNING

TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Note:

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection. This equipment generates, uses and can radiated radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase these paration between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio/TV technician for help.

The changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

Notice:

The information in this manual was current when published. The manufacturer

reserves the right to revise and improve its products. All specifications are

therefore subject to change without notice.

Safety Warning

Refer all work related to the installation of this product to qualified service

personnel or system installers.

Do not block the ventilation opening or slots on the cover.

Do not drop metallic parts through slots.This could permanently damage

the appliance. Turn the power off immediately and contact qualified service

personnel for service.

Do not attempt to disassemble the appliance.To prevent electric shock,

do not remove screws or covers. There are no user-serviceable parts

inside. Contact qualified service personnel for maintenance. Handle the

appliance with care. Do not strike or shake, as this may damage the

appliance.

Do not expose the appliance to water or moisture, nor try to operate it in

wet areas. Do take immediate action if the appliance becomes wet.

Turn the power off and refer servicing to qualified service personnel.

Moisture may damage the appliance and also cause electric shock.

Do not use strong or abrasive detergents when cleaning the appliance

body. Use a dry cloth to clean the appliance when it is dirty. When the

dirt is hard to remove,use a mild detergent and wipe gently.

Do not overload outlets and extension cords as this may result in a risk of

fire or electric shock.

Do not operate the appliance beyond its specified temperature, humidity

or power source ratings. Do not use the appliance in an extreme

environment where high temperature or high humidity exists. Use the

appliance at temperature within 0oC ~ +50oC and a humidity below 90%.

The input power source for this appliance is AC90~265V.

Safety Precautions

The exclamation point within an equilateral triangle is

intended to alert the user to presence of important operating

and maintenance(servicing)instructions in the literature

accompanying the appliance.

Warning :

To prevent fire or shock hazard, do not expose units not

specifically designed for outdoor use to rain or moisture.

Safety Precautions

The lightning flash with an arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the presence

of uninsulated ” dangerous voltage” within the product’s enclosure

that may be of sufficient magnitude to constitute a risk of electric

shock to persons

Attention:

Installation should be performed by qualified service personnel only

in accordance with the National Electrical Code or applicable local codes.

Power Disconnect:

Units with or without ON-OFF switches have power supplied to the unit

whenever the power code is inserted into the power source; however, the

unit is operational only when the ON-OFF switch is in the ON position.

The power cord is the main power disconnect for all units.

External Power Supplies

Use only the recommended power supplies.

Power supplies must comply with the requirement of

the latest version of IEC 60065/CNS 13439. Substitutions

may damage the unit or cause a fire or shock hazard

110V,60Hz Power Cords

110V,60Hz power cords, input and output, must comply with

the latest versions of IEC 60065/CNS 13439

Warning:

Electrostatic-sensitive device. Use proper

CMOS/MOSFET handing precautions to avoid

electrostatic discharge.

UNPACKING

Unpack carefully.

This is electronic equipment and should be

handled carefully.

Check to ensure that the following items are included;

•1. Digital Single Channel Recorder

•2. User’s manual

•3. CF card reader

•4. Power Cord

If an item appears to have been damaged in shipment,

replace it properly in its carton and notify the shipper.

If any items are missing, notify your

Everfocus Electronics Corp. Sales Representative or

Customer Service. The shipping carton is the safest

container in which the unit may be transported.

Save it for possible future use.

Service

If the unit ever needs repair service, the customer

should contact the nearest Everfocus Electronics Corp.

Service Center for return authorization and shipping

instruction.

Safety Precautions

Important Safeguards

Read Instruction---All the safety and operating instructions should be read before the init is operated

Retain Instructions---The safety and operating instructions should be retained for future reference.

Heed Warnings—All warnings on the unit and in the operating instructions should be adhered to.

Follow Instructions—All operating and use instructions should be followed

Cleaning—Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.

Use a damp cloth for cleaning

Attachments—Do not use attachment not recommended by the product manufacturer as they may cause hazards.

Water and Moisture—Do not use this unit near water-for example, near a bath tub, wash bowl, kitchen sink,

or laundry tub, in a wet basement, near a swimming pool, in an unprotected outdoor installation, or any area which is

classified as a wet location.

Servicing—Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified service personnel.

Power Cord Protection—Power supply cords should be routed so that they are not likely to be walked on or pinched by

items placed upon or against them, playing particular attention to cords and plugs, convenience receptacles, and the point

where they exit from the appliance.

Object and Liquid Entry—Never push objects of any kind into this unit through openings as they may touch dangerous

voltage points or short-out parts that could result in a fire or electric shock, Never spill liquid of any kind on the unit.

Important Safeguards

Table of Contents

1. Product Overview……….…...……………………………………………………………………………………..………….. 1

1.1 Feature………...…….…….….…………………………………….…………..……………………………………………..1

1.2 Specifications………....………………….………………………………..………….……………………………………...2

2. Front & Rear Panels………...…….………………………………………..…………………………………………………....3

3. Back Panel Connections…….………...……………………………………..…………………………………………………..6

4. System Connection…....………………………...…………………………..…………….…………………….………………..9

4.1 One Camera Connection………….…..…….………………………………………………………..……………………….9

4.2 Multiplexer Connection...……….….……………………………………………………………...………………………..10

4.3 Quad Connection ( with VCR )………….……………….………………………………………..……………………… 11

4.4 Quad Connection ( without VCR)….….………….……………...……………………………………………………...….12

5. Installation………...………………………………………………..……………….….……………………………………….13

6. Menu………...……………….……………………………………..……………………………………………………………14

6.1 Clock/Language Setup…...………….………….…….…………………………………………………………………….15

6.2 Timer-Set Setting Menu..…………………...…….……….………………………...……………………………………...16

6.3 Normal Record Setting Menu……………….…..…………………………………………………...…………………..….18

6.4 Alarm Record Setting Menu…………………….………..……………………………………………………………...….20

6.5 Buzzer Setting Menu…………………….………………………………………………………….………………………22

6.6 Archive Setting Menu…………………...….…………….…………………………...…………………………………….23

6.7 Network Setting Menu…...……………………………………..……………………………………………………………24

6.8 System Setting Menu…………………………………………………………………………………………………………26

7. Recording…...……………...……………………………………………………………..……………………………………. 28

7.1 Instant Recording……………..…………………………………………………….……………………………………... 28

7.2 Alarm Recording……………………………………………………………………………….………………………….. 29

8. Playback…...…………………………………………………….……………………….…………………………………..… 30

8.1 Normal Playback…………………………………………………………………………………………………………... 30

8.2 Search Playback…………………………………………………………………………………………………………… 32

9. Copy………...……………………….…………………………………………………………….…………………….………35

9.1 Still Image Copy……………………………………………………………………………………………………………35

9.2 Copy to Movie File……...………………………………………………………………………………………………….36

10. Interface Specifications……..….……...……………………………………………………………………………………...38

10.1 Transmission setting……..……………………………..………………………….………………………………………38

10.2 Remote Control Protocol…………………………………..………………………………………………………..……..39

11. Remote Controller………….…….……………………………………………………………………………...……………40

12. Appendix-A/Time Lapse Mode Recording Time…….……..………………………………………………………....….....41

12.1 Recording with and 80 GB HDD…..…………...………………….…………………………………………….………..41

12.2 Recording with and 160 GB HDD…………..…………………………………………………………………………….42

13. Appendix-B/ Security Lock setting..…...…….………………………………………………………………………………43

14. Appendix-C/ View From Internet/Intranet……….…...……………………………………………………………….……44

1. Product Overview

The EDSR100 is the first true VCR replacement designed particularly for the security industry, seamlessly combining

high-resolution video multiplexing and digital recording.

The EDSR100 at speeds up to 60/50 images per second with NTSC/PAL formats and replay event

instantly.

The EDSR100 incorporates all the benefits of digital video recording, is simple to install, and operates just like

a VCR. The highly efficient compression technology, as well as the superior clarity and detail of recorder images,

make the EDSR100 stand out from its competitors as the best choice for security surveillance.

1.1 Features

Product Overview and Features

Digital Recording provides superior quality images

Hard-disk hot-swapping capability

Pre-Alarm image recording

Compatible with most multiplexers

Time lapse and real time recording

Refresh rate up to 60 field (50 field for PAL)

Quick Search by date/time, alarm events, and recording list

Fast and slow playback of recorded video in various speeds

On-screen setup menu and system timer

Multi-level password protection

RS-232 communication port

Highly stable non-PC based proprietary system

Built-in M-JPEG compression/decompression with configurable quality

Audio recording capability

Programmed with various time-lapse speeds, Data can be stored in Compact Flash Card.

Operation status record log



Specifications

0℃~+50℃

Operating Temperature

430mm (L) x 88mm (W) x 300mm (H)Dimension

AC90~265VPower Source

9-pin female connectorRS-232

YesWatch Dog Timer

Built-in real time clockTimer

Front Panel KeypadUser Input Device

Menu DrivenUser Interface

On screen display setupSetup

Date/Time or EventPlayback Search

60/50 field per second for NTSC/PALPlayback Rate

60/50 field per second for NTSC/PALRecording Rate

Continuous, Time-lapse recording,

Timer or Event Recording

Recording Mode

3.5” IDE type, Hot- swappableHard Disk Storage

YesEvent Log

RJ45 connectorEthernet

YesVideo Loss Detection

2 input; 2 outputAudio

YesAlarm Output

YesAlarm Input

Yes, Built-in Compact Flash card slotCompactFlash Memory

720x484 (NTSC); 720x576 (PAL)Video Resolution

M-JPEGVideo Compression

1 video output (BNC), 1Vpp/75ohm;1S-Video outputVideo Output

1 video input with loop through (BNC),

1Vpp/75ohm;1S-Video input

Video Input

1.2 Specifications

Power Consumption 39W

Andere Handbücher für EDSR100

Inhaltsverzeichnis

Andere EverFocus DVR Handbücher

EverFocus

EverFocus VANGUARD 16x8 Bedienungsanleitung

EverFocus

EverFocus DVR-900 Bedienungsanleitung

EverFocus

EverFocus ENVR8304D-8CH Bedienungsanleitung

EverFocus

EverFocus ELUX16x2 Bedienungsanleitung

EverFocus

EverFocus DHV-410M Bedienungsanleitung

EverFocus

EverFocus EDSR100M Bedienungsanleitung

EverFocus

EverFocus UNIGUARD 4 HDD Series Bedienungsanleitung

EverFocus

EverFocus PARAGON FHD 16x4 Bedienungsanleitung

EverFocus

EverFocus EDVR16D1/250 Bedienungsanleitung

EverFocus

EverFocus EDVR SERIES Installationsanleitung

EverFocus

EverFocus EPHD04+ HDcctv Bedienungsanleitung

EverFocus

EverFocus ECOR Series Bedienungsanleitung

EverFocus

EverFocus EMV800 HD Bedienungsanleitung

EverFocus

EverFocus MoniVue System ESN41 Bedienungsanleitung

EverFocus

EverFocus ECOR264X1 Series Installations- und Betriebshandbuch

EverFocus

EverFocus ECOR FHD 4F Bedienungsanleitung

EverFocus

EverFocus TUTIS-16F3 Bedienungsanleitung

EverFocus

EverFocus EMV1200 HD Bedienungsanleitung

EverFocus

EverFocus eIVP-CFS-IV-V0004 Bedienungsanleitung

EverFocus

EverFocus ELR-4 Bedienungsanleitung

EverFocus

EverFocus EDR810H Bedienungsanleitung

EverFocus

EverFocus Paragon EPARA16D3 Handbuch

EverFocus

EverFocus ECOR264-4D2 Bedienungsanleitung

EverFocus

EverFocus ENR 400 Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
