EverFocus EMV400 Bedienungsanleitung

EMV400 FHD-N / EMV800 FHD-N Lite

4CH/4CH 1080p Full HD Mobile DVR

Quick Installation Guide

Release Date: October 2021

All the images including product pictures or screen shots in this document are for example only. The images may

vary depending on the product and software version. Information contained in this document is subject to

change without notice.

EverFocus Taiwan:

2F., No.12, Ln. 270, Sec. 3, Beishen Rd., Shenkeng Dist., New Taipei City 222, Taiwan

TEL: +886 2 26622338 FAX: +886 2 26623632 www.everfocus.com.tw marketing@everfocus.com.tw

1. Overview

1.1 Front Panel

1235 6 7 8 910 2 11

No.

Name

Description

1Reset Press to reset the system.

2 USB2.0 Port Three USB2.0 ports for connecting to the USB storage device or mouse.

3 SD Card Slot Insert a SD / SDHC card (up to 32GB) for alarm event backup recording (see

2.3 SD Card Installation).

4 HDD Tray Install a 2.5” HDD (up to 2TB) for recording. Please refer to 2.2 Hard Disk

Installation.

5 HDD Lock Lock or unlock the HDD tray. Only when the HDD Lock is locked will the

system start to record in the HDD.

6 IR Receiver Receives data from the infrared remote control.

7 Function

Key

Press the button for 3 seconds to switch the RCA / BNC video output from

call monitor to main monitor; and to switch the VGA video output from main

monitor to call monitor. To switch back the main and call monitors, press the

button for 3 seconds again. Please refer to 2.6 Monitor Connection in the

User’s Manual.

8 System

LEDs

•Alarm: Turns on when the connected alarm I/O is triggered; turns off

when the alarm I/O stops being triggered.

•GPS: Turns on continuously when the mobile DVR is receiving GPS data.

•System Fail: Turns off when system is acting normally. Turns on when

these events occur: System Clock Error / Fan Fail / Disk Temperature Over

/ Disk Fail / Disk Off / Network Loss.

•Heater: Blinks when heater on; off blinking when heater off.

•HD R/W: Blinks when the HDD is reading or writing.

•Power: Turns on continuously when the power is supplied. Blinks when

Battery power error occurs (lower than 9V or higher than 36V) or 12VDC

power supply error.

Call

Monitor

(RCA)

By default, this port is set to a Call monitor output. Connects to a Call

monitor using a RCA cable.

Note: You can optionally switch this port from Call monitor to Main monitor.

Please refer to 2.6 Monitor Connection in the User’s Manual.

10 Audio Out

RCA audio output for connecting to the speakers. The audio output only

works during playback. Speakers with a (built-in) amplifier and external

power supply are required.

11 Ethernet

Port One RJ-45 port for connecting to the network.

1.2 Rear Panel

1 82 3 4 6 75

No.

Name

Description

1 DC Power

Input

Use the supplied Power Harness Cable for connecting to 9 ~ 36VDC power

source. For details, please refer to 2.5 Power Harness Cable.

2 Audio Input

D-Sub connector for connecting to the supplied Audio Cable. For details,

please refer to 2.4 Audio Cable / Video Cable / Power-Out Cable.

Microphones with a (built-in) amplifier and external power supply are

required.

3 12VDC Power

Outputs

A total of 12VDC, 5A power supply to the connected cameras. Please refer

to 2.4 Audio Cable / Video Cable / Power-Out Cable.

4 Call Monitor

(CVBS)

By default, this port is set to a Call monitor output. Connects to a Call

monitor using a BNC cable.

Note: You can optionally switch this port from Call monitor to Main

monitor. Please refer to 2.6 Monitor Connection in the User’s Manual.

5 Antenna

Ports

Connects to the 3G/4G or WiFi Antenna for using 3G / 4G LTE / WiFi

function.

6 Video Input

M12 connector for connecting to the supplied Video Cable. You can then

connect cameras to the Video Cable. Please refer to 2.4 Audio Cable / Video

Cable / Power-Out Cable.

7 Main Monitor

(VGA)

By default, this port is set to a Main monitor output. Connects to a Main

monitor using a VGA cable.

Note: You can optionally switch this port from Main monitor to Call

monitor. Please refer to 2.6 Monitor Connection in the User’s Manual.

8 D-Sub

Connector

D-Sub connector for connecting to the Alarm I/O, RS-232 (CAN bus) or

RS-485 devices (such as analog PTZ cameras). For details, please refer to

2.5.4 D-Sub Cable in the User’s Manual.

1.3 Packing List

•Mobile DVR x 1

•HDD Lock Key x 2 (with 4 screws for screwing HDD. See 2.2 Hard Disk Installation)

•Mounting Screws x 4 (with 8 spacers. See 2.1 Mounting)

•IR Remote Control (with two AAA batteries. See Note 3) x 1

•Power Harness Cable x 1

•Video Cable x 1 (EMV400 FHD-N); x2 (EMV800 FHD-N Lite) (see 2.4 Audio Cable / Video

Cable / Power-Out Cable)

•Audio Cable x 1

•D-Sub Cable x 1

•Power-Out Cable x 1

•Quick Installation Guide x 1

Note:

1. Equipment configurations and supplied accessories vary by country. Please consult your

local EverFocus office or agents for more information. Please also keep the shipping carton

for possible future use.

2. Contact the shipper if any items appear to have been damaged in the shipping process.

3. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries

according to the instructions.

a. Use only two AAA dry cell batteries.

b. Do not dispose of the batteries in a fire as it may explode.

1.4 Optional Accessories

The mobile DVRs feature Wi-Fi/3G/4G function. You can optionally connect Wi-Fi/3G/4G

module and antenna to the mobile DVR for networking, or connect a GPS receiver for GPS

function.

•

3G Antenna: For using 3G network function

•

4G Antenna: For using 4G LTE network (LTE

frequency bands differ among regions)

•Wi-Fi Antenna: For using Wi-Fi function

•GPS Receiver (LS23035): For using GPS

function

•

Reinforced Data Storage Device (64GB)

For recordings backup

2. Basic Installation

2.1 Mounting

The Bracket is already installed on the mobile DVR. To mount the mobile DVR onto a surface, use

the supplied 4 black screws and 8 spacers (place 2 spacers on each screw hole).

Spacer with a cut

Screw Hole

2.2 Hard Disk Installation

You can install a 2.5” HDD (up to 2TB) into the HDD tray for video recording.

1. Turn off the power of mobile DVR. Unlock the HDD Lock using the supplied HDD Lock Key.

Locked

Unlocked

2. Unscrew the HDD tray screws and then pull out the HDD tray.

3. Insert a HDD to the HDD tray and then screw the HDD using the supplied HDD screws.

HDD

HDD Screws

4. Put back the HDD tray to the system and then tightly screw the HDD tray screws.

5. Lock the HDD Lock.

2.3 SD Card Installation

The mobile DVRs provide SD card function for Alarm event backup recording. Please follow the

steps below to install the SD Card. Up to 128 GB SD / SDHC cards are supported.

1. On the front panel of the mobile DVR, unscrew the SD card protection plate. Move upward

the protection plate and then insert the SD card.

2. Move downward the SD card protection plate and then screw back the SD card protection

plate. The SD card installation is now complete.

2.4 Audio Cable / Video Cable / Power-Out Cable

You can use the supplied Video Cables to connect the cameras to the MDVR. You can also use the

supplied Power-Out Cable to power on the connected cameras.

Audio Input Audio Cable

Camera

Video Cable

DC12V Out

Rear View

Red: + (12V)

Black: - (GND)

DC12V Out Cable

2.5 Power Harness Cable

You can connect the mobile DVR to a power source between 9 VDC ~ 36 VDC.

Rear View

IGN (Yellow)

DC Power In (Red)

GND

(Black)

9 VDC ~ 36 VDC

Pins on Power

Cable

Power Harness Cable

Power Input

Pin Assignment

No.

Color

Description

No.

Color

Description

Red

DC Power Input

Black

GND

Red

DC Power Input

Black

GND

Red

DC Power Input

Yellow

IGN

Black

GND

3. Basic Connection

Power

Supply

Audio Input

2.5" HDD

Mouse

Notebook / PC

WAN

Xfleet (Client PC)

Speaker

Main Monitor

Camera

Video Cable

Audio Cable

DC12V Out

Front View Rear View

1. To record videos, insert a 2.5” HDD to the HDD tray. Remember to lock the HDD Key Lock

after inserting the HDD or the recording will not start (see 2.2 Hard Disk Installation).

2. To control the system, connect a mouse or use the supplied IR Remote Control.

3. To listen to audio of video source, connect a speaker to the Audio-out RCA socket. Note that

the speaker with a (built-in) amplifier and external power is required.

4. To manage the mobile DVR over network, use a standard RJ-45 cable to connect the mobile

DVR to the network.

Note: The mobile DVRs feature Wi-Fi/3G/4G function. You can optionally connect

Wi-Fi/3G/4G module and antenna to the mobile DVR for networking.

5. To view videos, connect a monitor to the VGA port using the VGA cable supplied by the

monitor manufacturer.

6. Connect the cameras to the mobile DVR using the supplied Video Cable. Please refer to 2.4

Audio Cable / Video Cable / Power-Out Cable.

7. To power on the cameras, connect the power inputs of the cameras to the 12VDC power

outputs of the mobile DVR using the supplied Power-Out Cable, please refer to 2.4 Audio

Cable / Video Cable / Power-Out Cable.

8. Connect the audio input devices to the mobile DVR using the supplied Audio Cable. Please

refer to 2.4 Audio Cable / Video Cable / Power-Out Cable. Note that the microphone with a

(built-in) amplifier and external power is required.

9. Connect the supplied Power Harness Cable to the power supply in the vehicle for powering

the mobile DVR. Please refer to 2.5 Power Harness Cable.

P/N: 4605EMV0402031A
