1.ProductOverview

The PowerPlex eDR400, 4 Channel Digital Video Recorder, combines the

power of triplex multiplexing and digital video recording into one

comprehensive unit. The compact design is suitable for conventional

surveillance in limited spaces where only 4 cameras are required.

The EDR series digital video recorders provide excellent picture quality

with comprehensive programming that can be easily configured to meet a

customer’s need. Network and internet capabilities enhance the power

of remote monitoring. The PowerPlex eDR400 is the only suitable

weapon for security surveillance today.

1.1Features

!" Triplex operation: Recording, Live, & Playback

!" 4 Color or 4 B/W camera inputs (NTSC/PAL)

!" Intelligent motion detection with programmable area and sensitivity

for each camera

!" Powerful alarm processor with configurable triggering conditions

and reactions

!" Event recording, time-lapse recording or both

!" Up to 5 seconds of pre-record time

!" Built-in MPEG-1 and JPEG compression/decompression, with

configurable quality

!" Storage on 3.5” Docking Hard Disk, hot-swappable (DVR option)

!" Versatile display formats: full-screen, 4, 7, 9, 10, 13 & 16 video

!" Alarm history log for Video Loss, Motion, Alarm input, Hard Disk

Full and Power.

!" Multi-level password to ensure high degree of security

!" Configurable (Recording/Event) behaviors, up to 16 kinds of date

and 16 kinds of time

!" Recording rate: 30 fps for NTSC, 25 fps for PAL

!" Playback rate: up to 30 fps for NTSC, 25 fps for PAL

!" Independent record & playback

!" 2 Fast Ethernet interfaces, 1 for peer-to-peer, 1 for upward

communications

!" RS-232 interface for point-to-point or internet communications

!" Reserved RS-232 interface for PTZ camera control

!" 2 USB ports for backup devices, printer, USB port ISDN TA device

or USB hub.

!" Built-in CompactFlash memory, power off data protection, power on

and run

!" Built-in 4x4 video matrix

!" Graphics User Interface

!" Audio recording capability (reserved)

!" Stackable eDR400 architecture (up to 4, reserved)

!" Remote surveillance and playback through WEB Browser such as IE

or Netscape

!" Remote alarm notification

!" Remote upload/download of system configurations

Administrator’sGuideandOperatingInstructions

1.2TechnicalOverview

1.2.1VideoInputandOutput

The digital video recorder is designed to support either NTSC/EIA or

PAL/CCIR standard. To make the auto detection of video standard

work, at least one camera must be connected to the video input.

Camera input impedance termination is set independently for each

camera automatically. Synchronizing or phasing cameras is not

required to achieve the frame rate of 30 fps for NTSC/EIA or 25

fps for PAL/CCIR.

1.2.2VideoProcessing

The video processor controls the switching of the built-in video

matrix according to the system configurations. The video encoder

keeps analyzing the video signal from the cameras, and encoding the

incoming pictures in JPEG format or MPEG-1 format that is digitized

and smaller in size at 30 fps for NTSC/EIA or 25 fps for PAL/CCIR.

During video playback, the video decoder decodes the digitized

format, no matter it is JPEG or MPEG-1, and then displays the

decoded pictures on the VGA monitor screen.

1.2.3VideoStorageandRetrieval

The encoded pictures are stored in the hard disks, with the stored

frame rate for each camera set by the administrator. If any event

(Alarm, Motion, or Video Loss) happens, all the encoded pictures for

the correspondent camera for the preset pre-record duration will be

saved to the hard disk, and the recording rate for that camera will be

changed to its alarm recording rate afterwards for the preset

post-record duration.

During video playback, the selected pictures can be saved to ZIP disk,

DVD RAM etc. in .MPG format for MPEG-1 encoded video

or .MOV format for JPEG encoded video.

For Time-Lapse Mode Recording Time, please refer to Appendix B.

1.2.4MotionDetection

The digital video recorder continuously monitors all camera inputs

for motion. When motion is detected, the system reacts according to

the motion action set by the administrator, including increase of

recording frame rate, sounding the buzzer, triggering the alarm output,

Administrator’sGuideandOperatingInstructions

event log, etc. Motion detection options for different time types can

be set for each camera input using a 16 (width) by 12 (height) target

overlay. You can also enable or disable motion alarms for different

time types. However, the recording frame rate is NOT

influenced by motion detection for the digital video recorder.

1.2.5VideoDisplay

The VGA monitor displays either live camera pictures or pictures

from hard disks. The display resolution is 800x600(NTSC and

PAL). As many as 16 million colors can be displayed in the

following screen formats: full screen, 4 windows, 7 windows, 9

windows, 10 windows, 13 windows, and 16 windows. All the main

displays are window based look and feel for ease of user operations.

1.2.6VideoPlayback

The user can select a previously recorded hard disk to review the

recorded video. Displaying of the recorded video is composed of

decoding the JPEG or MPEG-1 encoded video automatically and

multiplexing each camera video to its designated video window.

With the coded data that was inserted into each recorded picture, the

digital video recorder can reconstruct each camera’s tag name, status,

date, and time information automatically. The image can be

displayed in any multi-window format on the VGA monitor, just like

in live video mode.

1.2.7Non-editableRecordedImages

The retrieved images are saved as .MPG files or .MOV files, which

can be played by Media Player or QuickTime. Therefore, those files

are editable by the video editing packages, just like the recorded

images in the other digital video recorders. However, the recorded

images in the hard disks are not editable by the video editing

packages. (They even cannot be seen by those packages.) That is

to say, the recorded images are guaranteed to be the original images.

Administrator’sGuideandOperatingInstructions

2.Front&RearPanels

The following is a brief overview of the rear panel and front panel of

EDR400.

Rear Panel

1. Power Socket: Connects to the DC 24V power source or the AC

adapter (system accepts 18V~30V DC power source).

2. Camera 1 Video Input: BNC connector for Camera 1.

3. Camera 2 Video Input: BNC connector for Camera 2.

4. Camera 3 Video Input: BNC connector for Camera 3.

5. Camera 4 Video Input: BNC connector for Camera 4.

6. 75ohm Termination: Normally, the termination should be set as On.

However, if the corresponding camera is connected to other devices,

please set it as Off.

7. VGA Monitor Output.

8. RS-232 Connector #2: Connects to PTZ camera (reserved).

1 32 4 5

6 7 8

Administrator’sGuideandOperatingInstructions

Front Panel

9. Alarm In 1-4: Connects to alarm inputs 1-4 & 1 common ground.

10. Alarm Out: Connects to 2 Normally Closed alarm outputs (1-2), 2

Normally Open alarm outputs (3-4) & 1 common ground.

11. RS232 connector #1: Connects to Modem.

12. Mouse (Y Cable) Connector: Connects to the PS2 mouse or the

Y cable (attached) for the mouse and keyboard (optional) connection.

The mouse must be connected at system startup.

13. Audio In (reserved).

14. Audio Out (reserved).

15. 2 USB connectors: Connect to the DVD RAM, ZIP, printer, USB port

ISDN TA(Terminal Adapter) device or USB hub.

16. LAN connector 1: For peer-to-peer connection (reserved).

17. LAN connector 2: Connects to the RJ45 LAN connector.

18. Reset Button.

19. LEDs: LEDs for system active, power and HDD access.

910 11 12

13 14

15 16 17 18

Administrator’sGuideandOperatingInstructions

Side Panel

20. Hard Disk Tray: Please make sure to set the hard disk as master. To

access the hard disk, use the attached key to open the cover and

remove the hard disk holder. The key can’t be removed from the cover

while the cover is open.

21. Cooling FAN.

Inhaltsverzeichnis

Andere EverFocus DVR Handbücher

EverFocus

EverFocus ECOR 264-8/4 F2 Bedienungsanleitung

EverFocus

EverFocus ECOR264-D2 DVR Series Bedienungsanleitung

EverFocus

EverFocus 410M Bedienungsanleitung

EverFocus

EverFocus ECOR264-D2 DVR Series Bedienungsanleitung

EverFocus

EverFocus ENVR8304D-8CH Bedienungsanleitung

EverFocus

EverFocus ENDEAVOR EDRHD-2H14 Bedienungsanleitung

EverFocus

EverFocus EDSR-1600 Bedienungsanleitung

EverFocus

EverFocus Paragon EPARA16D3 Handbuch

EverFocus

EverFocus VANGUARD 16x8H Plus Bedienungsanleitung

EverFocus

EverFocus PowerPlex EDR1600 Bedienungsanleitung

EverFocus

EverFocus EMV401 Bedienungsanleitung

EverFocus

EverFocus EMV400 Bedienungsanleitung

EverFocus

EverFocus NVR8008X Bedienungsanleitung

EverFocus

EverFocus EDR410H Bedienungsanleitung

EverFocus

EverFocus Nevio ENVS1600 Bedienungsanleitung

EverFocus

EverFocus eZ.HD ECOR FHD 16x1 Bedienungsanleitung

EverFocus

EverFocus EDR810H Bedienungsanleitung

EverFocus

EverFocus EMV1200 FHD Bedienungsanleitung

EverFocus

EverFocus H.265 VANGUARD II Series Bedienungsanleitung

EverFocus

EverFocus EMV400S FHD Bedienungsanleitung

EverFocus

EverFocus ECOR264X1 Series Installations- und Betriebshandbuch

EverFocus

EverFocus DVR-100H Bedienungsanleitung

EverFocus

EverFocus EPHD04+ HDcctv Bedienungsanleitung

EverFocus

EverFocus EPHD16+U Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
