USER MANUAL

CO2Monitor

Model CO200

2 CO200-en-US v1.3 1/21

Introduction

Congratulations on your purchase of the Model CO200 Carbon Dioxide Meter. The CO200

measures and displays CO2level, air temperature, and relative humidity. Visible and audible

alarm (with alarm relay output), and real-time calendar clock, make this an ideal instrument for

indoor air quality (IAQ) monitoring. The CO200 is shipped fully tested and calibrated and, with

proper use, will provide years of reliable service.

Description

METER

1. LCD Multifunction display

2. Power LED indicator

3. Control buttons

Power adaptor jack, alarm relay jack, and sensors on rear

LCD DISPLAY

1. CO2concentration in ppm

2. Calendar clock

3. Air Temperature

4. % Relative Humidity

FUNCTION INDICATORS

ppm CO2measurement value

GOOD CO2(good air quality level)

NORMAL CO2(normal air quality level)

POOR CO2(poor air quality level)

Air Temp Air Temperature

Humidity % Relative Humidity

°C or °F Celsius or Fahrenheit units

MIN/MAX Minimum or Maximum readings

Flashes when CO2alarm is triggered (relay activates)

CONTROL BUTTONS

SET Long press to enter setup mode. Saves settings.

ESC Exits setup page/mode. Terminates CO

calibration.

RESET Long press to clear the MIN/MAX memories.

▲Select a mode or increase a value in the setup menu.

MIN/MAX ▼Access MIN/MAX function or use as down-arrow in setup mode.

Long press SET, MIN/MAX, and

▲

to enter the CO

calibration mode

3 CO200-en-US v1.3 1/21

Operation

Powering the CO200

Plug the supplied power adaptor (5V/0.5A) into the power jack on the back of the meter

(ensure that you connect to the power jack on the left, not the alarm relay jack on the right;

see diagram in the Alarm Relay section below).

Now connect the power adaptor to an AC power source, the meter will switch ON, the front

panel LED power indicator will light, and the beeper will sound. If the power source voltage

is incorrect, “bAt“ will display and the LED indicator will flash. Do not use the CO200 with an

incorrect power source.

In normal operation the LCD will display CO

, temperature, humidity, date, and time. The air

quality level is also displayed (GOOD, NORMAL, POOR).

Measurements

The meter starts measuring as soon as it is powered and updates readings once per second. If the

operating environment changes (from high to low temperature, for example), it will require 2 minutes

for the CO2 sensor to respond and 10 minutes for the Relative Humidity sensor to respond.

Note: Do not hold the meter close to your mouth or any other source of CO2.

MIN/MAX Mode

In the normal mode, press the MIN/MAX button to see the minimum or the maximum CO2,

Temperature, and Humidity values. Each press of the MIN/MAX button steps through the MIN, the

MAX, and then the normal display mode.

Long press the RESET button to clear the minimum and maximum values from memory.

Alarm Function

The CO200 features an audible (beeper) and visual (flashing fan icon) alarm that warn when the

CO2concentration exceeds the programmed threshold. There are two alarm thresholds, the ‘POOR’

air quality threshold (that triggers the alarm), and the ‘NORMAL’air quality threshold (that cancels

the alarm). See the Setup mode to set these threshold settings.

The alarm output relay switches on and off as the CO2alarm switches on and off (see next section).

The audible alarm can be manually silenced by pressing any key, or it will automatically stop when

the CO2reading is no longer in the alarm region (the user can subsequently press and hold the

RESET button to re-activate the alarm, if desired).

If the beeper is manually silenced, it will sound again when readings

move out of, and then back into, the alarm region.

The fan icon continues to flash even when the beeper is manually

silenced. It disappears only when readings are no longer in the alarm

region.

4 CO200-en-US v1.3 1/21

Alarm Relay Output

The CO200 includes an alarm relay output that can be connected to an external device such as an

alarm light, warning sign, alarm buzzer, or controlling device (ON/OFF switch to a fan, for example).

The relay switches ON and OFF as the CO200’s CO2alarm switches ON and OFF (see previous

section for more on the alarm feature). The fan display icon flashes each time the relay closes.

The rear relay output jack requires a 2.5mm stereo phone plug. The relay is rated for 1A at 30VDC

or 0.5A or 125VAC.

1. AC adaptor input (5VDC)

2. Alarm relay output

3. Phone plug wiring

Setup Mode

Long press the SET button to enter the setup mode.

P1.1: Threshold setting for the ‘GOOD’air quality display icon

When entering the setup mode, P1.0and ‘CO2’are displayed. Press the SET button again to

access P1.1for setting the CO2upper limit (threshold) for the ‘GOOD’air quality display icon. The

current set value will appear blinking on the display.

Press the ▲or ▼button to increase or decrease the value. Each press adjusts in 100 ppm

increments. The range is 0 to 700 ppm (default is 700 ppm).

When the value has been set, press the SET button to confirm the ‘GOOD’threshold and move to

P1.2for setting the ‘NORMAL’display threshold. Press the ESC button to exit without saving.

P1.2: Threshold setting for the ‘NORMAL’air quality icon and the CO2Alarm

P1.2is used for setting the CO2high threshold for the ‘NORMAL’air quality display icon. It is also

the low threshold for the alarm beeper, the flashing fan alarm icon, and the output relay. The current

set value will appear blinking on the display.

Press the ▲or ▼button to increase or decrease the value. Each press adjusts in 100 ppm

increments. The range is 700 to 1000 ppm (default is 1000 ppm).

When the value has been set, press the SET button to confirm the ‘NORMAL’limit and move to

P1.3for setting the ‘POOR’display threshold. Press the ESC button to exit without saving.

5 CO200-en-US v1.3 1/21

P1.3: Threshold setting for the ‘POOR’air quality icon and CO2Alarm

P1.3is used for setting the high CO2threshold for the ‘POOR’air quality display icon, alarm beeper,

flashing fan icon, and output relay. The current set value will appear blinking on the display.

Press the ▲or ▼button to increase or decrease the threshold. Each press adjusts in 100 ppm

increments. The range is 1000 to 5000 ppm (default is 1000 ppm).

When the value has been set, press the SET button to confirm and return to the P1.0 screen. Press

ESC to exit without saving.

Caution: Set the alarm value within the specified range of the CO200 where accuracy is assured.

Out of specification readings are for reference only.

P2.0 Temperature Units

Press the ▲button in P1.0mode to access P2.0for setting the temperature display units.

Press the SET button to access the P2.1 setting mode. The °C or °F will blink (default is °C).

Press the ▲button to change the units. Press the SETbutton to confirm the setting or press the

ESC button to exit without saving and return to P1.0.

P3.0 Real-Time Clock

Press the ▲ button in P1.0twice to access P3.0for setting the real-time calendar clock. Press the

SET button and the meter will access P3.1, showing the blinking YEAR on the lower left. To change

the year, press the ▲ or ▼ button. Press the SET button to save the setting and to enter P3.2(or

press the ESC button to return to P3.0without saving the setting).

Press the ▲button from P3.1to access P3.2. The current MONTH setting will blink. To change the

month, press the ▲ or ▼ button. Press the SET button to save the setting and to enter P3.3(or

press the ESC button to return to P3.0without saving the setting).

Repeat as above to finish setting the P3.3(DATE), P3.4(HOUR) and P3.5(MINUTE)

6 CO200-en-US v1.3 1/21

P4.0: Factory Default Reset

Press the ▲button in P1.0 three times to access P4.0 where you can reset the meter to its default

settings. Press SET and the meter will access P4.1 with a blinking “No”. Press the ▲to switch the

status to ‘Yes’and then press either the SET button to confirm and continue or the ESC button to

abort the process.

Calibration

The meter is calibrated to a 400ppm CO2concentration at the factory. If the accuracy becomes a

concern, or after one year of use, return the meter to Extech for calibration or continue below.

ABC (Automatic Baseline CO2Calibration)

ABC (Automatic Baseline Calibration) establishes a baseline calibration to eliminate the zero drift of

the infrared sensor. The ABC function is always “ON” when the meter is powered.

ABC is designed to calibrate the meter at the minimum CO2reading detected over 7.5 days of

continuous monitoring (power on). It assumes that the area being tested receives fresh air with a

CO2level of approximately 400ppm at some point during the monitoring period. Note that It is not

suitable to use the CO200 in closed areas with consistently high CO2levels 24 hours a day.

Manual CO2Calibration

Manual calibration is suggested to be done outdoors on a clear day with good ventilation and fresh

air where the CO2level is approximately 400 ppm. Do not calibrate on a rainy day because high

humidity will affect the CO2level in air.

CAUTION: Do not calibrate the meter in an atmosphere of unknown CO2concentration. Do not

calibrate in places crowded with people, pets, plants, or where high CO2concentrations may exist

such as near ventilation ducts or fireplaces.

Place the meter in the calibration area and switch it on. Press and hold the

SET, ▲, and ▼buttons simultaneously for > 1 second to enter CO2

calibration mode. “400ppm”and “CO2” will blink while the calibration is in

process.

The calibration will require approximately five (5) minutes. When the

calibration is complete, the blinking stops and the meter returns to the normal operating mode.

Press ESC to abort a calibration session (not recommended).

7 CO200-en-US v1.3 1/21

Specifications

Function

Range

Resolution

Accuracy

CO2

0 to 9999ppm

1ppm

± (5%rdg + 50ppm)

Temperature

-10 to 60°C (14 to 140°F)

0.1°

± 0.6°C (0.9°F)

Humidity

0.1 to 99.9%

0.1%

± 3% (10 to 90%)

± 5% (< 10% or > 90%)

Display

Multi-function LCD

Sensor Type

CO2: NDIR (non-dispersive infrared) technology

Humidity: Capacitance sensor

Temperature (air): Thermistor

Response

CO2: < 2min for 90% step change

Air temperature: < 2min for 90% step change

RH: < 10min for 90% step change

Alarm relay output

Rated: 1A 30VDC or 0.5A 125VAC

Relay opens/closes as the CO2alarm switches ON/OFF

Operating Conditions

14 to 140°F (-10 to 60°C); < 90% RH non-condensing

Storage Conditions

-4 to 140°F (-20 to 60°C); <99% RH non-condensing

Power Supply

5VDC (±10%), ≥ 500mA (supplied adaptor)

Dimensions

4.6 x 4 x 4” (117 x 102 x 102 mm)

Weight

7.2 oz (204 g)

Maintenance

Cleaning and storage

1. The meter should be cleaned with a damp cloth and mild detergent when necessary. Do not use

solvents or abrasives.

2. Store the meter in an area with moderate temperature and humidity.

8 CO200-en-US v1.3 1/21

Troubleshooting

No power

Check that the AC adaptor is properly connected.

Slow response

Check that rear air flow vents are not blocked.

"BAt” and green LED flash

The adaptor output voltage is too high or too low.

Error Display Codes

CO2

Display

Code

E01

CO2sensor malfunction.

Return for repair.

E02

CO2reading out of range (low).

Re-calibrate the meter. If problems persist,

return for repair.

E03

CO2reading out of range (high).

Place the meter in fresh air and allow 5 minutes.

If problem persists, re-calibrate the meter.

Return for service if necessary.

E17

CO2senor failure.

Return for repair.

Temperature

Display

Code

E02

Air temperature out of

range (low).

Place the meter at room temperature for 30

minutes. If problem persists, return for repair.

E03

Air temperature out of

range (high).

Same as EO2.

E31

Sensor malfunction.

Return for repair.

Humidity

Display

Code

E04

Temperature display shows error.

Refer to temperature error codes.

E11

RH calibration failure.

Please return for repair.

E34

RH sensor circuit failure.

Please return for repair.

9 CO200-en-US v1.3 1/21

CO2Level Guidelines

Important: The public information provided below is offered for reference only. FLIR Systems, Inc. is not liable for

injury to persons or property through the use or misuse of this device. It is the responsibility of the user to ensure

proper air quality in the residential or commercial spaces where this device is to be used.

Non-enforced reference levels:

•250 - 350 ppm: Normal background outdoor levels.

•350- 1,000 ppm: Typical level found in occupied spaces with good air exchange.

•1,000 –2,000 ppm: Level associated with complaints of drowsiness and poor air.

•2,000 –5,000 ppm: Level associated with headaches, sleepiness, and stagnant, stale, or stuffy air. Poor

concentration, loss of attention, increased heart rate and slight nausea may also be present.

•>5,000 ppm: Exposure may lead to serious oxygen deprivation resulting in permanent brain damage, coma,

and death.

Regulatory exposure limits:

•ASHRAE Standard 62-1989 (1000ppm): CO2concentration in occupied building should not exceed

1000ppm.

•OSHA (5000ppm): Time weighted average over five 8-hour workdays should not exceed 5000ppm.

•Building bulletin 101 (Bb101) 1500ppm: UK standards for schools indicate that CO2, averaged over an

entire day (i.e. 9am to 3:30 pm), should not exceed 1500ppm.

•Germany, Japan, Australia, UK (5000ppm): 8-hour weighted average occupational exposure limit is

5000ppm.

Two-year Warranty

FLIR Systems, Inc. warrants this Extech brand instrument to be free of defects in parts and workmanship for two

years from date of shipment (a six-month limited warranty applies to sensors and cables). To view the full warranty

text please visit: http://www.extech.com/support/warranties.

Calibration and Repair Services

FLIR Systems, Inc. offers calibration and repair services for the Extech brand products we sell. We offer NIST

traceable calibration for most of our products. Contact us for information on calibration and repair availability, refer to

the contact information below. Annual calibrations should be performed to verify meter performance and accuracy.

Product specifications are subject to change without notice. Please visit our website for the most up-to-date product

information: www.extech.com.

Contact Customer Support

Customer Support Telephone List: https://support.flir.com/contact

Calibration, Repair, and Returns: repair@extech.com

Technical Support: https://support.flir.com

www.extech.com

Andere Handbücher für CO200

Inhaltsverzeichnis

Andere Extech Instruments Messgerät Handbücher

Extech Instruments

Extech Instruments AUT10 Bedienungsanleitung

Extech Instruments

Extech Instruments ExStik RE300 Bedienungsanleitung

Extech Instruments

Extech Instruments MA250 Bedienungsanleitung

Extech Instruments

Extech Instruments MA61 Bedienungsanleitung

Extech Instruments

Extech Instruments SP505 Bedienungsanleitung

Extech Instruments

Extech Instruments EX613 Bedienungsanleitung

Extech Instruments

Extech Instruments HD300-NISTL Bedienungsanleitung

Extech Instruments

Extech Instruments HDV7C-55-HD-1 Bedienungsanleitung

Extech Instruments

Extech Instruments PH220-C Bedienungsanleitung

Extech Instruments

Extech Instruments SL510 Bedienungsanleitung

Extech Instruments

Extech Instruments AN100 Bedienungsanleitung

Extech Instruments

Extech Instruments HDV7C-55-HD-1 Bedienungsanleitung

Extech Instruments

Extech Instruments TM100-NIST Bedienungsanleitung

Extech Instruments

Extech Instruments 407738 Bedienungsanleitung

Extech Instruments

Extech Instruments MO290-NISTL Bedienungsanleitung

Extech Instruments

Extech Instruments 433201A Bedienungsanleitung

Extech Instruments

Extech Instruments 461830 Bedienungsanleitung

Extech Instruments

Extech Instruments 421509 Bedienungsanleitung

Extech Instruments

Extech Instruments EN510 Bedienungsanleitung

Extech Instruments

Extech Instruments AN510 Bedienungsanleitung

Extech Instruments

Extech Instruments LT300 Bedienungsanleitung

Extech Instruments

Extech Instruments 382095 Bedienungsanleitung

Extech Instruments

Extech Instruments CO10 Bedienungsanleitung

Extech Instruments

Extech Instruments 250W Series Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
