User’s Guide

MultiTecTM Series

Digital MultiMeters with PC Interface

Models: MT310

MT320

MT330



Tech Support

Hotlines

781-890-7440

ext. 200

[email protected]

WARRANTY

EXTECH INSTRUMENTS CORPORATION warrants this instrument to be free of defects in parts and workmanship for

three years from date of shipment (a six month limited warranty applies on sensors and cables). If it should become

necessary to return the instrument for service during or beyond the warranty period, contact the Customer Service

Department at (781) 890-7440 ext. 210 for authorization. A Return Authorization (RA) number must be issued before

any product is returned to Extech. The sender is responsible for shipping charges, freight, insurance and proper

packaging to prevent damage in transit. This warranty does not apply to defects resulting from action of the user such as

misuse, improper wiring, operation outside of specification, improper maintenance or repair, or unauthorized modification.

Extech specifically disclaims any implied warranties or merchantability or fitness for a specific purpose and will not be

liable for any direct, indirect, incidental or consequential damages. Extech's total liability is limited to repair or replacement

of the product. The warranty set forth above is inclusive and no other warranty, whether written or oral, is expressed or

implied.

REPAIR AND CALIBRATION SERVICES

Extech offers complete repair and calibration services for all of the products we sell.

For periodic calibration, NIST certification or repair of any Extech product, call customer

service for details on services available. Extech recommends that calibration be performed

on an annual basis to insure calibration integrity.

right of reproduction in whole or in part in any form. Version 1.2 4/00

Introduction

Congratulations on your purchase of Extech model MT310, MT320, or MT330 digital multimeter. Properly used, this meter

will provide many years of reliable service. All models measures AC/DC Voltage/Current, Resistance, Frequency and

Capacitance. All models are Autoranging and include a PC Interface feature. The MT320 and MT330 also measure

temperature. The Model MT330 is True RMS responding.

Safety

International Safety Symbols

Refer to the manual Hazardous voltages Double insulation

for further information may be present.

UL Listed

The UL mark does not indicate that this product has been evaluated for the accuracy of its readings.

Safety Precautions

1. Improper use of this meter can cause damage, shock, injury or death. Read and understand this user manual

before operating the meter.

2. Make sure any covers or battery doors are properly closed and secured.

3. Always remove the test leads before replacing the battery or fuses.

4. Inspect the condition of the test leads and the meter itself for any damage before operating the meter. Repair any

damage before use.

5. Do not exceed the maximum rated input limits.

6. Use great care when making measurements if the voltages are greater than 25VAC rms or 35VDC. These

voltages are considered a shock hazard.

7. Always discharge capacitors and remove power from the device under test before performing Capacitance, Diode,

Resistance or Continuity tests.

8. Remove the battery from the meter if the meter is to be stored for long periods.

9. To avoid electric shock, do not measure AC current on any circuit whose voltage exceeds 250V AC.

10. Voltage checks on electrical outlets can be difficult and misleading because of the uncertainty of connection to the

electrical contacts. Other means should be used to ensure that the terminals are not "live".

Specifications

Function Ranges Accuracy

400.0mV ±(0.3% reading + 5 digits)

4.000V, 40.00V, 400.0V, ±(0.1% reading + 5 digits)MT330

±(0.3% reading + 5 digits)MT320

±(0.5% reading + 5 digits)MT310

DC Voltage

(V DC)

1000V ±(0.5% reading + 5 digits)

100.0-400.0mV ±(1.5% reading + 5 digits)

4.000V,40.00V, 400.0V ±(1.0% reading + 5 digits) (40Hz to 1kHz)

AC Voltage

(V AC)

(Model MT330

True RMS) 700.0V ±(1.5% reading + 5 digits)

400.0µA, 4000µA, 40.00mA, 400.0mA ±(1.2% reading + 10 digits)

DC Current

(A DC) 20.00A ±(2% reading + 10 digits)

400.0µA, 4000µA, 40.00mA, 400.0mA ±(1.5% reading +10 digits) (40Hz to 1kHz)

AC Current

(A AC)

(Model MT330

True RMS)

20.00A ±(2% reading + 10 digits)

Function Ranges Accuracy

400.0Ω, 4.000kΩ, 40.00kΩ, 400.0kΩ, 4000kΩ±(0.5% reading + 10 digits)

Resistance

40.00MΩ±(1% reading + 5 digits)

500.0mHz Not specifiedFrequency

5.000Hz, 50.00Hz, 500.0Hz, 5.000kHz, 50.00kHz,

500.0kHz, 5.000MHz, 10.00MHz

±(0.1% reading + 2 digits)

(250mVac peak minimum)

Capacitance 40.00nF, 400.0nF, 4.000uF, 40.00uF, 100.0uF ±(2% reading + 10 digits)

0.0-212.0°F ±(3°+ 5 digits)

212.0 – 400.0°F

Temp °F

(MT320 and

MT330 only) 400.0 - 2000°F

±(3% reading + 5 digits)

-20.0 – 100.0°C ±(3°+ 5 digits)

100.0 – 400.0°C

Temp °C

(MT320 and

MT330 only) 400.0 - 1370°C

±(3% reading + 5 digits)

Input Limit Specifications

Function Maximum Input

V DC or V AC 1000V DC or AC Peak, < 10 seconds

mA DC/AC 400mA DC/AC, fused 250V, 0.5A

A DC/AC 20A DC/AC, < 30 seconds (every 15min); Fused 250V, 20A

Frequency 250V DC or AC peak

Resistance 250V DC or AC peak, <10 seconds

Duty Cycle 250V DC or AC peak

General Specifications

Duty Cycle 0.1% to 99.9%

Diode Test Test voltage of 1.5V (max)

Continuity Check Audible tone if the resistance is less than 60Ω

Input Impedance 10MΩ(VDC and VAC), 100MΩin the 400mV range

Display 4000 count (3 ¾ digit) LCD, Model MT330 with back lighting

Overrange indication LCD displays "OL"

Polarity Auto positive polarity; Minus (-) sign for negative polarity

Low Battery Indication Battery symbol indicates low battery condition.

Power Supply One 9V battery (NEDA 1604)

Fuses µA, mA ranges: 500mA/250V ceramic; 20A range: 20A/250V ceramic

Operating Temperature 32oF to 104oF (0oC to 40oC)

Storage Temperature -4oF to 140oF (-20oC to 60oC)

Accuracy Temperature 64oF to 82oF (18oC to 28oC)

Relative Humidity < 80% RH operating, (<70% RH storage)

Dimensions / Weight 3.5x7x1.3" (88x178x33mm) / 0.7lb (315g)

Description

Meter (MT330 pictured)

1. 3 3/4 Digit (4000 count) Liquid Crystal Display (LCD).

2. Function keys

3. Rotary function switch

4. 20A, mA/µA, COM, V/Hz/Ω/Capacitance input jacks.

5. Temperature probe input socket (MT320 and MT330 only).

6. RS232 PC interface connector

Display

1. AutoRange mode

2. DC current or voltage

3. Negative (minus) sign

4. AC current or voltage

5. Input jack status icons

6. 20A blown fuse indicator

7. uA/mA blown fuse indicator

8. Incorrect test lead insertion indicator (active

in Capacitance, Hz, Ohms, Diode,

Continuity and ACV/DCV modes)

9. Power warning for Ohm, Cap and Diode

10. Continuity symbol

11. Diode symbol

12. Low Battery symbol

13. Relative mode indicator

14. Range hold indicator

15. PC interface indicator

Operation

Measurement Preparations and Considerations

1. ALWAYS push the power key to the OFF position when the meter is not in use. This meter has Auto Power OFF

that automatically shuts the meter OFF if 30 minutes elapse without activity. To recover from Auto OFF, press any

key. (Alternately, press the POWER key, wait three seconds, and press the POWER key again).

2. If "OL" appears on the display during a measurement, the measurement exceeds the range selected. Change to a

higher range.

AC or DC Voltage Measurements

1. Set the function switch to the "V" position

2. Press the "DC/AC" key until "DC or AC" appears on the LCD.

3. Insert the black test lead into the negative COM jack and the red test lead into the positive Vjack.

4. Touch the test probe tips to the circuit under test.

5. Read the voltage on the display
