Introduction

CongratulationsonyourpurchaseoftheExtechEasyViewDualKThermometer.Thisdevice

offersdualthermocoupleinputswithmultifunctionLCDdisplay.Thismeterisshippedfully

testedandcalibratedand,withproperuse,willprovideyearsofreliableservice.



MeterDescription

1. LCDdisplay

2. DataHOLDbutton

3. Powerbutton

4. Max/Minbutton

5. OFFSETbutton

6. Backlitebutton

7. C/F/Kunitsselectbutton

8. ElapsedTIMEbutton

9. T1orT1‐T2orT2displayselectbutton

10. T1Thermocoupleinputsocket

11. T2Thermocoupleinputsocket

12. Batterycompartment(rear)



www.ponpe.com

Contact

[email protected]

EA10 -EN V2.1 1/14

Operation

Connectingthermocouples

1. ThismeteracceptstwotypeKthermocoupleswithspadeplugs(sub‐miniaturetypewithone

spadewiderthantheother).

2. Plugthethermocouple(s)intothemeter'sT1and/orT2thermocoupleinputjack(s).

TurnPowerON

1. Pressthebuttontoturnpoweron.Themeterwillperformashortself‐test.

2. Ifaprobeisnotinsertedtothemeter,an“OL”indicationwillappearonthedisplay.

Selecting°C,°For°Kunitsofmeasure

PresstheC/F/Kbuttontoselectthedesiredtemperatureunitofmeasure.

SelectingT1,T2,andT1‐T2Displays

PresstheT1T2T1‐T2buttontostepthroughandselectadisplayof:

a. T1(thermocouple1)displaysintheupperlargedisplayandT2(thermocouple2)temp.

displaysinthelowersmalldisplay.

b. T1plusT2

c. T1‐T2plusT1

d. T1‐T2plusT2

MIN,MAX,AVGRecordingFunctionwithTimer

PresstheMX/MNbuttontobegincapturingtheMinimum(MN),Maximum(MX),andAverage

(AVG)temperaturevalues.TheElapsedTimeclockwillappearonthelowerleftofthedisplay

andthelowerdisplaywillindicatetheMAXIMUM(MX)valuecapturedsincetheMX/MNbutton

waspressed.

PresstheMX/MNbuttontochangethelowerdisplaytoreflectthestoredMXtoMNandthen

AVGvalueoftheinputselectedintheupperdisplay(T1,T2orT1‐T2).Eachreadingwillbe

accompaniedbyaTimervalueindicatingthetimewheneachreadingwasrecorded.

PresstheTimebuttontochangetheelapsedtimeformatfrommin:sectohour:min.

PressandHoldtheMX/MNbuttonuntilthedisplayreturnstostandardoperationtoexitthe

MX/MNfunction.

DataHold

PresstheHOLDbuttontofreezethereadinginthedisplay.The'H'holdiconwillappearonthe

upperleft‐handsideofthedisplay.PresstheHOLDbuttonagaintoreturntonormaloperation

(the'H'holdiconwilldisappear).

Offset

TheOffsetModepermitstheusertostorethetemperaturereadingasareferencevalueand

comparethisreferencevaluetosubsequenttemperaturereadings.InOffsetmode,themeter

displaystheactualmeasuredtemperatureminusthestoredreferencevalue.

PresstheOFFSETbuttontostorethecurrentlydisplayedtemperaturereadingsandenterthe

Offsetmode.“OFFSET”willappearinthedisplay.

PresstheOFFSETbuttontoexitthemode.

www.ponpe.com

Contact

[email protected]

EA10 -EN V2.1 1/14

Backlight

PressthebacklightbuttontoturnontheLCDdisplaybacklight.Thebacklightwill

automaticallyturnoffafteroneminuteorpressthebuttonagaintoturnthelightoff.

AutoPowerOFF

Themeterwillautomaticallyturnoffafter30minutesifnokeysarepressedduringthisperiod.

Autopoweroffisdisabledinthemax/minrecordingmode.

TurningPowerOFF

Pressthebuttontoturnpoweroff.



www.ponpe.com

Contact

[email protected]

EA10 -EN V2.1 1/14

Specifications

MeasurementRange‐200to1999oF(‐200to1360oC)

Resolution0.1oC/oF<200o,1oC/oF>200o

Accuracy

(@23±5oC)

±(0.3%reading+2oF)@‐200oFto1832oF

±(0.5%reading+2oF)@1832oFto1999oF

±(0.3%reading+5oC)@‐200oCto‐93oC

±(0.3%reading+1oC)@‐93oCto1000oC

±(0.5%reading+1oC)@1000oCto1360oC

TemperatureCoefficient0.1timestheapplicableaccuracyspecificationsperoCfrom0oCto

18oCand28oCto50oC(32oFto64oFand82oFto122oF)

Note:TemperatureaccuracydoesnotincludetheaccuracyofthetypeKprobe.

Note:Thetemperaturescaleisbasedontheinternationaltemperaturescaleof1990(ITS90).

GeneralSpecifications

Display  DualDisplayMulti‐functionLCDwithBacklight

InputProtection 60VDC;24VACrms

DisplayUpdateRate1persecond

Overrangeindication"OL"appearsontheLCD

Openinputindication"OL"appearsontheLCD

Lowbatteryindication“BT”appearsontheLCD

Powersupply 6AAABatteries

Batterylife Approximately200hourswithcarbonzincbatteries

OperatingTemperature32to122oF(0to50oC)

OperatingHumidity<80%RH

StorageTemperature14to140oF(‐10to60oC)

StorageHumidity 10to80%RH

Dimensions 5.91x2.8x1.4"(150x72x35mm)

Weight  Approx.8.29oz.(235g)withbattery



www.ponpe.com

Contact

[email protected]

EA10 -EN V2.1 1/14

Warranty

FLIRSystems,Inc.warrantsthisExtechInstrumentsbranddevicetobefreeofdefectsinpartsandworkmanshipforthree

yearsfromdateofshipment(asixmonthlimitedwarrantyappliestosensorsandcables).Ifitshouldbecomenecessaryto

returntheinstrumentforserviceduringorbeyondthewarrantyperiod,contacttheCustomerServiceDepartmentfor

authorization.Visitthewebsitewww.extech.comforcontactinformation.AReturnAuthorization(RA)numbermustbeissued

beforeanyproductisreturned.Thesenderisresponsibleforshippingcharges,freight,insuranceandproperpackagingto

preventdamageintransit.Thiswarrantydoesnotapplytodefectsresultingfromactionoftheusersuchasmisuse,improper

wiring,operationoutsideofspecification,impropermaintenanceorrepair,orunauthorizedmodification.FLIRSystems,Inc.

specificallydisclaimsanyimpliedwarrantiesormerchantabilityorfitnessforaspecificpurposeandwillnotbeliableforany

direct,indirect,incidentalorconsequentialdamages.FLIR’stotalliabilityislimitedtorepairorreplacementoftheproduct.The

warrantysetforthaboveisinclusiveandnootherwarranty,whetherwrittenororal,isexpressedorimplied.

Calibration,Repair,andCustomerCareServices

FLIRSystems,Inc.offersrepairandcalibrationservicesfortheExtechInstrumentsproductswe

sell.NISTcertificationformostproductsisalsoprovided.CalltheCustomerServiceDepartmentfor

informationoncalibrationservicesavailableforthisproduct.Annualcalibrationsshouldbe

performedtoverifymeterperformanceandaccuracy.Technicalsupportandgeneralcustomer

serviceisalsoprovided,refertothecontactinformationprovidedbelow.



Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform

www.extech.com

SupportLines:U.S.(877)439‐8324;International:+1(603)324‐7800

TechnicalSupport:Option3;E‐mail:[email protected]

Repair&Returns:Option4;E‐mail:[email protected]

Productspecificationsaresubjecttochangewithoutnotice

Pleasevisitourwebsiteforthemostup‐to‐dateinformation
