Flashforge Foto 13.3 Bedienungsanleitung

This guide is only applicable to FLASHFORGE Foto 13.3 3D printer

Foto 13.3

EN/CN-A02

1. When the glass over the LCD screen cracks, stop printing immediately, otherwise

the crack will expand and cause more serious damage.

2. The maximum tank volume is 3 liters. Note that moderate resin must be added

so its level will be between the upper and lower marker lines in the tank.

3. The correct way to cut oﬀ power supply is to turn oﬀ the power switch of the

printer.

4. Do not cut oﬀ the power abruptly during printing to avoid mechanical damage.

WARNING

Three screws A, B and C indicated in the picture should not be loosened,

otherwise the printing will fail!

NOTE

Each 3D printer has undergone a printing test before leaving the

factory. If there are residual consumables in the feed resin tank or

slight scratches on the printing platform, it is normal and will not

aﬀect the use.

Dear customer:

Thank you for choosing and using the products of Flashforge Technology. Thank

you for your great support and help. The product quality and performance of

Flashforge Technology are excellent. For your convenience, please read the

manual carefully before use, and strictly follow the instructions of the manual.

The entire Flashforge Technology team is always ready to provide you with the

best quality service. No matter what problems you encounter during use, please

manual.

In order for you to experience our products better, you can also obtain equipment

operating knowledge from the following channels:

Please unpack it carefully, you can take out the attached quick start guide from

the top layer of foam. The quick start guide will help you get familiar with the

device as quickly as possible and successfully complete the ﬁrst printing

experience.

Note

Quick Starter Guide

Foreword

Safety tips: Please make sure to read the following safety

tips carefully

Work Environment Safety

Notice

Keep your work place tidy.

Do not operate in the presence of ﬂammable liquids, gases or dust.

Children and untrained personnel should not operate the equipment alone.

Place Requirements

The device must be placed in a dry and ventilated

environment. The distances of the left, right and

back side space should be at least 20cm, and the

distance of the front side space should be at least

35cm.

Environment Requirements

Temperature: RT 15-30℃

Moisture: 20%-70%

Electrical Requirements

Be sure to ground the device; do not modify the plug of the device. (Ungrounded/

incorrectly grounded/modiﬁed plugs will inevitably increase the risk of leakage)

Do not expose the device to humidity and hot sun. (Wet environment will increase

the risk of leakage/exposure will accelerate the aging of plastic parts)

Do not abuse the power cord, and be sure to use the power cord provided by Flashforge.

Do not use the device during thunderstorms. If you do not use the device for a long

time, please turn oﬀ the device and unplug the power cord.

Personal Safety

Please don’t direct touch the photopolymer resin with hands.

Please put on gloves and masks during operation.

Please don’t look at the light source directly.

Do not operate the device while you are tired or under the inﬂuence of drugs, alcohol

or medication.

Photopolymer Resin

Requirements

Please store the photosensitive

resin solution in a dark and dry

environment. Please place it in

a place out of the reach of

children. Please ensure that the

label surface of the bottle is

facing the eye-catching

direction.

Legal Notice

The user has no right to make any changes to this manual.

Flashforge Technology will not be responsible for any safety accidents caused by

customers disassembling or modifying the equipment by themselves. Without the

permission of Flashforge no one may modify or translate this manual. This manual is

protected by copyright, and Flashforge reserves the right of ﬁnal interpretation of

this manual.

First edition (March 2021)

Photopolymer Resin Storage

Unused photopolymer resin needs to be stored in a dark, dry, cool place, and out of

the reach of children. Ensure the bottle body logo faces in an eye-catching and visible

direction.

Cautions

Operate the device in a well-ventilated environment

Do not leave the device unattended for long

Do not make any modiﬁcations to the device

Do not operate the device in bright light.

Never use the device for illegal activities.

Never use the device to make any food storage vessels.

Never use the device to make any electrical appliance.

Never put the model into your mouth.

Do not remove the models with force.

1. Z-axis 2. Platform Tighten Knob 3. Leveller 4. Build Plate

5. Light Shield 6. LCD 7. Box Tighten Knob 8. Resin Box

9. Touched Screen 10. Ethernet 11.USB Stick Port

12. Power Switch 13. Power Slot

Getting To Know Your 3D Printer

3D Printer Resin Power Cable

After-sales Service Metal Scraper Plastic Scraper Brush

Rubber Glove

Soft Cloth Filter Diagonal Pliers

USB Stick Wrench

Accessory Kit

Tweezers

Quick Start Guide

Accessory Box

1. Cut the tie to open the box. 2. Take out the top foam.

3. Lift up and remove the outer box. 4. Remove the foam on both sides.

5. Open the front door of the device and

prepare to take out the foam inside.

6. Loosen the platform fastening knob.

Unpacking

7. Take out the molded platform. 8. Remove the foam. Note that there is a

bottle of resin and a tool box inside the

foam cotton.

9. Complete.

1. Conﬁrm that the printing platform is clean. Install the platform as shown in the picture:

ﬁt it on the Z-axis and fasten it with hand-screw nuts.Conﬁrm that there is no

misalignment in the installation of the platform and that it is not loose when moved

manually.

2. Loosen the four M6 screws in the upper-adjustment block of the platform assembly.

Note that there are two screws on the both sides of the upper adjustment block.

Loosen

Leveling

4. Place 3 sheets of A4 paper over the

printer screen.

5. Click on [Tools] in the main interface,

and then click on [Z-axis Move].

3. Connect the power cable to theadapter, insert the outputof the power

adapter into the power inlet port on the back of the printer. Turn on the

switch.

Print Tool System

Move Residue WLAN

Stop
